100% recycled and recyclable packaging
Designed with manufacturing processes, physical features, materials, packaging and built-in software that are kinder to the environment and deliver better energy efficiency, the Philips Signage 3650 EcoDesign display is designed to operate using less than half the power of its counterparts, while still delivering the same unrivalled performance.
Android SoC processor. Native and web apps
Powered by our Android 10 SoC platform, these hard-working displays are optimised for native Android apps, and you can install web apps directly onto the display too. Flexible and secure, ensuring that display specs stay up to the moment for longer.
Connect and control your content via the cloud
Connect and control your content via the cloud with the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect a single display or your complete network. Show content in both landscape and portrait mode, with full HD resolution. Simply connect the display to the Internet using the optional CRD22 Wi-Fi module or via LAN, and enjoy your own created playlists.
EPEAT Silver Climate+ certified
Recognised by and registered with EPEAT with a Silver Climate+ Ecolabel, the Philips Signage 3650 EcoDesign meets the robust set of criteria laid out by the world's premier ecolabel for electronics.
FailOver. Ensure that content is always running
Critical for demanding commercial applications, FailOver is a revolutionary technology that automatically plays back-up content onscreen in the unlikely event of an input source or application failure. Simply select a primary input connection and a FailOver connection and you are ready for instant content protection.
Optional Interact for wireless screen share
Wirelessly screen-share using your existing Wi-Fi network to instantly and securely connect devices, or use our optional HDMI Interact dongle to cast directly onto the screen without connecting to the secured network.
Philips Wave ready for remote management
Unlock the power, versatility and intelligence inside your Philips Signage 3650 EcoDesign displays remotely with Wave. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing playlists and setting power schedules — saving you time, energy and environmental impact.
Wi-Fi and Bluetooth 5.2 via optional module
Easily schedule content to play from a USB or from internal memory. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback is done.
| Audio input | 3.5 mm jack | External control | RJ45 |
| RS232C (in/out) | 2.5 mm jack | IR (in/out) | 3.5 mm jack |
| Optional WiFi functionality | CRD22 Wi-Fi dongle | Video input | HDMI 2.0 (x2); DVI-I (x1); USB 2.0 (x2); USB 3.0 (x2) |
| Other connections | micro SD | Audio output | 3.5 mm jack |
| Remote control signal | Lockable | Tiled Matrix | Up to 15 x 15 |
| Network controllable | RS232, RJ45 | Energy-saving functions | Smart Power |
| Placement | Landscape (18/7), Portrait (18/7) | Signal loop through | RS232, IR Loop through |
| Keyboard control | Lockable, Hidden | Included Accessories | IR sensor cable, RS232 daisy-chain cable, Philips logo, AC Power Cord, AC Switch Cover, Cable clips, Quick start guide, RS232 cable, USB Cover |
| GPU | G52 MC1 | Memory | 16 GB; 3 GB DDR |
| CPU | Quad-Core Cortex A55 | Bezel width | 14.9 mm (Even bezel) |
| Product weight | 14.25 kg (31.42 lb) | Set Dimensions (W x H x D) | 1128.4 x 649.0 x 63.5 mm (44.43 x 25.55 x 2.50 inch) |
| Wall Mount | 400 x 400 mm, M6 | Built-in speakers | 2 x 10 W RMS |
| Mains power | 100–240 V~, 50/60 Hz | Consumption | 56 W (typical), 103 W (max) |
| Energy Label Class | E | Standby power consumption | <0.5 W |
| Power Saving Features | Smart Power | USB Playback Video | H.263, H.264, H.265, MPEG1/2/4, VP8, VP9 |
| USB Playback Picture | JPEG, BMP, PNG | USB Playback Audio | AAC, HEAAC, MPEG |
| Regulatory approvals | CE, CB, BSMI, FCC Class A, VCCI, J-Moss, ETL, RoHS | Warranty | 3 year warranty |
| On-Screen Display Languages | English, French, German, Italian, Polish, Russian, Spanish, Turkish, Chinese (Simplified & Traditional), Arabic, Japanese | Operating conditions | 0–40°C operation, -20–60°C storage, 20–80% RH (operation), 5–95% RH (storage), 0–3000 m altitude |
| MTBF | 30,000 hours | Panel technology | VA |
| Operating system | Android 10 | Pixel pitch | 0.2854 x 0.2854 mm |
| Panel resolution | 3840 x 2160 | Brightness | 350 cd/m² |
| Contrast ratio (typical) | 4000:1 | Dynamic contrast ratio | 500,000:1 |
| Response time (typical) | 8 ms | Viewing angle | 178° (H/V) |
| Display colours | 1.06 Billion | Aspect ratio | 16:9 |
| Optimum resolution | 3840 x 2160 @ 60 Hz | Diagonal screen size | 49.5 inch / 125.7 cm |
| Picture enhancement | 3/2-2/2 motion pull down, Dynamic contrast enhancement, Motion compensation deinterlacing, Progressive scan | Supported Computer Formats | 640x480 to 3840x2160, 24–75 Hz |
| Supported Video Formats | 480i/p, 720p, 1080i/p, 3840x2160p (24–60 Hz) | MTBF | 30,000 hours |
| Description | Downloads |
|---|---|
| Datasheet | Download |
| User Manual | Download |
| Mechanical Drawing | Download |
