Picture/Display |
|
Diagonal screen size (inch) |
55 inch |
Diagonal screen size (metric) |
139 cm |
Display |
4K Ultra HD LED |
Panel resolution |
3840 x 2160p |
Brightness |
350 cd/m² |
Contrast ratio (typical) |
1200:1 |
Supported Display Resolution |
|
HDMI |
Up to 3840 x 2160p@60 Hz |
Tuner |
Others: up to 1920 x 1080p@60 Hz |
T2 HEVC |
Up to 3840 x 2160@60 Hz |
USB, LAN |
HEVC: up to 3840 x 2160@60 Hz |
Others |
Up to 1920 x 1080p@60 Hz |
Tuner/Reception/Transmission |
|
Digital TV |
DVB-T/T2/C, HEVC UHD (up to 2160p60) |
Analogue TV |
PAL |
IP Playback |
Multicast, Unicast, HLS |
OTT App Channels |
Android TV |
OS |
Android TV™ 9 (Pie) |
Pre-installed apps |
Netflix, YouTube, Google Play Store, Google Play Movies, Google Play Games, YouTube Music |
Memory size (Flash) |
16 GB* |
Hospitality Features |
|
Hotel mode |
Switch-ON Settings Control, Volume limitation |
Installation Menu Lock |
Menu lock, Joystick Control Lock |
Prison mode |
Power control, Quick Start Mode, Auto Power ON/OFF |
Your brand |
Customisable Home Screen, Customisable Welcome App, Location Name (Geonames ID) |
CMND&Create |
Custom Dashboard (HTML&APK) |
CMND&Control |
Off-Line Channel Editor, Off-Line Settings Editor |
Remote Management over IP/RF |
TV Group management, Local Updates via USB, Instant Initial Cloning |
Control |
AppControl, JEDI Native Android TV Control, JSON API for TV Control-JAPIT |
Serial Xpress Protocol |
Crestron Connected, Joystick |
Interactive DRM |
VSecure, Playready Smoothstreaming |
Revenue generation |
MyChoice |
Remote Control |
Low-Battery Detection, RC Battery Door Lock, Glow-in-the-Dark Clock button |
CMND&Check-In |
Guest Name, Guest Language, Messages, Bill on TV, Express Checkout |
Sharing |
Chromecast Ultra built in, Secure Sharing, Network-managed Sharing |
Convenience |
Google Assistant, Google Account Login, Weather Forecast, >40 Supported Menu Languages, Clock in OFF mode, Theme TV, Wake Up Alarm, Sleep Timer |
Healthcare features |
|
Control |
Multi-Remote Control, Nurse call system compatible |
Convenience |
TalkBack, Independent main speaker mute |
Safety |
Double isolation class II, Flame retardant |
Multimedia |
|
Video playback supported |
Formats: H.264/MPEG4 AVC, MPEG1, MPEG2, MPEG4, WMV9/VC1, HEVC, Containers: AVI, MKV, VP9 |
Music formats supported |
MP3, AAC, WAV, WMA (v2 up to v9.2), WMA-PRO (v9 and v10) |
Subtitle formats supported |
SRT, SMI, TXT |
Picture formats supported |
JPG, PNG, BMP, GIF |
Audio |
|
Sound output Power |
20 W (2x10 W) |
Bathroom speaker out |
1.5 W Mono 8 ohm |
Speakers |
2.0, Down Firing |
Sound Features |
DTS-HD, Dolby Atmos Compatible, Dolby MS12D, AC-4, DTS Studio Sound |
Power |
|
Mains power |
AC 220-240 V; 50-60 Hz |
Ambient temperature |
0 °C to 40 °C |
Standby power consumption |
<0.3 W |
Energy Label Class |
F |
EU Energy Label power |
75 W |
Power Saving Features |
Eco mode, Auto switch-off timer, Light sensor |
EPREL registration number |
936014 |
Accessories |
|
Included |
Remote Control 22AV2005B/00, 2 x AAA batteries, Power Cord, Warranty Leaflet, Legal and Safety brochure, Edge Stand |
Optional |
Voice RC 22AV2025B/00, Easy RC 22AV1601B/12, Healthcare RC 22AV1604B/12, External Clock 22AV1860A/12, DOCSIS Cable Modem 22AV1970A, Setup RC 22AV9574A/12 |
Wireless Connectivity |
|
Wireless LAN |
802.11 ac, Wi-Fi-Direct |
Connectivity Bottom |
|
Antenna |
IEC-75 |
HDMI 2 |
HDMI 2.0 with HDCP 2.2 |
Ethernet (LAN) |
RJ-45 |
HDMI 3 |
HDMI 2.0 with HDCP 2.2 |
USB 2 |
USB 2.0 |
External Control |
RJ-48 |
Bathroom speaker out |
Mini-Jack |
External power |
12 V, max 1.5 A |
Side Connectivity |
|
Common Interface Slot |
CI+ 1.3.2 |
HDMI1 |
HDMI 2.0 with HDCP 2.2 |
Headphone out |
Mini-Jack |
USB1 |
USB 3.0 |
Connectivity Enhancements |
|
RJ48 |
IR-In/Out |
Serial Xpress interface |
EasyLink (HDMI CEC) |
HDMI |
ARC (all ports), Auto Input Selection |
Design |
|
Colour |
Black |
Dimensions |
|
Set Width |
1228 mm |
Set Height |
712 mm |
Set Depth |
78/85 mm |
Product weight |
13.1 kg |
Set width (with stand) |
1228 mm |
Set height (with stand) |
743 mm |
Set depth (with stand) |
245 mm |
Product weight (+stand) |
13.3 kg |
Wall-mount compatible |
M6, 100 x 200 mm |
