Philips 55BDL4550D/00

55" 4K D-Line Digital Signage Display

• Description
• Specifications
• Warranty

• Chasing innovation
  powered by Android
  Amaze your guests with a smarter, faster, signage display. With integrated WiFi and designed for running Android apps, it's the next evolution in signage solutions

  Save and play content with internal memory
  Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring that your media stays up even if the network goes down.

  Keep your content up and running with FailOver
  Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides content protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and your ready for instant protection.

  SmartPower for energy saving
  The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

  CMND: Take control of your displays
  A robust display management platform, CMND puts the power back into your hands. Update and manage content with CMND & Create or control your settings with CMND & Control. It's all possible with CMND.

  Create and update content with CMND & Create
  Design and create compelling content with CMND & Create, a powerful authoring tool. With a drag and drop interface, preloaded templates, and integrated widgets, you'll be able to amaze your customers with compelling content. Available in portrait and landscape mode.

  Manage settings of multiple displays with CMND & Control
  With CMND & Control, easily manage multiple displays in a central location. With real time display monitoring, setting and software updates from a remote location, and the ability to customize and configure multiple displays at once, such as video wall or menu board displays, controlling your suite of displays has never been easier.

  Android SoC processor. Native and web apps
  Control your display via an Internet connection. Android-powered Philips Professional Displays are optimized for native Android apps, and you can install web apps directly to the display too. A new Android 8 ensures the software is kept secure and remain to the latest specification for longer.

  Ensure your content is running with automatic screenshots
  Content is king, and with the automatic screenshot feauture, you can make sure that your content is up and running at all times. Screenshots are taken throughout the day, which are then stored in the FTP server. From there, the screenshots can be viewed no matter when, or where you are.

  ADS wide-view panel display
  Be seen from any angle with ADS wide-view technology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy, and superior colour reproduction with 180 degree viewing.

  Connect and control your content via the cloud
  Connect and control your content via the cloud with the integrated HTML5 browser. Using the Chromium based browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlists.


• Picture/Display
  Diagonal screen size (inch)	54.6 inch
  Diagonal screen size (metric)	138.7 cm
  Panel resolution	3840 x 2160
  Optimum resolution	3840 x 2160 @ 60Hz
  Brightness	500 cd/m²
  Contrast ratio (typical)	5000:1
  Aspect ratio	16:9
  Response time (typical)	8 ms
  Pixel pitch	0.315 × 0.315 mm
  Display colors	1.07 Billion
  Viewing angle (horizontal)	178 degrees
  Viewing angle (vertical)	178 degrees
  Operating system	Android 8.0
  Dynamic contrast ratio	500,000:1
  Panel technology	VA
  Picture enhancement	3/2 - 2/2 motion pull down
  	3D Combfilter
  	3D MA deinterlacing
  	Dynamic contrast enhancement
  	Motion compens. deinterlacing
  	Progressive scan
  Connectivity
  Video input	Video output
  Display Port1.2 (x1)	DisplayPort 1.2 (x1)
  DVI-I (x1)	HDMI 2.0 (x1)
  HDMI 2.0 (x2)
  USB 2.0 (x2)	Audio input
  	3.5 mm jack
  	Audio output
  	3.5mm jack
  External control	WiFi
  RJ45	Dual antenna 2.4GHz and 5GHz
  RS232C (in/out) 2.5 mm jack	4G/LTE antenna connectors (mPCIe)
  IR (in/out) 3.5 mm jack
  	Supported Display Resolution
  	Computer formats
  	1920 x 1080, 60Hz
  	1680 x 1050, 60Hz
  	1600 x 900, 60Hz
  	1024 x 768, 60Hz
  	1280 x 1024, 60Hz
  	1280 x 720, 60Hz
  	1440 x 900, 60 Hz
  	3840 x 2160, 30, 60Hz
  	640 x 480, 60Hz
  	800 x 600, 60Hz
  	Video formats
  	1080i, 50, 60Hz
  	576p, 50Hz
  	576i, 50Hz
  	480p, 60Hz
  	480i, 60Hz
  	1080p, 50, 60Hz
  	2160p, 24, 30, 60Hz
  	720p, 50, 60 Hz
  Dimensions
  Set Width	1241.8 mm
  Set Height	712.6 mm
  Set Depth	63.6 mm
  Set Width (inch)	48.89 inch
  Set Height (inch)	28.20 inch
  Set Depth (inch)	2.50 inch
  Bezel width	13.9 mm (Even bezel)
  Product weight (lb)	36.60 lb
  Product weight	16.6 kg
  Wall Mount	400 (H) x 400(V) mm, M6
  Convenience
  Placement	Landscape (24/7)
  	Portrait (24/7)
  	Tiled Matrix
  	Up to 10 x 15
  Keyboard control	Hidden
  	Lockable
  Signal loop through	IR Loopthrough
  	DisplayPort
  	HDMI
  	RS232
  Network controllable	RS232
  Screen saving functions	Pixel Shift, Low Bright
  Energy saving functions	Smart Power
  WiFi protocol	a b g n, 802.1x
  Power
  Standby power consumption	0.5 W
  Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
  Consumption (Typical)	178 W
  Consumption (Max)	218 W
  Energy Label Class	G
  Operating conditions
  Temperature range (operation)	0 ~ 40 °C
  Temperature range (storage)	-20 ~ 60 °C
  Altitude	0 ~ 3000 m
  MTBF	50,000 hour(s)
  Humidity range (operation)[RH]	20 - 80% RH (No condensation)
  Humidity range (storage) [RH]	5 - 95% RH (No condensation)
  Sound
  Built-in speakers	2 x 10W RMS
  Accessories
  Included accessories	Quick start guide
  	RS232 cable
  	AC Power Cord
  	IR sensor cable (1.8M)
  	Remote Control & AAA Batteries
  Included Accessories	RS232 daisy-chain cable
  	Philips logo (x1)
  	AC Switch Cover
  	USB Cover (x1)
  	Screws
  	Stand
  BM05922 (Optional)
  Multimedia Applications
  USB Playback Audio	USB Playback Picture
  AAC	BMP
  HEAAC	JPEG
  MPEG	PNG
  USB Playback Video
  H.263	MPEG
  H.264	H.264
  H.265	H.265
  Miscellaneous
  On-Screen Display Languages	Regulatory approvals
  English	CE
  French	RoHS
  German	BSMI
  Spanish	CB
  Polish	FCC, Class A
  Turkish	PSB
  Russian	VCCI
  Italian	CCC
  Simplified Chinese	CU
  Traditional Chinese	EMF
  Arabic	ETL
  Japanese	Warranty
  Danish	3 year warranty
  Dutch	Internal Player
  Finnish	CPU
  Norwegian	2 x A53 + 2 x A73
  Portuguese	GPU
  Swedish	ARM Mali G51
  	Memory
  	3GB DDR
  	Storage
  	32 GB eMMc
  What's in the box?	Other items in the box
  Quick start guide
  RS232 cable
  AC Power Cord
  IR sensor cable (1.8M)
  Remote Control & AAA Batteries
