Ubiquiti UniFi AC Mesh Pro Access Point 5 Pack | UAP-AC-M-PRO-5
SKU: UAP-AC-M-PRO-5
£793.13 (Excl. VAT)
- Description
- Specifications
-
Ubiquiti UniFi AC Mesh Pro Access Point 5 Pack
Scalable Enterprise Wi-Fi Management
UniFi is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi AC Mesh APs have a refined industrial design and can be easily installed using the included mounting hardware.Easily accessible through any standard web browser, the UniFi Controller software is a powerful software engine ideal for high-density client deployments requiring low latency and high uptime performance.
Use the UniFi Controller software to quickly configure and administer an enterprise Wi-Fi network – no special training required. RF map and performance features, real-time status, automatic UAP device detection, and advanced security options are all seamlessly integrated.
Features
Save money and save time UniFi comes bundled with a non-dedicated software controller that can be deployed on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service. You also have the option of using the UniFi Cloud Key with built-in software.Powerful HardwareThe UniFi AC Mesh APs feature Wi-Fi 802.11AC with Plug & Play Mesh technology.
Intuitive UniFi Controller Software Configure and manage your APs with the easy-to-learn user interface.
Expandable Unlimited scalability: build wireless networks as big or small as needed. Start with one and expand to thousands while maintaining a single unified management system.
-
Technical Specifications Details Mechanical Dimensions 343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4") Weight 633 g (1.4 lb) Hardware Networking interface (2) GbE RJ45 ports Management interface Ethernet Power method PoE Power supply Gigabit PoE adapter 48V DC, 0.5A* (*5-packs do not come with PoE adapters) Max. power consumption 9W Max. TX power 2.4 GHz 22 dBm 5 GHz 22 dBm 6 GHz - MIMO 2.4 GHz 3 x 3 5 GHz 3 x 3 6 GHz - Throughput rate 2.4 GHz 450 Mbps 5 GHz 1300 Mbps 6 GHz - Antenna gain 2.4 GHz 8 dBi 5 GHz 8 dBi 6 GHz - Button Factory reset Mounting Wall, pole (Included) Ambient operating temperature -40 to 70° C (-40 to 158° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g/n/ac Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) VLAN 802.1Q BSSID Up to 4 per radio Advanced QoS Per-user rate limiting Guest traffic isolation Supported Power save Supported WMM Voice, video, best effort, and background Concurrent clients 250+ Supported Data Rates (Mbps) 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) 802.11ac 6.5 Mbps to 1300 Mbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80)
