Picture/Display |
|
Diagonal screen size (metric) |
163.9 cm |
Diagonal screen size (inch) |
64.5 inch |
Aspect ratio |
16:9 |
Panel resolution |
3840 x 2160 |
Pixel pitch |
0.372 x 0.372 mm |
Optimum resolution |
3840 x 2160 @ 60 Hz |
Brightness |
400 cd/m² |
Display colours |
1.07 Billion |
Contrast ratio (typical) |
1200:1 |
Dynamic contrast ratio |
500,000:1 |
Response time (typical) |
8 ms |
Viewing angle (horizontal) |
178° |
Viewing angle (vertical) |
178° |
Panel technology |
IPS |
Clinical image |
D-Image preset (DICOM Part 14 compatible) |
Haze |
1% |
Connectivity |
|
Audio output |
3.5 mm jack |
Video input |
DVI-I (x 1), HDMI 2.0 (x 3), USB 2.0 (x 2) |
Audio input |
3.5 mm jack |
External control |
IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack |
Convenience |
|
Placement |
Landscape (18/7), Portrait (18/7) |
Tiled Matrix |
Up to 10 x 15 |
Keyboard control |
Hidden, Lockable |
Remote control signal |
Lockable |
Signal loop through |
RS232, IR Loop through |
Ease of installation |
Smart Insert |
Energy-saving functions |
Smart Power |
Network controllable |
RS232, RJ45 |
Start-up |
Switch on delay, Switch on status, Boot on source, Enable/disable Philips logo |
Sound |
|
Built-in speakers |
2 x 10 W RMS |
Power |
|
Mains power |
100–240 V~, 50/60 Hz |
Consumption (Typical) |
165 W |
Consumption (Max) |
220 W |
Standby power consumption |
<0.5 W |
Power Saving Features |
Smart Power |
Energy Label Class |
G |
Supported Display Resolution |
|
Computer formats |
640 x 480, 720 x 400, 800 x 600, 1024 x 768, 1280 x 720, 1280 x 800, 1280 x 1024, 1440 x 900, 1600 x 1200, 1920 x 1080, 3840 x 2160 |
Video formats |
480i, 480p, 576p, 576i, 720p, 1080i, 1080p, 3840 x 2160 |
Dimensions |
|
Set Width |
1462.3 mm |
Set Height |
837.3 mm |
Set Depth |
68.9 mm (wall mount), 89.9 mm (handle) |
Set Width (inch) |
57.57 inches |
Set Height (inch) |
32.96 inches |
Set Depth (inch) |
2.71 (wall mount), 3.54 (handle) |
Bezel width |
14.9 mm (Even bezel) |
Product weight |
27.80 kg |
Product weight (lb) |
61.29 lbs |
Operating conditions |
|
Altitude |
0 ~ 3000 m |
Temperature range (operation) |
0 ~ 40 °C |
MTBF |
50,000 hours |
Temperature range (storage) |
-20 ~ 60 °C |
Humidity range (operation) [RH] |
20~80% RH (No condensation) |
Humidity range (storage) [RH] |
5~95% RH (No condensation) |
Multimedia Applications |
|
USB Playback Video |
H.264, JPEG, MPEG, WMV3 |
USB Playback Picture |
BMP, JPEG, PNG |
USB Playback Audio |
AAC, WMA, MPEG, HEAAC |
Accessories |
|
Included Accessories |
IR sensor cable (1.8 m), Philips logo, AC power cord, RS232 daisy chain cable, USB Cover, Wire Clamper (x 3), Quick start guide, Remote control & AAA batteries |
Miscellaneous |
|
On-Screen Display Languages |
Arabic, English, French, German, Italian, Japanese, Polish, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese |
Warranty |
3-year warranty |
Regulatory approvals |
CE, FCC, Class A, CB, BSMI, VCCI, CU, ETL, EMF, PSB |
