Completely captivating. Fully flexible.
LED signage has become an increasingly popular tool for businesses to deliver compelling messages to customers. Samsung’s IFR series combines best-in-class LED picture quality, flexible design options and efficient operation in any environment.
Best-in-class LED picture quality
Drawing on Samsung’s industry leadership experience and years of innovation in visual display technology, the displays produce images with vivid color expression, reduced noise and a full range of grays and blacks.
Clearly refined visuals
LED HDR turns any content into HDR-level without requiring special metadata. Dynamic Peaking and Inverse Tone Mapping enhance content to optimum brightness levels while avoiding glare, and Color Mapping ensures an accurate color presentation.
Pin-sharp clarity, bright or dark
Discover the true beauty no matter how bright or dark a scene is. The IFR series supports HDR10+ which optimizes brightness and contrast ratio scene-by-scene to ensure each frame looks exactly as intended.
HDR experience in large scale
With Multi-link HDR technology, IFR series delivers more impactful content than ever before, providing HDR quality content up to 8K resolution. Multi-link HDR turns any content into HDR-level and is a flexible solution that can be applied to various layouts and screen sizes with less cabling.
Flexible design for any location
IFR series features two cabinet types of differing sizes to provide more flexibility in design. With support of portrait, landscape, curved and L-shaped installations, businesses can have ultimate control to create the ideal display for their space.
Screen uniformity all the time
On-site PC and mobile calibration combined with multi-step factory calibration tunes the whole screen of LED displays to uniform brightness and color. Color Expert LED Mobile provides a quick and easy calibration, requiring nothing more than a mobile phone and a Wi-Fi connection.
Seamless, smooth content playback
Frame rate synchronization guarantees smooth content without screen tearing when multiple S-boxes are connected. This means users can enjoy almost perfectly smooth playback even when combining or splitting content across cabinets.
Built for the studio
Samsung’s IFR series is built for studio shooting. Supporting frame rate synchronization and a high refresh rate to minimize flicker lines, the display helps producers create incredibly engaging and immersive content, with levels of detail like never before.
-
| Operation Conditions |
|
| Working Temperature |
0°C~+40°C / 10~80%RH |
| IP Rating |
IP20 |
| Physical Parameter |
|
| Pixel Pitch |
1.5mm |
| Pixel Configuration |
640x360 |
| Diode Type |
3-in-1 1010 |
| Optical Parameter |
|
| Brightness |
800nit |
| Viewing Angle (Horizontal/Vertical) |
160/160° |
| Color Temperature |
6,500K+-500K (floating Bin) |
| Electrical Parameter |
|
| Video Rate |
50/60Hz |
| Input Voltage (alternating current) |
100~240VAC |
| Power Frequency |
50/60Hz |
| Power Consumption (Max) |
694W |
| Refresh Rate (Hz) |
3840Hz |
| Certification and Compliance |
|
| Safety |
60950-1 |
| EMC |
Class A |
-
SAMSUNG SMART SIGNAGE STARDARD
WARRANTY GUIDE
SMART SIGNAGE
1. Warranty Term
Samsung currently provides a 3 year standard limited warranty, but the warranty period may vary by country. Please contact your local Samsung representative to check the standard warranty period applicable for your country.
Customers can purchase an extended warranty service pack, which must be purchased when the Product is purchased. The extended warranty period can increase the warranty period up to a total of 5 years.
2. Warranty Description
Samsung warrants that the Product will be free from manufacturing defects in material and workmanship during the abovementioned warranty period and fit for being used as commercial digital signage.
During the warranty period, Samsung will, at its sole discretion,
1) provide service via phone, mail, technical support website (ex. Service Cloud) or e-support access to Help Desk to assist in resolving issues. Phone support is available during normal business hours.
2) repair (at Samsung’s own or Samsung’s Authorized Service Center(ASC)), or replace (using new or refurbished replacement parts or Products) any defect within a reasonable period of time and free of charge.
Generally, On-Site Repair Service is the default service for any Product requiring repair during the applicable warranty period. However, depending on the installed Product, location, environment and any special contract terms, there could be other services available such as Carry-In or Pick-up & Return.
Service Response Turnaround Time (“TAT”):
The average TAT for Service Response is D+1 business days. Service Response means first response to a request (phone, e-mail, technical support website and / or verbal).
Service Response may take more than 1 business day depending on the case.
Service Repair TAT:
Service Repair means initial repair activity by Samsung or Samsung’s ASC.
※ Initial repair activity means one of below activities; site visit, checking symptoms, defective part exchange, configuration adjustment, etc.
Samsung shall aim for a Service Repair TAT of D+5 business days, provided however, additional time may be required, due to, by way of example, limitations in transportation/personnel availability, inaccessibility of location, locations requiring special access authorization (i.e. duty free stores), repeatability of the problem, and inaccurate description of the problem provided. Samsung will use its best efforts to solve the problem during its first on-site visit.
In the event Samsung experiences or foresees such delay, Samsung shall notify the customer and the Parties shall discuss in good faith to arrive at a resolution including a new delivery schedule.
Samsung recommends that the customer maintain a buffer stock of Products to minimize downtime.
3. Warranty Coverage
This limited warranty begins on the original date of purchase, and is valid only on Products purchased directly from Samsung or through Samsung’s authorized partners. To receive warranty service, the customer must contact Samsung for problem determination and service procedures. Warranty service can only be performed by a Samsung ASC. The original dated bill of sale must be presented upon request as proof of purchase to Samsung or Samsung’s ASC. In the event that no proof of purchase can be presented to Samsung, the limited warranty will commence from the date of manufacture specified on the Product.
All replaced parts and Products shall become the property of Samsung and must be returned to Samsung. The repaired or replaced parts or Products assume the remaining original warranty
