8-Port Managed Gigabit Switches
The US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. Its auto-sensing PoE ports deliver up to 15.4W of power per port.
The US-8 is a PoE Powered 8-port gigabit switch with PoE Passthrough. Perfect for cleanly adding Ethernet ports where needed, with passthrough to keep your PoE device powered.
Non-Blocking Throughput
The new 8-port models feature Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps.
Switching Capacity
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.
Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
| Feature | Specification |
|---|---|
| Mechanical | |
| Dimensions | 148 x 100 x 31 mm (5.8 x 3.9 x 1.2") |
| Weight | 432 g (15.2 oz) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) GbE RJ45 ports |
| PoE interface | (4) PoE (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 8 Gbps |
| Switching capacity | 16 Gbps |
| Forwarding rate | 11.9 Mpps |
| Power method | (1) 48V DC, 2A Max. |
| Power supply | External AC/DC adapter: 100-240V AC, 50/60 Hz; 48V DC, 1.25A |
| Supported voltage range | 44–57V DC |
| Max. power consumption | 12W (Excluding PoE output.) |
| Total available PoE | 48W |
| Max. PoE wattage per port by PSE | 15.4W |
| ESD/EMP protection | Air: ± 24kV, contact: ± 24kV |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| Ethernet | Link/Speed/Activity |
| PoE |
