Go big
Versatile videowall display.
55"
Direct LED Backlight
Full HD
700 cd/m²
Operate, monitor and maintain with CMND and Control
Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.
CMND and Create. Develop and launch your own content
Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.
FailOver ensures that content is always playing
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.
OPS slot allows for PC embedding without cabling
Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.
Remote system management through CMND
Take control of your Philips Professional Display network. CMND lets you manage, update, maintain and play via one easy-to-use interface. From installation to daily operation.
Add Android processing power with an optional CRD50 module
Embed an Android System-on-Chip (SoC) into your Philips Professional Display. The optional CRD50 module is an OPS device that enables Android processing power without the need for cables. Simply slide into the OPS slot, which contains all the connections needed to run the module (including power supply).
Tiling mode. Create tiled 4K videowalls of any size
Connect two or more Philips professional displays to create a tiled videowall — without the need for external devices. A single player takes care of content, whether you have four screens or 40. 4K content is fully supported and if you're showing that content on four screens you get the best possible dot-by-dot resolution.
| Picture/Display | |
|---|---|
| Diagonal screen size (metric) | 138.7 cm |
| Diagonal screen size (inch) | 54.6 inch |
| Panel resolution | 1920 x 1080p |
| Optimum resolution | 1920 x 1080 @ 60 Hz |
| Brightness | 700 cd/m² |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 ms |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 degree |
| Viewing angle (vertical) | 178 degree |
| Pixel pitch | 0.63 x 0.63 mm |
| Display colours | 1.07 B |
| Contrast ratio (typical) | 1200:1 |
| Haze | 28% |
| Supported Display Resolution | |
| Computer formats | |
| 640 x 480, 60, 67, 72, 75 Hz | |
| 800 x 600, 56, 60, 72, 75 Hz | |
| 1024 x 768, 60 Hz | |
| 1280 x 768, 60 Hz | |
| 1280 x 800, 60 Hz | |
| 1280 x 1024, 60 Hz | |
| 1360 x 768, 60 Hz | |
| 1366 x 768, 60 Hz | |
| 1440 x 900, 60 Hz | |
| 1600 x 1200, 60 Hz | |
| 1920 x 1080, 60 Hz | |
| 1920 x 1200, 60 Hz | |
| 3840 x 2160, 30Hz | |
| Video formats | |
| 480i, 60 Hz | |
| 480p, 60 Hz | |
| 576p, 50 Hz | |
| 576i, 50 Hz | |
| 720p, 50, 60 Hz | |
| 1080i, 50, 60 Hz | |
| 1080p, 50, 60 Hz | |
| 3840 x 2160, 30Hz | |
| Connectivity | |
| Video input | |
| Composite (Share component Y) | |
| Component BNC (x 3) | |
| Display Port1.2 (x 1) | |
| DVI-D (x 1) | |
| HDMI 1.4 (x 2) | |
| VGA (Analogue D-Sub) (x 1) | |
| USB 2.0 (x 1) | |
| Audio input | |
| 3.5 mm mini jack (x 1) | |
| Audio Left/Right (RCA) x 1 | |
| Video output | |
| DVI-I (x 1) | |
| DisplayPort 1.2 (x 1) | |
| Audio output | |
| External speaker connector | |
| 3.5 mm Mini Jack (x 1) | |
| External control | |
| RS232C (in/out) 2.5 mm jack | |
| IR (in/out) 3.5 mm jack | |
| RJ45 x 2 | |
| Other connections | |
| OPS | |
| Thermal sensor | |
| Convenience | |
| Placement | |
| Landscape (24/7) | |
| Portrait (24/7) | |
| Tiled Matrix Up to 10 x 10 | |
| Screen-saving functions | |
| Pixel Shift, Low Bright | |
| Signal loop through | |
| DisplayPort, RS232, DVI Loop through, IR Loop through | |
| Ease of installation | |
| Carrying Handles | |
| Smart Insert | |
| Energy-saving functions | |
| Smart Power | |
| Network controllable | |
| RS232, RJ45, RJ45 hub available | |
| Operating conditions | |
| Temperature range (operation) | 0 ~ 40 °C |
| Temperature range (storage) | -20 ~ 60 °C |
| Altitude | 0 ~ 3000 m |
| MTBF | 50,000 hour(s) |
| Humidity range (operation)[RH] | 20 - 80% (without condensation) |
| Humidity range (storage) [RH] | 5 - 90% (without condensation) |
| Power | |
| Standby power consumption | <0.5 W |
| Consumption (Max) | 360 W |
| Consumption (Typical) | 165 W |
| Sound | |
| Built-in speakers | 2 x 10 W (RMS) |
| Accessories | |
| Stand | BM05462/BM05922 (Optional) |
| Included Accessories | |
| AC Switch Cover | |
| Gap pad x 3 | |
| Kit-1 (x1) | |
| Kit-2 (x2) | |
| Power cable (3 m) | |
| Quick start guide (x 1) | |
| Remote control and AAA batteries | |
| RS232 Cable (3 m) | |
| RS232 daisy-chain cable | |
| Wire Clamper (x 3) | |
| HDMI cable (1.8 m) (x 1) | |
| Miscellaneous | |
| On-Screen Display Languages | |
| Arabic, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese | |
| Regulatory approvals | |
| FCC, Class A, RoHS, CB, BSMI, PSB, CE, CU, ETL, CCC, CECP | |
| Warranty | |
| 3 year warranty | |
| Multimedia Applications | |
| USB Playback Video | |
| ISM, M2TS, M4V, Manifest, MK3D, MKV, MP4, MPEG, MPG, MPD, MT2, MTS, TS, VOB | |
| USB Playback Audio | |
| AAC, AIF, AIFF, ASF, M3U, M4A, MP3, MP4, PLS, WAV, WMA | |
| USB Playback Picture | |
| BMP, GIF, JPEG, JPG, PNG | |
| Dimensions | |
| Set Width | 1211.4 mm |
| Set Height | 682.2 mm |
| Set Depth | 97.3 (D@Handle)/98.4 (D@Wall mount) mm |
| Set Width (inch) | 47.69 inch |
| Set Height (inch) | 26.86 inch |
| Set Depth (inch) | 3.83 (D@Handle)/3.87 (D@Wall mount) inch |
| Bezel width | 0.9 mm |
| Wall Mount | 400 mm x 400 mm, M6 |
| Product weight | 24.9 kg |
