Display |
|
Backlight |
Crystal-UHD 4K |
Screen Size |
43 inches |
Resolution |
4K (3,840 x 2,160) |
Video |
|
Picture Engine |
UHD Mastering Engine |
Micro Dimming |
N/A |
Auto Motion Plus |
Yes |
Clear Motion |
N/A |
Film Mode |
Yes |
Natural Mode Support |
Yes |
Motion Rate |
100 |
PQI (Picture Quality Index) |
1300 |
HDR (High Dynamic Range) |
HDR |
HDR10+ |
Support |
HLG (Hybrid Log Gamma) |
Yes |
Contrast |
Mega Contrast |
Color |
PurColor |
Viewing Angle (Horizontal/Vertical) |
178/178 |
Auto Depth Enhancer |
N/A |
Contrast Enhancer |
Yes |
Audio |
|
Dolby Digital Plus |
Yes |
Sound Output (RMS) |
20W |
Speaker Type |
2CH |
Woofer |
N/A |
Bluetooth Audio |
N/A |
Smart TV |
|
Samsung SMART TV |
N/A |
Voice Interaction |
N/A |
TV Plus |
N/A |
Web Browser |
N/A |
Universal Guide |
N/A |
VESA |
|
VESA Mount |
200 x 200 mm |
VESA Screw Size |
M8 |
VESA Screw Depth |
20-22 |
Convergence |
|
TV to Mobile - Mirroring |
N/A |
Mobile to TV - Mirroring, DLNA |
N/A |
Ambient Mode |
N/A |
360 Video Player |
N/A |
360 Camera Support |
N/A |
Easy Setup |
N/A |
Bluetooth Low Energy |
N/A |
WiFi Direct |
N/A |
TV Sound to Mobile |
N/A |
Sound Mirroring |
N/A |
General Feature |
|
Accessibility |
UK English, German, French, Spanish, Italian, Dutch, Polish, Danish, Swedish, Finnish, Norwegian, Portuguese, Russian (only when connecting to Network in EE, LV, LT) |
Digital Clean View |
Yes |
Auto Channel Search |
Yes |
Auto Power Off |
Yes |
Caption (Subtitle) |
Yes |
Connect Share™ (HDD) |
Yes |
ConnectShare™ (USB 2.0) |
Yes |
EPG |
Yes |
Game Mode |
Yes |
OSD Language |
27 European Languages + Russian (only when connecting to Network in EE, LV, LT) |
Picture-In-Picture |
N/A |
BT HID Support |
N/A |
USB HID Support |
Yes |
Teletext (TTX) |
Yes |
Ultra Clean View |
N/A |
V-Chip |
N/A |
MBR Support |
N/A |
IPv6 Support |
N/A |
System |
|
Digital Broadcasting |
DVB-T2CS2 |
Analog Tuner |
Yes |
CI (Common Interface) |
CI+(1.4) |
Data Broadcasting |
HbbTV 2.0.1 (IT) / HbbTV 1.5 (CZ, SK, DE, AT, FR, ES, FI, EE, GR) / HbbTV 1.0 (PL, HU, CH, BE, NL, LU, PT, DK) / MHEG 5 (GB, IE) |
Hospitality Feature |
|
H.Browser Compatibility |
N/A |
Samsung LYNK™ REACH (IP) |
N/A |
Samsung LYNK™ REACH (RF) |
REACH 4.0 |
Samsung LYNK™ Cloud |
N/A |
Hospitality Home Menu |
Home Menu 2017 |
Hospitality Home Menu 2.0 |
N/A |
Bluetooth Music Player (Mobile → TV) |
N/A |
Hospitality Plug&Play (Easy Set-up) |
Yes |
Auto Source Mode |
Yes |
Power On Mode |
Yes |
Hotel Channel List |
Yes |
Channel Menu Display |
Yes |
Mixed Channel List (ATSC, DVB-T/T2/C/S2, Analog) |
Yes |
My Channel |
Yes |
Energy Saving Mode (BLU Control) |
Yes |
Logo Display with Time Out Setting (BMP/Movie) |
Yes |
Welcome Message |
Yes |
RJ12/IR Pass Through |
Yes |
Clock Back Up Supply |
Yes |
Software Clock |
N/A |
Multi Code Remote Control |
Yes |
Music Mode (Input: PC/AV/Component/HDMI) |
Yes |
Music Mode Backlight on/off |
N/A |
TTX Clock Update (Analogue) |
Yes |
USB Cloning |
Yes |
Smoovie Compatibility |
Yes |
Soft AP |
N/A |
On/Off Timer (Schedule) |
Yes |
Wake-up Timer (Alarm) |
Yes |
Samsung LYNK™ DRM |
Yes |
Pro
|
N/A |
Pro
SW |
N/A |
bLAN |
No |
Security Mode |
Yes |
S/W EPG (Solution EPG) |
Yes |
UL Certification |
N/A |
Input & Output |
|
HDMI |
3/0 |
USB |
2 x USB-A |
Component In (Y/Pb/Pr) |
N/A |
Composite In (AV) |
N/A |
Ethernet (LAN) |
N/A |
Headphone |
N/A |
Audio Out (Mini Jack / LR) (Side/Rear) |
N/A |
Digital Audio Out (Optical) |
1 |
RF In (Terrestrial / Cable input / Satellite Input) |
1/1 (Common Use for Terrestrial) / 0 |
Ex-Link (Supports RS-232C Gender) |
N/A |
CI Slot |
1 |
HDMI A / Return Ch. Support |
Yes |
Wireless LAN Built-in |
N/A |
Anynet+ (HDMI-CEC) |
Yes |
Pillow Speaker Jack |
No |
Variable Audio Out |
N/A |
Variable Audio Out Volume Control |
N/A |
Video Out |
N/A |
RJ12 (Side/Rear) |
0/1 |
RJP (Remote Jackpack) (Side/Rear) |
0/1 |
Headphone ID |
N/A |
Door-Eye Control (Side/Rear) |
No |
Door-Eye Video In (Side/Rear) |
No |
PC/DVI Audio In (Mini Jack) (Side/Rear) |
No |
Ethernet Bridge (LAN-Out) |
N/A |
Design |
|
Front Colour |
Black |
Stand Type |
Square |
Swivel (Left/Right) |
Yes |
Bezel Type |
3 Bezel-less |
Light Effect (Deco) |
N/A |
Eco |
|
Energy Efficiency Class |
G |
Eco Sensor |
Yes |
Power |
|
Power Supply (V) |
AC220-240V~ 50/60Hz |
Power Consumption (Max) |
125 W |
Power Consumption (Energy Saving Mode) |
N/A |
Power Consumption (Stand-by) |
0.50 W |
Power Consumption (Typical) |
54.0 W |
Dimension |
|
Set Dimension without Stand (WxHxD) |
963.9 x 558.9 x 59.6 mm |
Set Dimension with Stand (WxHxD) |
963.9 x 610.9 x 226.5 mm |
Package Dimension (WxHxD) |
1183 x 670 x 143 mm |
Weight |
|
Set Weight without Stand |
8.6 kg |
Set Weight with Stand |
11.8 kg |
Package Weight |
15.0 kg |
Accessory |
|
Remote Controller Model |
TM1240A |
Batteries (for Remote Control) |
Yes |
Samsung Smart Control (Included) |
N/A |
Mini Wall Mount Supported |
Yes |
VESA Wall Mount Supported |
Yes |
User Manual |
N/A |
E-Manual |
N/A |
ANT-Cable |
N/A |
Power Cable |
Yes |
Quick Install Guide |
Yes |
Data Cable |
Yes |
Stand Mount Kit |
Yes |
Security Screws (Stand Base) |
No |
PureCare Remote (Seamless White Remote) |
No |
No Gap Wall-mount |
N/A |
Optional Stand Support |
N/A |
Slim Gender Cable |
N/A |
Screwed Battery Cover (Remote Control) |
Yes |
Angle Adaptor (for Side RF tuner) |
No |
