StarTech 1m Grey CAT6 Cable - Slim - Snagless RJ45 Connectors - N6PAT100CMGRS

This slim CAT6 cable meets all Category 6 patch cable specifications to deliver a reliable Gigabit network connection in high-density data center applications.

Easy Cable Runs
The design of this slim CAT6 patch cord is 36% thinner than standard networking cables, which allows better airflow and heat dissipation in tight spaces. The cable is also more flexible than standard Ethernet cables, so cable runs are easier in crowded network racks.

This cable features snagless connectors that protect the RJ45 clips during installation, making them less likely to snag or break as you pull them through narrow spaces.

Protect Your Equipment
This CAT6 patch cable is tested to comply with ANSI/TIA 568 C.2 Category 6 requirements ensuring a reliable connection to your networking equipment. Certified with Low Smoke Zero Halogen (LSZH) fire rating, this patch cord ensures a safe connection.

The 50-micron gold connectors on the patch cable deliver optimum conductivity and eliminate signal loss due to oxidation or corrosion.

High-Quality Construction
Each CAT6 cable is manufactured using high-quality copper conductors and is carefully constructed and tested to keep Near-End Crosstalk (NEXT) well within acceptable limits. Plus, each cable is built with 28 AWG copper wire, to ensure peak performance for your demanding Ethernet applications.

N6PAT100CMGRS is backed by StarTech.com lifetime warranty and free lifetime technical support.

Applications
For installation in high-density data centers
Designed for use with Gigabit networks

Warranty Information
Warranty	Lifetime
Connector(s)
Connector A	1 - RJ-45
Connector B	1 - RJ-45
Hardware
Number of Conductors	4 pair UTP
Connector Plating	Gold
Cable Jacket Material	Al(OH)3 (Aluminium Hydroxide), EVA (Ethylene-Vinyl Acetate Copolymer)
Fire Rating	LSZH Rated (Low Smoke Zero Halogen)
Cable Type	Snagless
Wiring Standard	TIA/EIA-568-B.1-2001 T568B
Packaging Information
Package Height	0.1 mm [0.0 in]
Package Length	20.0 cm [7.9 in]
Shipping (Package) Weight	34.0 g [1.2 oz]
Package Width	22.0 cm [8.7 in]
Package Quantity	1
Performance
Cable Rating	CAT6 - 250 MHz
Physical Characteristics
Product Height	1.0 cm [0.4 in]
Product Length	1.0 m [3.3 ft]
Weight of Product	24.0 g [0.8 oz]
Product Width	2.0 cm [0.8 in]
Color	Gray
Wire Gauge	28 AWG
Conductor Type	Stranded Copper
Cable Length	1 m [3.3 ft]
What's in the Box
Included in Package	1 - 1 m Slim CAT6 Cable
