Adopt a new paradigm for your business
The Wall is the epitome of innovation. It constantly delivers new avenues to create unparalleled visual statements. Redefining the LED paradigm once again, The Wall now solves the biggest challenge of industry, drastically improving installation. The Wall, let it transform your business.
An abyss of depth
Black Seal Technology
A deep black background blankets the screen with perfect uniformity, creating a seamless canvas for purer black levels with enhanced depth that delivers unparalleled contrast and immaculate detail.
Superior color purity
Ultra Chroma Technology
Colors leap to life with spectacular vibrancy to recreate scenes as if you were there in real life. Narrower wavelengths produce RGB colors two times purer* and more accurate than conventional LEDs.
* Figure is based on internal testing standards against Samsung's conventional LED Signage.
The installation process, reinvented
Pre-assembled Installation
The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.
The installation process, reinvented
Pre-assembled Installation
The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.
The installation process, reinvented
Pre-assembled Installation
The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.
The installation process, reinvented
Pre-assembled Installation
The Wall All-in-One drastically simplifies installation by docking the background plates and hanging just three or four preset modules, depending on the display size. Installation now takes only two hours for two people to complete the screen.
Auto configuration setup
Built-in Control Box
Time-consuming configuration between control box and cabinet is no longer needed. The Wall All-in-One integrates the control box so it’s built-into the display, eliminating a cumbersome configuration process to get the display up and running faster.
Critical decisions without complexity
Simple Choice
The Wall All-in-One removes complex elements traditionally associated with LED displays, creating a streamlined purchase path. Now, make purchases based on just two factors – resolution and size – without complications such as pixel pitch or configuration.
No extra peripherals needed
All-inclusive Components
The Wall All-in-One includes everything you need to begin operations - from the control box and wall brackets to speakers and deco bezels. No additional purchases or components are required, allowing you to focus on getting your display up and running fast.
Colors mapped to perfection
20bit Processing
The Wall All-in-One offers 20bit processing to present exact color mapping with faultless accuracy. Deeper bit depth at low grayscale also delivers extraordinary contrast ratio and smooth, natural tones.
Continuous natural shading
Linear Grayscale
A precise linear grayscale showcases intricacies in every scene, delivering textures, volume and continuous shadow details. The elevated continuity pulls you further into your content for unbroken immersion.
Instant AI optimization
Neural Quantum Processor 4K
Every second of content is instantly analysed and optimised for perfect picture quality. The powerful AI processor delivers superior visuals in any size up to 4K* resolution, enhancing contrast and removing noise.
Dazzling dynamic range
MICRO HDR
Reimagine the limits of conventional screens with advanced HDR picture refinement technology to illuminate ideal peak brightness and contrast in every scene for precise, true-to-life imagery.
Smooth, seamless motion
MICRO Motion
Every motion becomes sharper, with greater clarity. The Wall All-in-One automatically converts standard 60Hz signals to 120Hz, removing motion judder in fast-paced action for smoother streams and a seamless viewing experience, every time.
-
| Operation Conditions |
|
| Working Temperature |
0°C~+40°C / 10~80%RH |
| Physical Parameter |
|
| Pixel Pitch |
1.26mm |
| Pixel Configuration |
1920 x 1080 |
| Diode Type |
Flip-chip RGB LED (182*93) |
| Optical Parameter |
|
| Brightness |
500 nit |
| Contrast Ratio |
24,000:1 |
| Viewing Angle (Horizontal/Vertical) |
170/155° |
| Colour Temperature |
6,500K ± 500K (floating bin) |
| Electrical Parameter |
|
| Video Rate |
120 Hz |
| Input Voltage (alternating current) |
100~240V AC |
| Power Frequency |
50/60 Hz |
| Refresh Rate |
3840 Hz |
| Certification and Compliance |
|
| Safety |
|
| CB (Europe) |
IEC60950-1/EN60950-1 |
| CCC (China) |
GB4943.1-2011 |
| PSB (Singapore) |
PSB+IEC60950-1 |
| NOM (Mexico) |
NOM-001-SCFI-1993 |
| IRAM (Argentina) |
IRAM+IEC60950-1 |
| SASO (Saudi Arabia) |
SASO+IEC60950-1 |
| BIS (India) |
IEC60950-1 / IS13252 |
| NOM (Mexico) |
Tuner: NOM-001-SCFI-1993 Tunerless: NOM-019-SCFI-1998 |
| KC (Korea) |
K 60950-1 |
| EAC (Russia) |
EAC+IEC60950-1 |
| INMETRO (Brazil) |
INMETRO+IEC60950-1 |
| BSMI (Taiwan) |
BSMI+IEC60950-1 |
| RCM (Australia) |
IEC60950-1/AS/NZS 60950-1 |
| UL (USA) |
cUL60950 |
| EMC |
|
| Class A FCC (USA) Part 15, Subpart B |
KCC/EK (Korea) Tuner: KN32 / KN35 Tunerless: KN32 / KN35 |
| CE (Europe) |
EN55032:2012 or 2015 EN55024:2010 or EN 55035:2017 |
| VCCI (Japan) |
VCCI CISPR32:2016 |
| CCC (China) |
GB/T9254-2008 GB17625.1-2012 |
| BSMI (Taiwan) |
CNS13438 (ITE EMI ) CNS14336-1 (ITE Safety ) CNS15663 (RoHS) |
| C-Tick (Australia) |
AS/NZS CISPR32:2015 |
| GOST (Russia/CIS) |
ROCT CISPR 24-2013 ROCT CISPR 22:2005 |
-
SAMSUNG SMART SIGNAGE STARDARD
WARRANTY GUIDE
SMART SIGNAGE
1. Warranty Term
Samsung currently provides a 3 year standard limited warranty, but the warranty period may vary by country. Please contact your local Samsung representative to check the standard warranty period applicable for your country.
Customers can purchase an extended warranty service pack, which must be purchased when the Product is purchased. The extended warranty period can increase the warranty period up to a total of 5 years.
2. Warranty Description
Samsung warrants that the Product will be free from manufacturing defects in material and workmanship during the abovementioned warranty period and fit for being used as commercial digital signage.
During the warranty period, Samsung will, at its sole discretion,
1) provide service via phone, mail, technical support website (ex. Service Cloud) or e-support access to Help Desk to assist in resolving issues. Phone support is available during normal business hours.
2) repair (at Samsung’s own or Samsung’s Authorized Service Center(ASC)), or replace (using new or refurbished replacement parts or Products) any defect within a reasonable period of time and free of charge.
Generally, On-Site Repair Service is the default service for any Product requiring repair during the applicable warranty period. However, depending on the installed Product, location, environment and any special contract terms, there could be other services available such as Carry-In or Pick-up & Return.
Service Response Turnaround Time (“TAT”):
The average TAT for Service Response is D+1 business days. Service Response means first response to a request (phone, e-mail, technical support website and / or verbal).
Service Response may take more than 1 business day depending on the case.
Service Repair TAT:
Service Repair means initial repair activity by Samsung or Samsung’s ASC.
※ Initial repair activity means one of below activities; site visit, checking symptoms, defective part exchange, configuration adjustment, etc.
Samsung shall aim for a Service Repair TAT of D+5 business days, provided however, additional time may be required, due to, by way of example, limitations in transportation/personnel availability, inaccessibility of location, locations requiring special access authorization (i.e. duty free stores), repeatability of the problem, and inaccurate description of the problem provided. Samsung will use its best efforts to solve the problem during its first on-site visit.
In the event Samsung experiences or foresees such delay, Samsung shall notify the customer and the Parties shall discuss in good faith to arrive at a resolution including a new delivery schedule.
Samsung recommends that the customer maintain a buffer stock of Products to minimize downtime.
3. Warranty Coverage
This limited warranty begins on the original date of purchase, and is valid only on Products purchased directly from Samsung or through Samsung’s authorized partners. To receive warranty service, the customer must contact Samsung for problem determination and service procedures. Warranty service can only be performed by a Samsung ASC. The original dated bill of sale must be presented upon request as proof of purchase to Samsung or Samsung’s ASC. In the event that no proof of purchase can be presented to Samsung, the limited warranty will commence from the date of manufacture specified on the Product.
All replaced parts and Products shall become the property of Samsung and must be returned to Samsung. The repaired or replaced parts or Products assume the remaining original warranty
