| Picture/Display |
|
| Diagonal screen size (inch) |
64.5 |
| Diagonal screen size (metric) |
163.83 |
| Panel resolution |
3840 x 2160 |
| Optimum resolution |
3840 x 2160 @ 60 Hz |
| Brightness |
350 |
| Contrast ratio (typical) |
1300:1 |
| Dynamic contrast ratio |
500,000:1 |
| Aspect ratio |
16:9 |
| Response time (typical) |
9 |
| Pixel pitch |
0.372 (H) x 0.372 (V) mm |
| Display colours |
1.07 billion |
| Viewing angle (horizontal) |
178 |
| Viewing angle (vertical) |
178 |
| Picture enhancement |
3/2 - 2/2 motion pull down, Motion compens. deinterlacing, 3D MA deinterlacing, Dynamic contrast enhancement, Progressive scan |
| Operating system |
Android 9 |
| Connectivity |
|
| Video input |
HDMI 2.0 (x 4), Display Port1.2 (x 1), DVI-I (x 1), USB 2.0 (x 2), USB 3.0 (x 2), USB-C |
| Video output |
DisplayPort 1.2 (x 1), DVI - D (x 1), HDMI 2.0 (x 2) |
| Audio input |
3.5 mm jack |
| Audio output |
3.5 mm Jack (x 2) |
| Other connections |
OPS, micro SD |
| External control |
RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack |
| Supported Display Resolution |
|
| Computer formats |
1024 x 768, 1280 x 720, 1920 x 1080, 3840 x 2160, etc. |
| UHD Formats |
3840 x 2160 @ 24, 25, 30, 60 Hz, 50 Hz |
| Video formats |
1080i, 1080p, 480p, 4K x 2K, 720p |
| Dimensions |
|
| Set Width |
1485.1 mm |
| Set Height |
860.10 mm |
| Set Depth |
86.2 mm (D@wall mount), 97.4 mm (D@speaker cover) |
| Set Width (inch) |
58.47 inch |
| Set Height (inch) |
33.86 inch |
| Set Depth (inch) |
3.39 (D@wall mount), 3.83 (D@speaker cover) |
| Bezel width |
1.50 mm (even) |
| Product weight |
45.8 kg (100.97 lb) |
| Wall Mount |
400 (H) x 400 (V) mm, M8 |
| Smart Insert mount |
6M4L6, 100 mm pitch, Max. Size 150 mm x 300 mm |
| Convenience |
|
| Placement |
Landscape (18/7), Portrait (12/7) |
| Keyboard control |
Hidden, Lockable |
| Signal loop through |
RS232, IR Loop through |
| Network controllable |
RJ45, RS232 |
| Energy-saving functions |
Smart Power |
| Screen-saving functions |
Pixel Shift, Low Brightness |
| Ease of installation |
Smart Insert |
| DPMS power saving system |
Yes |
| Power |
|
| Standby power consumption |
<0.5 W |
| Mains power |
100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption (Typical) |
190 W |
| Consumption (Max) |
320 W |
| Operating Conditions |
|
| Temperature range (operation) |
0 ~ 40°C |
| Temperature range (storage) |
-20 ~ 60°C |
| Relative humidity |
2080% (operating), 595% (storage) |
| Altitude |
0 ~ 3000 m |
| MTBF |
50,000 hours |
| Sound |
|
| Built-in speakers |
2 x 20 W RMS |
| Accessories |
|
| Included Accessories |
Philips logo, Cleaning cloth, DVI-I Cable (1.8 m), HDMI Cable (3 m), IR sensor cable (1.8 m), Power cable (x 3), RS232 Daisy chain cable, Touch Pen (x 2), USB A to B cable (3 m), USB Cover (x 1), AAA batteries, Quick start guide, Remote control (x 1), RS232 cable (3 m) |
| Multimedia Applications |
|
| USB Playback Audio |
AAC, M4A, MP3, WMA |
| USB Playback Picture |
BMP, JPEG, JPG, PNG |
| USB Playback Video |
ASF, AVI, DAT, FLV, MKV, MP4, MPEG, MPG, TS, VOB, WEBM, WMV |
| Miscellaneous |
|
| On-Screen Display Languages |
English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish |
| Regulatory approvals |
CE, RoHS, VCCI, CB, CU, EMF, EPA, ETL, FCC Class A |
| Warranty |
3-year warranty |
| Internal Player |
|
| CPU |
MTK5680 |
| Storage |
32 GB eMMC |
| Wi-Fi |
AP(WC0SR2511-88112BU), STA(WCT5GM2511MT7668AU) |
| Micro SD Card |
Support to 1TB |
| RAM |
DDR4 4 GB |
| Multi-touch Interactivity |
|
| Touchpoints |
10 simultaneous touch points |
