The ProDVX IPPC-22-6000 is an Intel Panel PC with a 21.5" Touch Display. The ProDVX IPPC-22-6000 standard comes with an Intel Pentium N4200 1.1 GHz. This device can be connected through RJ45 LAN, WiFi, Bluetooth and is fanless due to passive cooling. This Intel SOC Touch Display has a projected capacitive touch display in plastic housing. Optional accessories for the Pogo Pins are a 1D/2D Barcode Scanner, NFC Module or VESA brackets. This product requires an additional Windows 10 IoT Enterprise LTSC license.
| Category | Specification |
|---|---|
| Panel | |
| Panel Type | TFT LCD IPS |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 wide |
| Backlight | Edge-LED backlight |
| Brightness | 250 cd/m² |
| Viewing Angle | H178° / V178° |
| Contrast Ratio | 3000:1 |
| Touch Type | 10 TP P-Cap, 20 ms |
| Surface Treatment | Glare |
| Display Modes | Landscape, Portrait, Table Mode |
| Gyroscope | N/A |
| Operation Hours | 24/7 |
| System | |
| Chipset | Intel HD505 |
| CPU | Intel Pentium N4200 1.1 GHz |
| GPU | Intel HD 505 Graphics |
| Cooling | Fanless |
| System Memory | 4GB DDR3L |
| Internal Storage | 64GB SSD (M.2 2242) |
| External Storage | SD Card Slot (door) |
| Storage Socket 2 | SD Card Slot (door) |
| OS | Windows 10 IoT LTSC |
| Windows License | Yes, additional cost |
| Video Input | N/A |
| Video Output | Yes, mini-HDMI out |
| LED Light Bar | N/A |
| Connectivity & I/O | |
| Power Input | 12V DC-IN |
| COM Ports | 2x COM (RJ45) |
| USB Ports | 2x USB 3.0, 1x Micro-USB |
| Audio I/O | Combo Jack, S/PDIF |
| Network | 1x Ethernet RJ45 (10/100/1000 Mbps) |
| WiFi | 802.11 a/b/g/n/ac |
| Bluetooth | Bluetooth 4.2 |
| Power over Ethernet | N/A |
| Integrated NFC | via PoGo & USB |
| Camera | via PoGo & USB |
| Multimedia | |
| Video Support | MKV, MP4 |
| Audio Support | MP3, WMA |
| Photo Support | JPEG, PNG |
| Microphone | Yes |
| Speakers | 2 x 3 W |
| Physical | |
| Housing | ABS+PC (Macrolon) |
| Color | Black |
| Weight | 4200 g |
| Dimensions (mm) | 530.5 x 321.22 x 35 mm |
| Mounting | VESA 100 |
| Power Supply | 12V / 5A (Included) |
| Power Usage | 40 ~ 70 Watt |
| Pogo Pins | 3x (bottom, left, right) |
| Environmental | |
| Storage Temp | -10 ~ 55°C |
| Working Temp | 0 ~ 40°C |
| Humidity | 10 ~ 90% non-condensing |
| MTBF | 50,000 hours demonstrated |
| Clock Battery | CR2032 Lithium (non-rechargeable) |
| Miscellaneous | |
| OSD Language | Multi-language |
| Warranty | 3 years |
| Certifications | CE, RoHS, REACH |
| SKU | 6022100 |
| Description | Downloads |
|---|---|
| Datasheet | Downloads |
| User Guide | Downloads |
| Drawing | Downloads |
