Picture/Display |
|
Diagonal Screen Size |
163.9 cm (65 inch) |
Aspect Ratio |
16:9 |
Panel Resolution |
3840 x 2160 |
Pixel Pitch |
0.372 (H) x 0.372 (V) mm |
Optimum Resolution |
3840 x 2160 @ 60 Hz |
Brightness |
400 cd/m² |
Display Colors |
1.07 Billion |
Contrast Ratio (Typical) |
5000:1 |
Response Time (Typical) |
6.5 ms |
Viewing Angle |
178° (Horizontal & Vertical) |
Picture Enhancement |
3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement |
Panel Technology |
VA |
Operating System |
Android 13 |
OS UI Resolution |
1920 x 1080 @ 60 Hz |
Connectivity |
|
Audio Output |
3.5 mm Mini Jack (x1), SPDIF |
Video Input |
VGA (Analogue D-Sub) (x1), USB-C (up to 65 W), HDMI 2.0 (x3), USB 2.0 (x1), USB 3.0 (x4) |
Audio Input |
3.5 mm mini jack (x1) |
Other Connections |
OPS, USB-B (x2) |
External Control |
RS232C (in) D-Sub9, RJ45 x 2, Bluetooth BT5.2 |
Convenience |
|
Placement |
Landscape (16/7) |
Screen-Saving Functions |
Pixel Shift, Low Brightness |
Keyboard Control |
Lockable |
Remote Control Signal |
Lockable |
Other Convenience |
Carrying handles, Network controllable (RS232, RJ45) |
Sound |
2 x 16 W built-in speakers |
Power |
100 ~ 240 VAC, 50/60 Hz, Consumption (Typical): 140 W, Standby Power Consumption: <0.5 W, Power Saving Features: Smart Power, Energy Label Class: F |
Supported Display Resolution |
480i, 60 Hz, 480p, 60 Hz, 720p, 50/60 Hz, 1080i, 50/60 Hz, 1080p, 50/60 Hz, 2160p, 30/60 Hz |
Dimensions |
Set Width: 1488.4 mm (58.6 inch), Set Height: 896.6 mm (35.28 inch), Set Depth: 86.2 mm (3.40 inch), Wall Mount: 600 x 400 mm, M8 |
Weight |
Product with packaging: 47 kg (103.62 lb), Product without stand: 35.45 kg (78.15 lb) |
Operating Conditions |
Altitude: 0 ~ 5000 m, Temperature range (operation): 0 ~ 40 °C, MTBF: 50,000 hour(s), Temperature range (storage): -20~60 °C, Humidity range (operation): 10–90% (without condensation), Humidity range (storage): 10–90% (without condensation) |
Multimedia Applications |
USB Playback: Video (H.263, H.264, H.265, MPEG1/2, MPEG4, VP8), Picture (BMP, JPEG, PNG), Audio (AAC, MPEG, HEAAC) |
Internal Player |
CPU: Quad-Core Cortex A55, GPU: Multi-Core Mali-G52, Memory: 4 GB RAM, Storage: 32 GB eMMc, Wi-Fi: 2.4/5 GHz |
Accessories |
Power code (US, UK, EU), HDMI cable, USB-A to B, Remote control and AAA batteries, 2 pcs stylus, Quick start guide, Wall mount |
Miscellaneous |
On-Screen Display Languages: [Multiple languages listed], Warranty: 5-year warranty, Regulatory approvals: CE, FCC, Class A, RoHS, CB, EAC, EMF, ETL, Energy Star 8.0 |
Interactivity |
Multi-touch technology: 0-gap Infrared touch, Touchpoints: 50 simultaneous touch points (depending on application), Plug and play: HID compliant, Protection glass: Anti-Glare, Tempered safety glass 7 MOHS |
