Build a Smart IoT Environment with Fabulous LoRaWAN sensor
PLANET LS100-DW IP30 LoRaWAN Indoor Occupancy Sensor, which offers an elegant solution for real-time monitoring of building entrances. Apart from enhanced security measures, it contributes to energy management by providing data support. Through LoRaWAN connectivity, this sensor delivers real-time status updates on doors and windows, improving energy efficiency and access control.
LoRa and LoRaWAN Wireless Technology
LoRa is a low-power, wide area network (LPWAN) RF modulation technology. It standardizes LPWANs and enables extremely long-range data links. With a range of up to three miles (five kilometers) in urban areas and over 10 miles (15 kilometers) in rural areas (line of sight), LoRa is ideal for creating networks that require long-range or deep in-building communication. A key feature is its ultra-low power requirements, enabling the deployment of battery-operated devices that can last up to several years. Using the open LoRaWAN protocol in a star topology, it's suitable for applications with numerous low-power devices collecting small amounts of data. The LS series is ideal for LoRa-enabled devices in the IoT system.
LoRaWAN-based Sensor
PLANET LoRaWAN LS100/LS200 series Sensor is fully compatible with standard LoRaWAN gateways like PLANET LCG-300 series, supporting the LoRaWAN class A protocol. It is ideal for large-scale IoT applications, including building automation, smart metering, HVAC systems, agriculture, and more. The sensor facilitates the seamless integration of multiple sensors, making it a perfect choice for retrofitting legacy assets into IoT-enabled systems.
LS100-WL
IP65 LoRaWAN Water Leak Sensor
LS100-PIR
IP30 LoRaWAN Indoor Occupancy Sensor
LS100-DW
IP30 LoRaWAN Door and Window Sensor
LS200-TH
IP65 LoRaWAN Indoor Temperature and Humidity Sensor
LS200-PT
IP65 LoRaWAN Product Temperature Sensor
LS200-TC
IP65 LoRaWAN Machine Temperature Sensor
LS200-RF
IP65 LoRaWAN Refrigerator Temperature and Humidity Sensor
LS200-LG
IP65 LoRaWAN Light Level Sensor
LS200-CM3
IP53 LoRaWAN 3-phase Current Meter
Key Features
Door and Window contact Sensor
IP30 rating
LoRaWAN™ Class A compatible
| Technology | LoRaWAN | Frequency | LS100-DW-868M: 863–870 MHz; LS100-DW-915M: 902–928 MHz |
| TX Power | EU868: 16dBm; IN865: 20dBm optional; US915: 20dBm; AS923: 16dBm optional; AU915: 20dBm optional; KR920: 14dBm optional | Rx Sensitivity | -136dBm LoRa SF12 293bps; -121dBm FSK 5kHz 1.2kbps |
| Work Mode | OTAA/ABP Class A | Power Supply | 2x 3.0V CR2450 button battery (Battery not included) |
| Operating Voltage | DC 2.4V～3V | Battery Life Time | 1.52 years (25°C, 60-minute reports, TxPower=20dBm, SF10) |
| Standby Current | 12µA | Wake-up Current | 120mA/11mA typical value |
| Low Battery Threshold | 2.4V | Dimensions | 57 x 38.05 x 15.2 mm; 42.5 x 13 x 12 mm (Magnet) |
| Weight | 43.8g | Ingress Protection | IP30 |
| Operating Temperature | -20°C to 55°C | Relative Humidity | <90% RH (non-condensing) |
| Storage Temperature | -40°C ~ 85°C | Regulatory Compliance | FCC PART 15B |
| Description | Downloads |
|---|---|
| Datasheet | Download |
