Chasing innovation
powered by Android
Amaze your guests with a smarter, faster, signage display. With integrated WiFi and designed for running Android apps, it's the next evolution in signage solutions
Save and play content with internal memory
Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring that your media stays up even if the network goes down.
Keep your content up and running with FailOver
Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides content protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and your ready for instant protection.
SmartPower for energy saving
The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.
CMND: Take control of your displays
A robust display management platform, CMND puts the power back into your hands. Update and manage content with CMND & Create or control your settings with CMND & Control. It's all possible with CMND.
Create and update content with CMND & Create
Design and create compelling content with CMND & Create, a powerful authoring tool. With a drag and drop interface, preloaded templates, and integrated widgets, you'll be able to amaze your customers with compelling content. Available in portrait and landscape mode.
Manage settings of multiple displays with CMND & Control
With CMND & Control, easily manage multiple displays in a central location. With real time display monitoring, setting and software updates from a remote location, and the ability to customize and configure multiple displays at once, such as video wall or menu board displays, controlling your suite of displays has never been easier.
Android SoC processor. Native and web apps
Control your display via an Internet connection. Android-powered Philips Professional Displays are optimized for native Android apps, and you can install web apps directly to the display too. A new Android 8 ensures the software is kept secure and remain to the latest specification for longer.
Ensure your content is running with automatic screenshots
Content is king, and with the automatic screenshot feauture, you can make sure that your content is up and running at all times. Screenshots are taken throughout the day, which are then stored in the FTP server. From there, the screenshots can be viewed no matter when, or where you are.
ADS wide-view panel display
Be seen from any angle with ADS wide-view technology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy, and superior colour reproduction with 180 degree viewing.
Connect and control your content via the cloud
Connect and control your content via the cloud with the integrated HTML5 browser. Using the Chromium based browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlists.
-
Picture/Display |
|
Diagonal screen size (inch) |
54.6 inch |
Diagonal screen size (metric) |
138.7 cm |
Panel resolution |
3840 x 2160 |
Optimum resolution |
3840 x 2160 @ 60Hz |
Brightness |
500 cd/m² |
Contrast ratio (typical) |
5000:1 |
Aspect ratio |
16:9 |
Response time (typical) |
8 ms |
Pixel pitch |
0.315 × 0.315 mm |
Display colors |
1.07 Billion |
Viewing angle (horizontal) |
178 degrees |
Viewing angle (vertical) |
178 degrees |
Operating system |
Android 8.0 |
Dynamic contrast ratio |
500,000:1 |
Panel technology |
VA |
Picture enhancement |
3/2 - 2/2 motion pull down |
|
3D Combfilter |
|
3D MA deinterlacing |
|
Dynamic contrast enhancement |
|
Motion compens. deinterlacing |
|
Progressive scan |
Connectivity |
|
Video input |
Video output |
Display Port1.2 (x1) |
DisplayPort 1.2 (x1) |
DVI-I (x1) |
HDMI 2.0 (x1) |
HDMI 2.0 (x2) |
|
USB 2.0 (x2) |
Audio input |
|
3.5 mm jack |
|
Audio output |
|
3.5mm jack |
External control |
WiFi |
RJ45 |
Dual antenna 2.4GHz and 5GHz |
RS232C (in/out) 2.5 mm jack |
4G/LTE antenna connectors (mPCIe) |
IR (in/out) 3.5 mm jack |
|
|
Supported Display Resolution |
|
Computer formats |
|
1920 x 1080, 60Hz |
|
1680 x 1050, 60Hz |
|
1600 x 900, 60Hz |
|
1024 x 768, 60Hz |
|
1280 x 1024, 60Hz |
|
1280 x 720, 60Hz |
|
1440 x 900, 60 Hz |
|
3840 x 2160, 30, 60Hz |
|
640 x 480, 60Hz |
|
800 x 600, 60Hz |
|
Video formats |
|
1080i, 50, 60Hz |
|
576p, 50Hz |
|
576i, 50Hz |
|
480p, 60Hz |
|
480i, 60Hz |
|
1080p, 50, 60Hz |
|
2160p, 24, 30, 60Hz |
|
720p, 50, 60 Hz |
Dimensions |
|
Set Width |
1241.8 mm |
Set Height |
712.6 mm |
Set Depth |
63.6 mm |
Set Width (inch) |
48.89 inch |
Set Height (inch) |
28.20 inch |
Set Depth (inch) |
2.50 inch |
Bezel width |
13.9 mm (Even bezel) |
Product weight (lb) |
36.60 lb |
Product weight |
16.6 kg |
Wall Mount |
400 (H) x 400(V) mm, M6 |
Convenience |
|
Placement |
Landscape (24/7) |
|
Portrait (24/7) |
|
Tiled Matrix |
|
Up to 10 x 15 |
Keyboard control |
Hidden |
|
Lockable |
Signal loop through |
IR Loopthrough |
|
DisplayPort |
|
HDMI |
|
RS232 |
Network controllable |
RS232 |
Screen saving functions |
Pixel Shift, Low Bright |
Energy saving functions |
Smart Power |
WiFi protocol |
a b g n, 802.1x |
Power |
|
Standby power consumption |
0.5 W |
Mains power |
100 ~ 240 VAC, 50 ~ 60 Hz |
Consumption (Typical) |
178 W |
Consumption (Max) |
218 W |
Energy Label Class |
G |
Operating conditions |
|
Temperature range (operation) |
0 ~ 40 °C |
Temperature range (storage) |
-20 ~ 60 °C |
Altitude |
0 ~ 3000 m |
MTBF |
50,000 hour(s) |
Humidity range (operation)[RH] |
20 - 80% RH (No condensation) |
Humidity range (storage) [RH] |
5 - 95% RH (No condensation) |
Sound |
|
Built-in speakers |
2 x 10W RMS |
Accessories |
|
Included accessories |
Quick start guide |
|
RS232 cable |
|
AC Power Cord |
|
IR sensor cable (1.8M) |
|
Remote Control & AAA Batteries |
Included Accessories |
RS232 daisy-chain cable |
|
Philips logo (x1) |
|
AC Switch Cover |
|
USB Cover (x1) |
|
Screws |
|
Stand |
BM05922 (Optional) |
|
Multimedia Applications |
|
USB Playback Audio |
USB Playback Picture |
AAC |
BMP |
HEAAC |
JPEG |
MPEG |
PNG |
USB Playback Video |
|
H.263 |
MPEG |
H.264 |
H.264 |
H.265 |
H.265 |
Miscellaneous |
|
On-Screen Display Languages |
Regulatory approvals |
English |
CE |
French |
RoHS |
German |
BSMI |
Spanish |
CB |
Polish |
FCC, Class A |
Turkish |
PSB |
Russian |
VCCI |
Italian |
CCC |
Simplified Chinese |
CU |
Traditional Chinese |
EMF |
Arabic |
ETL |
Japanese |
Warranty |
Danish |
3 year warranty |
Dutch |
Internal Player |
Finnish |
CPU |
Norwegian |
2 x A53 + 2 x A73 |
Portuguese |
GPU |
Swedish |
ARM Mali G51 |
|
Memory |
|
3GB DDR |
|
Storage |
|
32 GB eMMc |
What's in the box? |
Other items in the box |
Quick start guide |
|
RS232 cable |
|
AC Power Cord |
|
IR sensor cable (1.8M) |
|
Remote Control & AAA Batteries |
