Picture/Display |
LED HD TV, D-LED |
Diagonal screen size (metric) |
80 |
Diagonal screen size (inch) |
32 |
Panel resolution |
1366 x 768p |
Brightness |
250 |
Viewing angle |
178º (H)/178º (V) |
Audio |
|
Sound output Power |
16 (2x8) |
Speakers |
2.0, Down Firing |
Sound Features |
AVL, Dynamic Bass, Incredible surround, Dolby MS10 |
Design |
|
Colour |
Black |
Tuner/Reception/Transmission |
|
Digital TV |
DVB-T/T2/C |
HEVC FHD (up to 1080p60) |
|
Analogue TV |
PAL, SECAM |
Video Playback |
NTSC, PAL, SECAM |
Rear Connectivity |
|
Antenna |
IEC-75 |
HDMI1 |
ARC, HDMI 1.4 |
HDMI 2 |
HDMI 1.4 |
Digital Audio out |
Optical |
DVI audio in |
Mini-Jack |
VGA input |
15 pin D-sub |
Scart |
CVBS, RGB |
Side Connectivity |
|
Common Interface Slot |
CI+ 1.3.2 |
Headphone out |
Mini-Jack |
USB1 |
USB 2.0 |
Connectivity Enhancements |
|
HDMI |
ARC (HDMI1) |
EasyLink (HDMI CEC) |
One-touch play, System Standby, RC pass-through, system audio control, Scart Power on scart |
Features |
|
Digital services |
8d EPG, Now and Next, MHEG, Teletext, Subtitles |
Ease of use |
Picture Style, Sound Style, Picture Format, Independent volume control, Local control (Joystick) |
Hospitality Features |
Hotel mode (Joystick Control Lock, Menu lock, Installation Menu Lock, Volume limitation, Prison mode (high-security mode), TXT/MHEG/USB/EPG/Subtitle Lock) |
CMND&Control |
Remote Management over RF, TV Group management, Off-Line Settings Editor, Off-Line Channel Editor, Your brand (Welcome Logo, Customizable Home Screen), Revenue generation (MyChoice), Cloning and Firmware update (Instant Initial Cloning, Via USB/RF) |
Timer |
Sleep Timer, Wake Up Alarm, Wake Up On Channel, Wake Up Sounds |
Clock |
Glow-in-the-Dark RC button, On-screen Clock |
Channels |
Combined List, Off-Line Channel Editor, Control (Block Automatic Channel Update) |
Power control |
Green/fast start-up, Switch On control (Channel) |
Feature |
Picture Style, Picture Format, Sound Style, Volume, Menu language, Remote Control (Cable Strap Ready, Low-Battery Detection, RC Battery Door Lock, Glow-in-the-Dark Clock button, Anti-Theft (Battery Anti-theft Protection, Kensington Lock) |
Languages |
Guest language control |
Healthcare features |
Control (Multi-Remote Control, Healthcare RC compatible) |
Convenience |
Headphone out, Independent main speaker mute, Headphone Detection |
Safety |
Double isolation class II, Flame retardant |
Multimedia |
|
Multimedia connections |
USB |
Video playback supported |
Formats: H.264/MPEG4 AVC, MPEG1, MPEG2, MPEG4, WMV9/VC1, MP4, MPG, TS, WMV, HEVC. Containers: AVI, MKV |
Subtitle formats supported |
SRT, SMI, SSA, SUB, TXT |
Music formats supported |
MP3, AAC, WAV, WMA (v2 up to v9.2) |
Picture formats supported |
BMP, JPG, PNG, GIF |
Supp. Video Resolution on USB |
Up to 1920x1080p@60Hz |
Accessories |
|
Included |
Edge Stand, 2 x AAA batteries, Power Cord, Warranty Leaflet, Legal and Safety brochure, Remote Control 22AV1903A/12 |
Optional |
Easy RC 22AV1601B/12, Healthcare RC 22AV1604B/12, Setup RC 22AV9574A/12 |
Power |
|
Mains power |
AC 220-240 V; 50-60 Hz |
Energy Label Class |
E |
EPREL registration number |
345104 |
EU Energy Label power |
28 |
Standby power consumption |
<0.3 W |
Power Saving Features |
Eco mode, Auto switch-off timer |
Ambient temperature |
0 °C to 40 °C |
Dimensions |
|
Set Width |
732 |
Set Height |
432 |
Set Depth |
77 |
Set width (with stand) |
732 |
Set height (with stand) |
455 |
Set depth (with stand) |
166 |
Product weight |
4.6 |
Product weight (+stand) |
4.7 |
Wall-mount compatible |
100 x 100 mm, M6 |
