Official Partner
Compact CPE Design
The NanoStationM features the CPE design that expanded the global Wireless ISP industry.
Plug and Play Installation
The NanoStation M requires no tools for assembly; only a single wrench is required for pole-mounting.
Versatile Application Use
The NanoStation M can be deployed for Point-to-Point (PtP) bridging, wireless connectivity to a video surveillance system, or use as an airMAX CPE.
Dual Ethernet Connectivity
With software-enabled PoE output, the secondary Ethernet port can power an external device, such as a PoE security camera, for seamless IP video integration.
Advanced Software Technology
Ubiquiti’s airMAX technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
Window/Wall Mounting Kit
Use the NanoStation Mount to quickly mount the NanoStationM on a window or wall. 180° vertical or horizontal adjustment allows for custom positioning.
| Feature | Details |
|---|---|
| Antenna | |
| Antenna gain level (max) | 8 dBi |
| Design | |
| Certification | RoHS |
| Housing material | Plastic |
| Internal | No |
| LED indicators | Yes |
| Product colour | White |
| Features | |
| 2.4 GHz | Yes |
| Ethernet LAN data rates | 10/100 Mbit/s |
| Frequency band | 2.412-2.462 GHz |
| Maximum data transfer rate | 150 Mbit/s |
| Maximum outdoor range | 10000 m |
| Networking standards | IEEE 802.3/IEEE 802.3u |
| Wi-Fi data rate (max) | 150 Mbit/s |
| Legal Information | |
| EU ECCN Code | 5A002 |
| UNSPSC Code | 43222640 |
| US ECCN Code | 5A002 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Operational conditions | |
| Operating relative humidity | 5 - 95 % |
| Operating temperature (T-T) | -30 - 75 °C |
| Package dimensions (verified) | |
| Depth Verified | 9.6 cm |
| Gross Weight Verified | 0.516 kg |
| Height Verified | 8.3 cm |
| Width Verified | 21.8 cm |
| Performance | |
| Built-in processor | Yes |
| Flash memory | 8 MB |
| Internal memory | 32 MB |
| Processor architecture | MIPS 24Kc |
| Processor frequency | 400 MHz |
| Processor model | Qualcomm Atheros |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| AC input voltage | 24 V |
| Input current | 0.5 A |
| Input voltage | 24 V |
| Power consumption (typical) | 5.5 Watt |
| Power over Ethernet (PoE) | Yes |
| Product dimensions | |
| Net Weight (Product, kg) | 0.18 kg |
| Product Depth | 8 cm |
| Product Height | 16.1 cm |
| Product Width | 3.1 cm |
| Technical details | |
| Harmonized System (HS) code | 85176990 |
| Vendor information | |
| Brand Name | Ubiquiti |
| Warranty | 2 Year(s) |
| Categories | |
| Main category | Network |
| Subcategory | Wireless Network |
| Subcategory | Wireless Access Points |
| Description | Downloads |
|---|---|
| Ubiquiti Networks NanoStation M2 150 Mbit/s White Power Over Ethernet (LOCOM2) DataSheet | Downloads |
| Ubiquiti Networks NanoStation M2 150 Mbit/s White Power Over Ethernet (LOCOM2) User Guide | Downloads |
| Ubiquiti Networks NanoStation M2 150 Mbit/s White Power Over Ethernet (LOCOM2) Quick Start Guide | Downloads |
