Philips D-Line | 55BDL4511D/00 55" 4K Smart Digital Signage Display

Say more

Make it stand out with a fast Philips D-Line Professional 4K UHD display. Philips superb picture quality ensures true colours and intense contrast. You can effortlessly display content from multiple sources on a single screen.

Smart, fast, 24/7 display.

55"

UHD (3840 x 2160)

500 cd/m²
Operate, monitor and maintain with CMND and Control

Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures that content is always playing

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

SmartPower for energy saving

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

Schedule what you want, when you want with SmartPlayer

Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.

Optional OPS Slot

Open Pluggable Specification is an industry-standard slot into which you can add an OPS-compatible media player. This gives you the ability to upgrade or change your hardware whenever you need to. Turning your display into an all-in-one digital signage solution has become simplicity itself.

Technical Specifications	Details
Diagonal screen size (metric)	138.7 cm
Diagonal screen size (inch)	54.6 inch
Panel resolution	3840 x 2160
Optimum resolution	3840 x 2160 @ 60 Hz
Brightness	500 cd/m²
Dynamic contrast ratio	500,000:1
Response time (typical)	8 ms
Aspect ratio	16:9
Viewing angle (horizontal)	178 degree
Viewing angle (vertical)	178 degree
Pixel pitch	0.315 × 0.315 mm
Display colours	1.07 Billion
Panel technology	VA
Contrast ratio (typical)	5000:1
Haze	25%
Computer formats	640 x 480, 800 x 600, 1024 x 768, 1280 x 720, 1280 x 1024, 1440 x 900, 1600 x 900, 1680 x 1050, 1920 x 1080, 3840 x 2160 @ 30/60 Hz
Video formats	480i, 480p, 576p, 576i, 720p @ 50/60 Hz, 1080i @ 50/60 Hz, 1080p @ 50/60 Hz, 2160p @ 24/30/60 Hz
Video input	Display Port1.2 (x 1), DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2)
Audio input	3.5 mm jack
Video output	DisplayPort 1.2 (x 1), HDMI 2.0 (x 1)
Audio output	3.5 mm jack
External control	IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack, OPS
Placement	Landscape (24/7), Portrait (24/7)
Screen-saving functions	Pixel Shift, Low Bright
Signal loop through	DisplayPort, RS232, HDMI, IR Loop through
Energy-saving functions	Smart Power
Network controllable	RS232, RJ45
Keyboard control	Hidden
Lockable	Yes
Temperature range (operation)	0 ~ 40 °C
Temperature range (storage)	-20 ~ 60 °C
Altitude	0 ~ 3000 m
MTBF	50,000 hour(s)
Humidity range (operation)[RH]	20–80% RH (No condensation)
Humidity range (storage) [RH]	5–95% RH (No condensation)
Consumption (Typical)	135 W
Consumption (Max)	278 W
Standby power consumption	0.5 W
Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
Energy Label Class	G
Built-in speakers	2 x 10 W RMS
Accessories	Stand (BM05922-Optional), AC Switch Cover, Philips logo (x 1), RS232 daisy-chain cable, AC power cord, IR sensor cable (1.8 m) (x 1), Quick start guide (x 1), Remote control and AAA batteries, RS232 cable, USB Cover and screw x 1, Wire Clamper (x 3)
On-Screen Display Languages	Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese
Regulatory approvals	CE, FCC Class A, CCC, RoHS, CB, BSMI, EMF, VCCI, PSB, ETL, CECP, EAC
Warranty	3 year warranty
USB Playback Video	H.263, H.264, H.265, MPEG
USB Playback Picture	BMP, JPEG, PNG
USB Playback Audio	AAC, MPEG, HEAAC
Set Width	1241.8 mm / 48.89 inch
Set Height	712.6 mm / 28.06 inch
Set Depth	63.6 mm / 2.50 inch
Bezel width	13.9 mm
