Picture/Display |
|
Diagonal Screen Size |
108 cm (42.5 inch) |
Aspect Ratio |
16:9 |
Panel Resolution |
3840 x 2160 |
Pixel Pitch |
0.2451 x 0.2451 mm |
Optimum Resolution |
3840 x 2160 @ 60 Hz |
Brightness |
400 cd/m² |
Display Colours |
1.07 Billion |
Contrast Ratio (Typical) |
1200:1 |
Dynamic Contrast Ratio |
500,000:1 |
Response Time (Typical) |
8 ms |
Viewing Angle (Horizontal) |
178° |
Viewing Angle (Vertical) |
178° |
Panel Technology |
IPS |
Clinical Image |
D-Image preset (dicom part 14 compatible) |
Haze |
1% |
Connectivity |
|
Audio Output |
3.5 mm jack |
Video Input |
DVI-I (x 1), HDMI 2.0 (x 2), USB 2.0 (x 2) |
Audio Input |
3.5 mm jack |
External Control |
IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack |
Convenience |
|
Placement |
Landscape (18/7), Portrait (18/7), Tiled Matrix (up to 10 x 15) |
Keyboard Control |
Hidden, Lockable |
Remote Control Signal |
Lockable |
Signal Loop Through |
RS232, IR Loop through |
Energy-saving Functions |
Smart Power |
Network Controllable |
RS232, RJ45 |
Start-up |
Switch on delay, Switch on status, Boot on source, Start-up window enable/disable |
Sound |
|
Built-in Speakers |
2 x 10 W RMS |
Power |
|
Mains Power |
100–240 V~, 50/60 Hz |
Consumption (Typical) |
105 W |
Consumption (Max) |
155 W |
Standby Power Consumption |
<0.5 W |
Power Saving Features |
Smart Power |
Energy Label Class |
G |
Supported Display Resolutions |
|
Computer Formats |
640x480, 720x400, 800x600, 1024x768, 1280x1024, 1920x1080, 3840x2160, etc. |
Video Formats |
480i, 480p, 576p, 576i, 720p, 1080i, 1080p, 3840x2160, etc. |
Dimensions |
|
Set Width |
973.0 mm (38.31 inch) |
Set Height |
561.2 mm (22.09 inch) |
Set Depth |
63.5 mm (2.50 inch) |
Bezel Width |
13.9 mm (Even bezel) |
Product Weight |
10.7 kg (23.59 lb) |
Operating Conditions |
|
Altitude |
0 ~ 3000 m |
Temperature Range (Operation) |
0 ~ 40 °C |
Temperature Range (Storage) |
-20 ~ 60 °C |
Humidity Range (Operation) |
20~80% RH (No condensation) |
Humidity Range (Storage) |
5~95% RH (No condensation) |
Multimedia Applications |
|
USB Playback Video |
H.264, JPEG, MPEG, WMV3 |
USB Playback Picture |
BMP, JPEG, PNG |
USB Playback Audio |
AAC, WMA, MPEG, HEAAC |
Accessories |
|
Included Accessories |
IR sensor cable (1.8 m), Philips logo, AC power cord, Remote control, etc. |
Miscellaneous |
|
On-Screen Display Languages |
Arabic, English, French, German, Italian, Japanese, Polish, Russian, etc. |
Warranty |
3 year warranty |
Regulatory Approvals |
CE, FCC, Class A, CB, BSMI, VCCI, CU, ETL, EMF, PSB |
