About This Product
The Ubiquiti USW-Pro-8-PoE UniFi 8-Port Layer 3 Managed Desktop Gigabit PoE+ Switch stands out as an advanced networking solution, boasting eight (8) ports and powerful Layer 3 management capabilities. Equipped with both PoE+ and PoE++ output, this desktop Gigabit switch ensures seamless and efficient connectivity for your network infrastructure.
Unleash Network Potential
The USW-Pro-8-PoE combines eight (8) ports and robust Layer 3 management capabilities. This desktop Gigabit switch features both PoE+ and PoE++ outputs to deliver seamless and efficient connectivity for your network infrastructure. With six (6) 1GbE PoE+ ports and two (2) 1GbE PoE++ ports supporting high-power devices, along with two (2) 10G SFP+ ports for high-speed connections, this switch ensures versatility and adaptability. Its total PoE availability of 120W guarantees ample power for connected devices, making it an ideal choice for businesses seeking a reliable and advanced networking solution.
Compact Powerhouse Switch
Boasting a sleek desktop form factor, the switch's mechanical attributes make it an ergonomic choice. The plastic and metal enclosure, along with a plastic mount, enhances its durability. Ideal for a variety of applications, the USW-Pro-8-PoE-120W is a reliable and certified solution for modern network setups.
| Category | Details |
|---|---|
| Mechanical | |
| Dimensions | 200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
| Weight | 2.1 kg (4.6 lb) |
| Enclosure materials | Polycarbonate, metal |
| Mount material | Polycarbonate |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (8) GbE RJ45 ports |
| (2) 10G SFP+ ports | |
| PoE interface | (6) PoE/PoE+ |
| (2) 60W PoE++ | |
| Total non-blocking throughput | 28 Gbps |
| Switching capacity | 56 Gbps |
| Power method | Universal input, 100—240V AC, 2A Max. |
| Power supply | AC/DC, internal |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 30W (Excluding PoE output) |
| Total available PoE | 120W |
| Max. PoE wattage per port | PoE: 15W |
| PoE+: 30W | |
| PoE++: 60W | |
| Voltage range PoE mode | PoE: 44—57V |
| PoE+: 50—57V | |
| PoE++: 50—57V | |
| LCM display | (1) 1.3" touchscreen |
| LEDs | RJ45 ports: link/activity |
| Button | Factory reset |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features | |
| Layer 2 features | IGMP snooping |
| STP / RSTP with priorities and port-level disable | |
| Port isolation | |
| Storm control | |
| Voice VLAN | |
| Port mirroring | |
| LACP port aggregation | |
| Multicast / broadcast rate limiting | |
| MAC address blocking | |
| Flow control | |
| 802.1X control | |
| Jumbo frames | |
| Proprietary loop protection | |
| DHCP snooping / guarding | |
| Egress rate limit | |
| LLDP-MED | |
| Port restricted by MAC | |
| Device isolation with ACLs | |
| Layer 3 features | DHCP for locally-managed networks |
| DHCP relay | |
| Inter-VLAN routing between networks on same switch | |
| Static routing between local networks | |
| Application Requirements | UniFi Network Version 7.5.176 and later |
