Layer 2, 8 x RJ45, 4 x 802.3at PoE+, Gigabit Ethernet, 99.6 x 163.7 x 31.7 mm
The USW-Lite-8-PoE is a fully managed Layer 2 switch with eight Gigabit Ethernet ports for your RJ45 Ethernet devices. Four ports also offer auto-sensing 802.3at PoE+ that provide up to a total PoE wattage of 52W for UniFi Access Points or other PoE devices.
Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-Lite-8-PoE offers Layer 2 switching protocols and features. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
| Technical Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 99.6 x 163.7 x 31.7 mm (4 x 6.4 x 1.3") |
| Weight | 295 g (10.4 oz) |
| Enclosure material | Polycarbonate |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) GbE RJ45 ports |
| PoE interface | (4) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total non-blocking throughput | 8 Gbps |
| Switching capacity | 16 Gbps |
| Power method | 54V DC, 1.1A power adapter |
| Power supply | 54V, external, 60W |
| Supported voltage range | 50—57V DC |
| Max. power consumption | 8W (Excluding PoE output) |
| Total available PoE | 52W* |
| Max. PoE wattage per port by PSE | PoE+: 30W |
| Button | Factory reset |
| Ambient operating temperature | -15 to 40° C (5 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features | |
| Layer 2 features | IGMP snooping |
| STP / RSTP with priorities and port-level disable | |
| Port isolation | |
| Storm control | |
| Voice VLAN | |
| Port mirroring | |
| LACP port aggregation | |
| Multicast / broadcast rate limiting | |
| MAC address blocking | |
| Flow control | |
| 802.1X control | |
| Jumbo frames | |
| Proprietary loop protection | |
| DHCP snooping / guarding | |
| Egress rate limit | |
| LLDP-MED | |
| Port restricted by MAC | |
| Device isolation with ACLs | |
| Layer 3 features | – |
| LEDs | |
| System | Status |
| Ethernet | PoE |
| Speed/link/activity | |
| PoE | Link/activity |
| Application Requirements | |
| UniFi Network | Version 7.2.94 and later |
