Incorporating a dish reflector design with proprietary airMAX® ac technology, the PowerBeam™ ac is ideal for CPE deployments requiring maximum performance.
Integrated Radio Design
Ubiquiti’s InnerFeed® technology integrates the radio into the feedhorn of an antenna, so there is no need for cables to connect the radio to the antenna. This improves performance because it eliminates cable losses.
Performance Breakthrough
airMAX® ac products offer improved latency, noise immunity, scalability and significantly increased throughput performance.
Superior Processing
Ubiquiti's airMAX® engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.
Incredible Antenna “Beam” Performance
The form factor of the PowerBeam™ ac features the highest gain for its size. The PowerBeam ac’s excellent beam directivity provides the best performance in high-noise environments.
Advanced Software Technology
Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
Protective Radome
The PowerBeam™ ac PBE-5AC-500 includes a protective radome to shield the radio from nature's harshest elements.
| Features | Description |
|---|---|
| Antenna type | Directional antenna |
| Certification | FCC, IC, CE |
| LED indicators | LAN/Power/WLAN |
| Mounting | Pole |
| Polarization | Dual polarization |
| Product colour | White |
| RoHS compliance | Yes |
| Survival wind speed | 96 km/h |
| Voltage Standing Wave Ratio (VSWR) | 1.5:1 |
| Wind load | 264.6 |
| Legal Information | |
| EU ECCN Code | 5A002 |
| UNSPSC Code | 43221729 |
| US ECCN Code | 5A002 |
| Logistics data | |
| Harmonized System (HS) code | 85177100 |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 70 °C |
| Other features | |
| Dimensions (WxDxH) | 620 x 620 x 386 mm |
| Package dimensions (verified) | |
| Depth Verified | 61 cm |
| Gross Weight Verified | 6.55 kg |
| Height Verified | 32 cm |
| Width Verified | 61 cm |
| Performance | |
| Antenna gain level (max) | 27 dBi |
| Built-in processor | Yes |
| Flash memory | 16 MB |
| Frequency band | 5 GHz |
| Internal memory | 128 MB |
| Internal memory type | DDR2 |
| Processor frequency | 720 MHz |
| Processor model | Atheros MIPS 74Kc |
| Power | |
| Power consumption (max) | 8.5 Watt |
| Product dimensions | |
| Net Weight (Product, kg) | 3.15 kg |
| Product Depth | 31.5 cm |
| Product Height | 52.5 cm |
| Product Width | 52.5 cm |
| Technical details | |
| Harmonized System (HS) code | 85177100 |
| Sustainability certificates | RoHS |
| Vendor information | |
| Brand Name | Ubiquiti |
| Warranty | 2 Year(s) |
| Categories | |
| Main category | Network |
| Subcategory | Wireless Network |
| Subcategory | Passive Antennas |
