Trendnet 2-Port HDMI KVM Switch | TK-215I
TRENDnet's 2-Port HDMI KVM Switch, model TK-215i, controls two computers (with an available HDMI port) with one set of console controls. No driver installation required, simply plug in the integrated cables to share two computers with a full HD 1080p display. The TK-215i supports HDMI and 3.5 mm analog audio and features an ergonomic computer toggle switch.
Computers
Control up to 2 computers
1080p HD
Supports full HD 1080p (progressive 1920 x 1080 pixels) with a 60 Hz refresh rate
2-Way Audio
Full audio support through HDMI cable connections with optional 3.5 mm microphone and speaker jacks
Toggle Switch
Use the integrated 1.5 m (5 ft.) cable to position the toggle switch in the most ergonomic location
Console Connectors
Emulation Technology supports advanced USB keyboard and mouse designs
HDMI Display
HDMI 1.3 with HDCP support
Computer Ports
Requires free USB and HDMI ports from connected computer
Integrated Cables
All required cables are integrated
Switch Software
Windows®and Mac®based KVM switch software to define hot keys and create auto-scan intervals
-
Feature |
Details |
Console Port on KVM |
Keyboard: USB |
|
Mouse: USB |
|
Monitor: HDMI 1.3 (19-pin) |
|
Speaker jack: 3.5 mm |
|
Microphone jack: 3.5 mm |
Computer Connections (up to 2) |
Keyboard/mouse: USB 2.0 type A |
|
Monitor: HDMI 1.3 (19-pin) |
|
Speaker jack: 3.5 mm |
|
Microphone jack: 3.5 mm |
Monitor Resolution |
1920 x 1080 @ 60 Hz |
Audio Support |
5.1 Audio over HDMI cables |
|
Analog audio over speaker and microphone jacks |
LED |
Computer 1 and Computer 2 |
Switching Control |
One touch toggle switch |
|
Keyboard hot key commands |
|
KVM Switch Software |
Supported OS |
Windows® and Mac® |
Operating Temperature |
0 – 40 °C (32 – 104 °F) |
Operating Humidity |
Max. 90 % non-condensing |
Dimensions |
Unit: 85 x 58 x 28 mm (3.3 x 2.3 x 1.1 in.) |
|
Integrated Cable: 85 cm (3 ft.) |
|
Toggle switch: 150 cm (5 ft.) |
Weight |
350 g (12.3 oz.) |
Warranty |
2 year limited |
Certifications |
CE, FCC |
Package Contents |
TK-215i, Quick Installation Guide, CD-ROM (Utility & User's Guide) |
-
