Powerful Enterprise Switch Models
The UniFi® Switch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Total non-blocking throughput: up to 26 Gbps for 24-port models and up to 70 Gbps for 48-port models.
Advanced Port Management
Each switch port offers custom settings: port name, PoE, network/VLAN configuration, and operation mode (switching, mirroring, or aggregate).
Optical Fiber Connectivity
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.
Convenient PoE+ Support
The UniFi® Switch features auto-sensing IEEE 802.3af/at and 24V passive PoE to power multiple devices on the network.
Seamless Integration
The UniFi® Switch integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform to create a highly scalable, end-to-end system of network devices across multiple locations — all controlled from a single interface.
| Category | Specifications |
|---|---|
| Mechanical | |
| Dimensions | 485 x 374.6 x 43.7 mm (19.1 x 14.8 x 1.7") |
| Weight | 6.1 kg (13.5 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band, (1) RJ45 Serial port Out-of-Band |
| Networking interface | (48) GbE RJ45 ports, (2) 1G SFP ports, (2) 1/10G SFP+ ports |
| PoE interface | (48) PoE/PoE+ (Pins 1, 2+; 3, 6-), 24V DC passive PoE (Pins 4, 5+; 7, 8-) |
| Total non-blocking throughput | 70 Gbps |
| Switching capacity | 140 Gbps |
| Forwarding rate | 104.16 Mpps |
| Power method | Universal input, 100—240V AC, 50/60 Hz |
| Power supply | AC/DC, internal, 500W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | Excluding PoE output: 64W, Including PoE output: 500W |
| Total available PoE | 500W |
| Max. PoE wattage per port by PSE | 24V Passive PoE: 17W, PoE+: 34W |
| Voltage range PoE mode | 24V Passive PoE: 20–27V, PoE+: 50—57V |
| ESD/EMP protection | Air: ± 24kV, contact: ± 24kV |
| Sound level* | |
| Fan level 0 | 10.7 dBr |
| Fan level 1 | 16.2 dBr |
| Fan level 2 | 19.3 dBr |
| Fan level 3 | 23.6 dBr |
| Background noise level | 27.5 dBa |
| Shock and vibration | ETSI300-019-1.4 Standard |
| Ambient conditions | |
| Operating temperature | -5 to 40° C (23 to 104° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE, Speed/Link/Activity |
| SFP | Speed/Link/Activity |
