TP-LINK’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.
Enterprise Hardware
With Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE210 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -40℃ (-40℉) to +70 ℃ (158℉).
Advanced Antenna System
Built-in High Gain Dual-Polarized Antenna
Dedicated metal reflector ensures higher gain
and lower noise interference
5km+ Wireless Data Transmission
Specially designed for outdoor uses, ideal for long distance wireless data transmission over 5km+, tested in the field.
TP-LINK MAXtream TDMA Technology
As network scale increases, wireless competition and collisions among CPEs and base stations will be
so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user
experience. To mitigate these effects, the CPE210 uses MAXtream TDMA Technology.
Pharos Control – Centralized Management System
CPE210 also comes equipped with centralized management software that helps users easily manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.
PharOS
User-friendly web-based management system allows professionals to do more specific configurations.
2.4GHz 300Mbps 9dBi Outdoor CPE CPE210
| Hardware Features | Description |
|---|---|
| Processor | Qualcomm Atheros 560MHz CPU, MIPS 74Kc |
| Memory | 64MB DDR2 RAM, 8MB Flash |
| Interface | - 1 10/100Mbps Shielded Ethernet Port (Passive PoE in) - 1 Grounding Terminal - 1 Reset Button |
| Power Supply | Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) |
| Voltage Range | 16-27VDC |
| Power Consumption | 10.5 Watts Max |
| Dimensions | 8.8 x 3.1 x 2.4 in. |
| Antenna Type | Built-in 9dBi 2x2 Dual-polarized Directional Antenna |
| Beam Width | 65° (H-Plane) / 35° (E-Plane) |
| Protection | - 15KV ESD Protection - 6KV Lightning Protection |
| Enclosure | Outdoor ASA stabilized plastic material |
| Certification | IPX5 waterproof Certification |
| Wireless Features | Description |
|---|---|
| Wireless Standards | IEEE 802.11b/g/n (with Pharos MAXtream disabled) |
| Proprietary Protocol | TDMA Mode (with Pharos MAXtream enabled) |
| Wireless Speeds | See below |
| Frequency | 2.4~2.483GHz |
| Transmission Power | 27dBm/500mw (1dBm step adjustable) |
| Software Features | Description |
|---|---|
| Wireless Configurations | See below |
| Management | - Discovery and Remote Management via Pharos Control application - HTTP/HTTPS Web-based management - System Log - SNMP Agent(v2c) - Ping Watch Dog - Dynamic DDNS - SSH Server |
| POE Adapter Features | Description |
|---|---|
| Dimensions | 4.3 x 2.2 x 1.3 in |
| Interfaces | - 1 AC Jack with Earth Ground - 1 10/100Mbps Shielded Ethernet Port (Power + Data) - 1 10/100Mbps Shielded Ethernet Port (Data) - Remote Reset Button |
| Others | Description |
|---|---|
| Certification | FCC, RoHS, IPX5 |
| Package Contents | - Outdoor Wireless CPE - 24VDC Passive PoE Adapter - Pole Mounting Straps - AC Power Cord - Installation Guide |
| Environment | - Operating Temperature: -40℃ |
| Description | Downloads |
|---|---|
| Installation Guide |
Downloads |
