Planet 8-Port 10/100/1000BASE-T Gigabit Ethernet Switch | GSD-803

SKU: GSD-803
Part Number: GSD-803
Condition: Brand New
Purchase Orders Accepted
Save £7.57 Save £7.57
Original price £51.63
Inc. VAT
Original price £51.63 - Original price £51.63
Original price £51.63

£36.72 (Excl. VAT)

Current price - £44.06 Inc. VAT
£44.06 - £44.06
Current price- - £44.06
(Inc. VAT )
Availability:
39 in stock

payment-icons

Bulk Price & Price Match Request

Contact our expert sales team on 020 8191 9223 for best price and dedicated assistance.

Educational & Public Sector Prices Available

For more details, please call us at 020 8191 9223 or email us at info@screenmoove.com

  • Description
  • Specifications
  • Downloads
  • Planet 8-Port 10/100/1000BASE-T Gigabit Ethernet Switch | GSD-803

    Optimal Solution for Energy Saving and Gigabit High Performance
    PLANET Green Networking Switch-GSD-803 is an ideal solution in line with the energy-saving trend worldwide. The GSD-803 is an 8-port Gigabit Ethernet Switch bringing both benefits of energy saving and Gigabit wire speed performance. It is specially designed for home networking, SOHOs and enterprises.

    Energy Saving
    The GSD-803 incorporates two advanced Green Networking technologies and is able to provide power saving up to 40% less energy but maintains high performance efficiently.
    (1) Hibernation Link Down power saving
    The Hibernation Link Down power saving goes beyond IEEE specifications to automatically lower power for a given port when it is not linked. With the Hibernation Link Down power saving technology, the GSD-803 will automatically adjust power usage of the ports that are shut down or not connected to network device.
    (2) Intelligent scales power based on cable length
    Intelligent scales power, the other technology adopted, is an intelligent algorithm that actively determines the appropriate power level based on cable length. When the GSD-803 is connected with Ethernet cable shorter than 20m, a device can obtain maximum power saving because the GSD-803 would automatically detect the Ethernet cable length and diminish power usage. The connected device can substantially reduce the overall power consumption, which makes a significant contribution to energy saving.



    Leading Home, SOHO and Workgroup Users to High-speed Networking Generation

    The GSD-803 is designed with modern metal compact housing and easy for deployment of high speed Gigabit networking in home or SOHO applications. Providing 16Gbps internal switching fabric, the GSD-803 can handle an extremely large amount of data in a secure topology linking to a backbone or high capacity servers. The GSD-803 provides 4K MAC address table, and wire-speed packet transfer performance without risk of packet loss. The high data throughput of the device makes it ideal for most Gigabit environments, especially for the network to be upgraded to a Gigabit environment.

    Plug & Play
    All RJ-45 copper interfaces of the GSD-803 support 10/100/1000Mbps auto-negotiation for optimal speed detection through RJ-45 Category 5, 5e or 6 cables. They support standard auto-MDI/MDI-X feature which can detect the type of connection to any Ethernet device without requiring special straight or crossover cables.

  • Specification Details
    Hardware Specification
    Hardware Version 7
    10/100/1000BASE-T Ports 8 auto MDI/MDIX ports
    LED Display One for Power, Two for 1000 & Link / Act per port
    Enclosure Metal
    Dimensions (W x D x H) 155 x 86 x 26 mm
    Weight 348g
    Power Requirements 5V DC, 1A (External power adapter)
    Power Consumption (100M Full Operation) 3.4 watts / 11 BTU
    Switch Specification
    Switch Processing Scheme Store-and-Forward
    Address Table 4K
    Flow Control Back pressure half duplex, IEEE 802.3x pause frame full duplex
    Switch Fabric 16Gbps
    Throughput (packet per second) 11.9Mpps
    Jumbo Packet Size 9K
    Standards Conformance
    Standards Compliance IEEE 802.3 (Ethernet), IEEE 802.3u (Fast Ethernet), IEEE 802.3ab (Gigabit Ethernet), IEEE 802.3x (Full-duplex Flow Control), IEEE 802.3az Energy Efficient Ethernet (EEE)
    Regulation Compliance FCC Part 15 Class B, CE
    Environment
    Temperature Operating: 050 degrees C, Storage: -1070 degrees C
    Humidity Operating: 595%, Storage: 595% (non-condensing)
  • Description Downloads
    Datasheet Downloads
