| Picture/Display |
D-LED, LED HD TV |
| Diagonal screen size (metric) |
80 |
| Diagonal screen size (inch) |
32 |
| Panel resolution |
1366 x 768p |
| Brightness |
250 |
| Viewing angle |
178º (H)/178º (V) |
| Audio |
|
| Sound output Power |
16 (2x8) |
| Speakers |
2.0, Down Firing |
| Bathroom speaker out |
1.5 W Mono 8 ohm |
| Sound Features |
DTS-HD, Dolby Atmos Compatible, Dolby MS12D, AVL, Incredible surround |
| Design |
|
| Colour |
Black |
| Tuner/Reception/Transmission |
|
| Digital TV |
DVB-T/T2/C |
| HEVC FHD (up to 1080p60) |
|
| Analogue TV |
PAL |
| IP Playback |
Multicast, Unicast |
| Rear Connectivity |
|
| Digital Audio out |
Optical |
| Ethernet (LAN) |
RJ-45 |
| Antenna |
IEC-75 |
| External Control |
RJ-48 |
| HDMI 2 |
HDMI 1.4 |
| USB 2 |
USB 2.0 |
| Bathroom speaker out |
Mini-Jack |
| Side Connectivity |
|
| Common Interface Slot |
CI+ 1.3.2 |
| USB1 |
USB 2.0 |
| HDMI1 |
HDMI 1.4 |
| Headphone out |
Mini-Jack |
| Connectivity Enhancements |
|
| HDMI |
MHL 2.0 (HDMI1), ARC (HDMI2) |
| EasyLink (HDMI CEC) |
One-touch play, System Standby, RC pass-through, system audio control |
| LAN |
Wake up on LAN |
| RJ48 |
IR-In/Out, Serial Xpress interface |
| Features |
|
| Digital services |
8d EPG, Now and Next, MHEG, Teletext, HbbTV, Subtitles |
| Ease of use |
Picture Style, Sound Style, Local control (Joystick) |
| Hospitality Features |
Apps (YouTube), Your brand (Customizable Home Screen, Location Name (Geonames ID), CMND&Create, Customizable Dashboard (HTML), Welcome Logo), CMND&Control (Off-Line Channel Editor, Off-Line Settings Editor, Remote Management over IP/RF, TV Group management, CMND&Check-In (Guest Name, Guest Language) |
| Languages |
Guest language control |
| Clock |
On-screen Clock, Optional External Clock |
| Timer |
Sleep Timer, Wake Up Alarm, Wake Up On Channel, Wake Up Sounds |
| Remote Control |
Low-Battery Detection, RC Battery Door Lock, Glow-in-the-Dark Clock button |
| Control |
JSON API for TV Control-JAPIT, Serial Xpress Protocol |
| Cloning and Firmware update |
Instant Initial Cloning, Via USB/RF/IP |
| Interactive DRM |
VSecure, Playready Smoothstreaming |
| Power control |
Quick Start Mode, Auto Power ON, WoLAN |
| Switch On control |
Channel |
| Feature |
Picture Format, Volume, Picture Style, Revenue generation (MyChoice) |
| Hotel mode |
Joystick Control Lock, Menu lock, Installation Menu Lock, Volume limitation, Prison mode (high-security mode), TXT/MHEG/USB/EPG/Subtitle Lock |
| Healthcare features |
Control (Multi-Remote Control, Healthcare RC compatible, Nurse call system compatible) |
| Convenience |
Headphone out, Independent main speaker mute, Headphone Detection |
| Safety |
Double isolation class II, Flame retardant |
| Multimedia |
|
| Video playback supported |
Formats: H.264/MPEG4 AVC, MPEG1, MPEG2, MPEG4, WMV9/VC1, HEVC. Containers: AVI, MKV, VP9 |
| Subtitle formats supported |
SRT, SMI, TXT |
| Music formats supported |
MP3, AAC, WAV, WMA (v2 up to v9.2), WMA-PRO (v9 and v10) |
| Picture formats supported |
JPG, PNG, BMP, GIF |
| Supp. Video Resolution on USB |
Up to 1920x1080p@60Hz |
| Accessories |
|
| Included |
Edge Stand, Remote Control 22AV1904A/12, 2 x AAA batteries, Power Cord, Warranty Leaflet, Legal and Safety brochure |
| Optional |
Easy RC 22AV1601B/12, Healthcare RC 22AV1604B/12, External Clock 22AV1860A/12, DOCSIS Cable Modem 22AV1970A, Setup RC 22AV9574A/12 |
| Power |
|
| Mains power |
AC 220-240 V; 50-60 Hz |
| Energy Label Class |
F |
| EPREL registration number |
345147 |
| EU Energy Label power |
28 |
| Standby power consumption |
<0.3 W |
| Power Saving Features |
Eco mode |
| Ambient temperature |
0 °C to 40 °C |
| Dimensions |
|
| Set Width |
732 |
| Set Height |
432 |
| Set Depth |
77 |
| Set width (with stand) |
732 |
| Set height (with stand) |
494 |
| Set depth (with stand) |
179 |
| Product weight |
4.5 |
| Product weight (+stand) |
4.6 |
| Wall-mount compatible |
100 x 100 mm, M6 |
