Operate, monitor and maintain with CMND and Control
Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.
FailOver ensures that content is always playing
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.
Schedule what you want, when you want with SmartPlayer
Schedule what you want, when you want with SmartPlayer
Turn your USB into a true cost-effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display. Create your playlist and schedule your content via the on-screen menu, and enjoy your own playlists anytime, anywhere.
Integrated media player. Easily schedule USB content
Easily schedule content to play from USB. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback has finished.
| Specification | Value |
|---|---|
| Diagonal screen size (metric) | 163.9 cm |
| Diagonal screen size (inch) | 64.5 inch |
| Panel resolution | 3840 x 2160 |
| Optimum resolution | 3840 x 2160 @ 60 Hz |
| Brightness | 400 cd/m² |
| Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 ms |
| Aspect ratio | 16:9 |
| Viewing angle (horizontal) | 178 degree |
| Viewing angle (vertical) | 178 degree |
| Pixel pitch | 0.372 x 0.372 mm |
| Display colours | 1.07 Billion |
| Panel technology | IPS |
| Contrast ratio (typical) | 1200:1 |
| Clinical image | D-Image preset (dicom part 14 compatible) |
| Haze | 1% |
| Supported Display Resolution | |
| Computer formats | Video formats |
| 640 x 480, 60, 67, 72, 75 Hz | 480i, 60 Hz |
| 720 x 400, 70 Hz | 480p, 60 Hz |
| 800 x 600, 56, 60, 72, 75 Hz | 576p, 50 Hz |
| 832 x 624, 75 Hz | 576i, 50 Hz |
| 1024 x 768, 60, 70, 75 Hz | 720p, 60 Hz |
| 1152 x 864, 75 Hz | 1080i, 50, 60 Hz |
| 1152 x 870, 75 Hz | 1080p, 50, 60 Hz |
| 1280 x 720, 60 Hz | 3840 x 2160, 30Hz |
| 1280 x 800, 60 Hz | 3840 x 2160, 60 Hz |
| 1280 x 1024, 60 Hz | |
| 1440 x 900, 60 Hz | |
| 1600 x 1200, 60 Hz | |
| 1680 x 1050, 60 Hz | |
| 1920 x 1080, 60 Hz | |
| Connectivity | |
| Video input | DVI-I (x 1), HDMI 2.0 (x 3) |
| USB 2.0 (x 2) | |
| Audio input | 3.5 mm jack |
| Audio output | 3.5 mm jack |
| External control | IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack |
| Convenience | |
| Placement | Landscape (18/7), Portrait (18/7) |
| Tiled Matrix | Up to 10 x 15 |
| Signal loop through | RS232, IR Loop through |
| Ease of installation | Smart Insert |
| Energy-saving functions | Smart Power |
| Network controllable | RS232, RJ45 |
| Keyboard control | Hidden |
| Lockable | Remote control signal Lockable |
| Start-up | Switch on delay, Switch on status, Boot on source, Start-up window enable/disable Philips logo |
| Operating conditions | |
| Temperature range (operation) | 0 ~ 40 °C |
| Temperature range (storage) | -20 ~ 60 °C |
| Altitude | 0 ~ 3000 m |
| MTBF | 50,000 hour(s) |
| Humidity range (operation)[RH] | 20~80% RH (No condensation) |
| Humidity range (storage) [RH] | 5~95% RH (No condensation) |
| Power | |
| Consumption (Typical) | 165 W |
| Consumption (Max) | 220 W |
| Standby power consumption | <0.5 W |
| Mains power | 100–240 V~, 50/60 Hz |
| Power Saving Features | Smart Power |
| Energy Label Class | G |
| Sound | |
| Built-in speakers | 2 x 10 W RMS |
| Accessories | |
| Included Accessories | IR sensor cable (1.8 m) (x 1), Philips logo (x 1), AC power cord, AC Switch Cover, Quick start guide (x 1), Remote control and AAA |
| Leaflet | Downloads |
| Mechanical Drawing | Downloads |
| Manual | Downloads |
