Philips 86BDL3652T/00

86” 4K Android Interactive Touchscreen Display

• Description
• Specifications
• Warranty
• Downloads

• Interactive classroom display
  Featuring multi-touch technology
  Maximise engagement and inspire collaboration with an interactive Philips T-Line display. Featuring anti-glare toughened glass, these Android-powered displays are made to withstand heavy daily usage and feature up to 20 touchpoints

  Operate, monitor and maintain with CMND and Control
  Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

  OPS slot allows for PC embedding without cabling
  Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

  Android: Run your own app or choose your favourite app to run
  With Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day and with the auto-orientation feature, showing content in portrait or landscape is as simple as turning the display.

  Multi-touch technology capable of 20 touchpoints
  Create a memorable interactive experience with up to 20 touchpoints at the same time. Perfect for collaborative and competitive applications, this display connects your audience with any content - making it ideal for education, public venues, corporate, hospitality and retail settings. The touch panel is HID compliant, providing true plug-and-play operation.

  Whiteboard mode built in
  Inspire agile collaboration with whiteboard mode. Simply activate this feature to turn your display into a blank canvas that can be drawn on by multiple users by hand or with dedicated display markers. Everything on the screen can then be captured for easy printing or file sharing.

  Wireless screen sharing and advanced collaboration
  Display four feeds on the one screen. Wireless screen sharing allows you to connect multiple devices at the same time for quick content switching when you need it. Use your existing Wi-Fi network to instantly and securely connect devices or use our optional HDMI interact dongles to cast directly to the screen without needing to connect to your secured/protected network.

• Picture/Display	Details
  Diagonal screen size (metric)	217.4 cm
  Diagonal screen size (inch)	85.6 inch
  Panel resolution	3840 x 2160
  Optimum resolution	3840 x 2160 @ 60 Hz
  Brightness	420 cd/m²
  Dynamic contrast ratio	500,000:1
  Response time (typical)	8 ms
  Aspect ratio	16:9
  Viewing angle (horizontal)	178 degrees
  Viewing angle (vertical)	178 degrees
  Pixel pitch	0.4935 x 0.4935 mm
  Display colours	1.07 billion
  Picture enhancement	3/2 - 2/2 motion pull down
  3D Combfilter	Motion compens. deinterlacing
  Progressive scan	3D MA deinterlacing
  Dynamic contrast enhancement
  Surface treatment	Anti-Glare coating
  Panel technology	IPS
  Contrast ratio (typical)	1200:1
  Operating system	Android 9
  Supported Display Resolution
  Computer formats	See supported resolutions in the provided data
  Video formats	See supported resolutions in the provided data
  Connectivity
  Video input	Display Port1.2 (x 1), DVI-I (x 1), HDMI 2.0 (x 4), USB 2.0 (x 2), USB 3.0 (x 2), USB-C
  Audio input	3.5 mm Jack (x 1)
  Video output	DisplayPort 1.2 (x 1), DVI - D (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2)
  Audio output	3.5 mm Jack (x 2)
  External control	IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack
  Other connections	OPS, micro SD
  Convenience
  Placement	Portrait (12/7), Landscape (18/7)
  Screen-saving functions	Low Bright
  Signal loop through	DisplayPort, RS232, IR Loop through
  Ease of installation	Smart Insert
  Energy-saving functions	Smart Power
  Picture performance	Advanced colour control
  Network controllable	RS232, RJ45
  Keyboard control	Hidden, Lockable
  Remote control signal	Lockable
  Other convenience	Carrying handles
  Operating conditions
  Temperature range (operation)	0 ~ 40 °C
  Temperature range (storage)	-20 ~ 60 °C
  Relative humidity	20–80% (Operational), 5–95% (Storage)
  Altitude	0 ~ 3000 m
  MTBF	50,000 hour(s)
  Power
  Consumption (Typical)	390 W
  Consumption (Max)	650 W
  Standby power consumption	<0.5 W
  Mains power	100 - 240 V~, 50 - 60 Hz, 7.5 A
  Power Saving Features	Smart Power
  Energy Label Class	G
  Sound
  Built-in speakers	2 x 20 W RMS
  Accessories
  Optional accessories	Interact dongles
  Included Accessories	Cleaning cloth (x 1), DVI-D cable (1.8 m), M2 Screw (x 2), M3 screw (x 2), Philips logo (x 1), RS232 daisy-chain cable, Touch Pen (x 2), Touch USB (x 1), USB Cover (x 1), AC power cord, Batteries for remote control, HDMI cable, IR sensor cable (1.8 m) (x 1), Quick start guide (x 1), Remote control (x 1), RS232 cable
  Miscellaneous
  On-Screen Display Languages	Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese
  Regulatory approvals	CE, FCC, Class A, RoHS, CB, BSMI, EAC, EMF, PSB, ETL
  Warranty	5-year warranty
  Multimedia Applications
  USB Playback Video	ASF, AVI, DAT, FLV, MKV, MP4, MPEG, MPG, TS, VOB, WEBM, WMV
  USB Playback Picture	BMP, JPEG, JPG, PNG
  USB Playback Audio	AAC, M4A, MP3, WMA
  Interactivity
  Multi-touch technology	0-gap Infrared touch
  Touch points	20 simultaneous touch points
  Plug and play	HID compliant
  Protection glass	Anti-Glare
  Tempered safety glass
  Internal Player
  CPU	MTK5680
  GPU	DDR4 4 GB
  Memory	4 GB RAM
  Storage	32 GB eMMc
  Wi-Fi	AP(WC0SR2511-88112BU), STA(WCT5GM2511MT7668AU)
  Dimensions
  Smart Insert mount	100 mm x 100 mm, 6 x M4L6
  Set Width	1961.00 mm
  Set Height	1132.30 mm
  Set Depth	80.5 mm (D@wall mount) / 108.4 mm (D@speaker cover)
  Set Width (inch)	77.20 inch
  Set Height (inch)	44.58 inch
  Set Depth (inch)	3.17" (D@wall mount) / 4.27" (D@speaker cover)
  Bezel width	17.8 mm(even)
  Wall Mount	600(H)x400(V) mm, M8
  Product weight	74.3 kg
  Product weight (lb)	163.8 lb
  What's in the box?	Other items in the box: Optional accessories: Interact dongles
