Picture/Display |
|
Diagonal screen size (metric) |
163.8 cm |
Diagonal screen size (inch) |
64.5 inch |
Aspect ratio |
16:9 |
Panel resolution |
3840 x 2160 |
Pixel pitch |
0.372 x 0.372 mm |
Optimum resolution |
3840 x 2160 @60 Hz |
Brightness |
500 cd/m² |
Display colours |
1.07 Billion |
Contrast ratio (typical) |
1200:1 |
Dynamic contrast ratio |
500,000:1 |
Response time (typical) |
8 ms |
Viewing angle (horizontal) |
178 degree |
Viewing angle (vertical) |
178 degree |
Picture enhancement |
3/2 - 2/2 motion pull down, Dynamic contrast enhancement, Motion compens. deinterlacing, Progressive scan |
Panel technology |
ADS |
Operating system |
Android 11 |
Haze |
25% |
Connectivity |
|
Audio output |
3.5 mm jack |
Video input |
DVI-I (x 1), DisplayPort 1.4 (x 1), HDMI 2.0 (x 2), USB 3.0 (x 2), VGA (via DVI) |
Audio input |
3.5 mm jack |
Other connections |
4G/LTE antenna connectors, Micro USB (x 1) (OTG), USB 2.0 (x 1) |
Video output |
DisplayPort 1.4 (x 1) |
External control |
RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack |
Wi-Fi |
Wi-Fi 6 + Bluetooth 5.2 (slide-in module) |
Convenience |
|
Placement |
Landscape (24/7), Portrait (24/7) |
Tiled Matrix |
Up to 10 x 15 |
Screen-saving functions |
Pixel Shift |
Keyboard control |
Hidden, Lockable |
Signal loop through |
IR Loop through, DisplayPort, RS232 |
Energy-saving functions |
Smart Power |
Network controllable |
RS232, External 4G mPCIe slot, RJ45, Wi-Fi |
WiFi protocol |
a b g n, 802.11 ax, 802.11 ac |
Sound |
|
Built-in speakers |
2 x 10 W RMS |
Power |
|
Mains power |
100 ~ 240 VAC, 50 ~ 60 Hz |
Consumption (Typical) |
TBD W |
Consumption (Max) |
TBD |
Standby power consumption |
<0.5 W |
Energy Label Class |
G |
Supported Display Resolution |
|
Computer formats |
Various |
Video formats |
Various |
Dimensions |
|
Set Width |
1462.3 mm |
Product weight |
28.1 kg |
Set Height |
837.3 mm |
Set Depth |
89.9 (D@Handle)/ 68.9 (D@Wall mount) mm |
Set Width (inch) |
57.57 inch |
Set Height (inch) |
32.96 inch |
Wall Mount |
400 mm(H) x 400 mm(V), M8 |
Set Depth (inch) |
3.54 (D@Handle)/ 2.71 (D@Wall mount) inch |
Bezel width |
14.9 mm (Even bezel) |
Product weight (lb) |
61.95 lb |
Operating conditions |
|
Altitude |
0 ~ 3000 m |
Temperature range (operation) |
0 ~ 40 °C |
MTBF |
50,000 hour(s) |
Temperature range (storage) |
-20 ~ 60 °C |
Humidity range (operation)[RH] |
20–80% RH (No condensation) |
Humidity range (storage) [RH] |
5–95% RH (No condensation) |
Multimedia Applications |
|
USB Playback Video |
Various |
USB Playback Picture |
BMP, JPEG, PNG |
USB Playback Audio |
AAC, HEAAC, MPEG |
Internal Player |
|
CPU |
2 x A72 + 4 x A53 |
GPU |
ARM Mali-T860 MP4 |
Memory |
4 GB RAM |
Storage |
32 GB eMMc |
Miscellaneous |
|
On-Screen Display Languages |
English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish |
Warranty |
3 year warranty |
Regulatory approvals |
CB, CE, CCC, FCC Class A, RoHS, EMF, EnergyStar 8.0, UL |
