| Diagonal screen size (metric) |
189.3 cm |
| Diagonal screen size (inch) |
74.5 inch |
| Panel resolution |
3840 x 2160 |
| Optimum resolution |
3840 x 2160 @ 60 Hz |
| Brightness |
420 cd/m² |
| Contrast ratio (typical) |
1200:1 |
| Dynamic contrast ratio |
500,000:1 |
| Surface treatment |
Anti-Glare coating |
| Aspect ratio |
16:9 |
| Response time (typical) |
9 ms |
| Pixel pitch |
0.4296 x 0.4296 mm |
| Display colours |
1.07 billion |
| Viewing angle (horizontal) |
178 degrees |
| Viewing angle (vertical) |
178 degrees |
| Picture enhancement |
3/2 - 2/2 motion pull down |
| 3D Combfilter |
Motion compens. deinterlacing |
| Progressive scan |
3D MA deinterlacing |
| Dynamic contrast enhancement |
|
| Panel technology |
IPS |
| Operating system |
Android 9 |
| Interactivity |
|
| Multi-touch technology |
Advanced infrared touch |
| Touch points |
20 simultaneous touch points |
| Plug and play |
HID compliant |
| Protection glass |
Anti-Glare |
| Tempered safety glass |
|
| Connectivity |
|
| Video input |
Display Port1.2 (x 1), DVI-I (x 1), USB 2.0 (x 2), USB 3.0 (x 2), USB-C, HDMI 2.0 (x 4) |
| Audio input |
3.5 mm Jack (x 1) |
| Audio output |
3.5 mm Jack (x 2) |
| Other connections |
OPS, micro SD, External control (IR in/out 3.5 mm jack, RJ45, RS232C in/out 2.5 mm jack) |
| Video output |
DisplayPort 1.2 (x 1), DVI - D (x 1), USB 2.0 (x 2), HDMI 2.0 (x 2) |
| Supported Display Resolution |
|
| Computer formats |
See supported resolutions in the provided data |
| Video formats |
See supported resolutions in the provided data |
| Convenience |
|
| Placement |
Landscape (18/7), Portrait (12/7) |
| Signal loop through |
IR Loop through, DisplayPort, RS232 |
| Network controllable |
RS232, RJ45 |
| Picture performance |
Advanced color control, Screen-saving functions (Pixel Shift, Low Brightness) |
| Keyboard control |
Hidden, Lockable |
| Remote control signal |
Lockable |
| Energy-saving functions |
Smart Power |
| Other convenience |
Carrying handles, Ease of installation (Smart Insert) |
| Dimensions |
|
| Bezel width |
16.30 mm (even) |
| Set Width |
1715.50 mm |
| Set Height |
993.70 mm |
| Set Depth |
80.8 mm (D@wall mount) / 108.7 mm (D@speaker cover) |
| Set Width (inch) |
67.54 inch |
| Set Height (inch) |
39.12 inch |
| Set Depth (inch) |
3.18"(D@wall mount) /4.28" (D@speaker cover) |
| Wall Mount |
600(H)x400(V) mm, M8 |
| Product weight |
53.0 kg |
| Product weight (lb) |
116.85 lb |
| Smart Insert mount |
100 mm x 100 mm, 6 x M4L6 |
| Sound |
|
| Built-in speakers |
2 x 20 W RMS |
| Operating conditions |
|
| Temperature range (operation) |
0 ~ 40 °C |
| Relative humidity |
20–80% (Operational), 5–95% (Storage) |
| MTBF |
50,000 hour(s) |
| Altitude |
0 ~ 3000 m |
| Temperature range (storage) |
-20 ~ 60 °C |
| Power |
|
| Mains power |
100 ~ 240 VAC, 50/60 Hz |
| Standby power consumption |
<0.5 W |
| Consumption (Typical) |
190 W |
| Power Saving Features |
Smart Power |
| Consumption (Max) |
380 W |
| Energy Label Class |
G |
| Accessories |
|
| Included accessories |
AC Power Cord, RS232 cable, Remote Control, Batteries for remote control, Quick start guide, HDMI cable, IR sensor cable (1.8 M) |
| Other items in the box |
Cleaning cloth (x 1), DVI-D cable (1.8 m), M2 Screw (x 2), M3 screw (x 2), Philips logo (x 1), RS232 daisy-chain cable, Touch Pen (x 2), Touch USB (x 1), USB Cover (x 1) |
| Optional accessories |
Cast to dongle |
| Miscellaneous |
|
| On-Screen Display Languages |
Arabic, English, French, German, Italian, Japanese, Polish, Spanish, Turkish, Russian, Simplified Chinese, Traditional Chinese, Portuguese, Danish, Dutch, Finnish, Norwegian, Swedish |
| Regulatory approvals |
CE, BSMI, CB, EMF, ETL, FCC, Class A, PSB, RoHS, EAC |
| Warranty |
3 year warranty |
| Multimedia Applications |
|
| USB Playback Audio |
AAC, M4A, MP3, WMA |
| USB Playback Picture |
BMP, JPEG, JPG, PNG |
| USB Playback Video |
ASF, AVI, DAT, FLV, MKV, MP4, MPG, TS, VOB, MPEG, WEBM, WMV |
| Internal Player |
|
| CPU |
MTK5680 |
| Memory |
4 GB RAM |
| Storage |
32 GB eMMc |
| Wi-Fi |
AP(WC0SR2511-88112BU), STA(WCT5GM2511MT7668AU) |
| GPU |
DDR4 4 GB |
| What's in the box? |
Other items in the box: AC Power Cord, RS232 cable, Remote Control, Batteries for remote control, Quick start guide, HDMI cable, IR sensor cable (1.8 M), Optional accessories: Cast to dongle |
