Vestel 65" IFD65TH752/3 Interactive Display

High-Brightness 700 cd/m2 - 24/7 Operation Hours

• Description
• Specifications
• Warranty
• Downloads

• Different Sizes for various classrooms

  Available in a variety of large screen sizes, the IFD range gives customers the options to choose exactly what they need for their room size.



  Wireless Presentation

  Teachers, students or any user can share their screen efficiently and conveniently in the classroom or meeting room via EShare application. This application can connect any operating system and show up to 4 different screen at the same time.



  Ease of use with Android

  Android gives teachers one touch access for lessons and collaboration tools including whiteboard, web browser, apps library, and native wireless screen sharing.



  Palm Erase

  Automatic palm erasing function allows teachers and students to simplify the white board experience with smooth writing and erasing.



• Feature	Value
  Screen Size	65"
  Panel Technology	Direct-Type LED
  Backlight Type	350 cd/m²
  Native Resolution	UHD: 3840 x 2160 - HDR10
  Contrast Ratio (typical)	1200:1
  Dynamic Contrast Ratio	35000:1
  Panel Life Time (Min.)	30.000 hrs
  Life Time (typical)	8 ms
  Active Area (H x V)	1428 x 804 mm
  Pixel Pitch (H x V)	0.372 x 0.372 mm
  PPI (pixel per inch)	68
  Viewing Angle	178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
  Color Value	1.07 B (10-bit)
  Screen Treatment	2H
  Haze Level	8%
  Refresh Rate	60 Hz
  Front Type	Touch Bezel
  Orientation	Horizontal
  Operation Hours	16/7 Panel
  Area of Usage	Indoor
  Built-in System	Mainboard Model - MB135VS
  Monitor Connectivity	RGB Input - VGA(DE-15F), RGB Output - N/A, Video Input - 3xHDMI2.0, 2xUSB2.0, USB2.0(Internal), 1xMicroSD, Video Output - HDMI2.0, Audio Input - Line In L/R, Audio Output - Headphone, Optic SPDIF, External Control - RS232(DE-9F), 2*Ethernet(RJ45), Service(RJ12), External Sensor - RJ12
  Touch Interactivity	Type of Touch Technology - Infrared (IR) Tech. - 10 Points, Sensitivity - Any touch with finger, gloved hand or pointer, Connectivity - HID, TUIO, Flash
  Compatibility	Windows®7,Windows®8, Windows®10, Vista, XP, Mac® OS, Linux, Android
  Orientation	Landscape support
  Calibration	No need
  Accuracy	90% <
  Reporting Rate	up to 450 fps
  Glass Type	Anti Glared (AG), Tempered
  Frame Rate	up to 450 fps
  Communication	USB 2.0
  Power Supply Mode	USB
  Supply Voltage	DC 5V +/- 5%
  Average Current	< 400 mA
  Response Time	< 10 ms
  Touch Accuracy	+/- 2 mm (over 90% area)
  Touch Durability	Unlimited
  HID Compatibility	Yes USB
  Object Sizes for Touch	5 mm
  Product Dimensions (WxDxH)	1507 x 118 x 882 mm
  Package Dimensions (WxDxH)	1756 x 265 x 1100 mm
  Product Weight	38.6 kg
  Package Weight	48 kg
  Vesa Mounting	400 x 400 mm
  Bezel Width	B:38
  Operating Temperature	+40°C / 0°C
  Operating Humidity	90%
  Power Supply	110 VAC - 240 VAC
  Power Consumption	Typical - 240 W, Maximum - 200 W, Deep Standby ≤ 0.5W
  Main Features	USB-Autoplay, Auto-switch on Failover, Control Button Lock, HDMI Wake-Up
  Mechanical Features	IR Touch, Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying handles, Detachable logo positioning, Cable Holders
  Optional Features	OPS Compliance
  Speaker	2 x 8 W
  Accessory	QSG, Instruction Book, Power Cord, Remote Control, RC Battery, Mounting Kit, Extension Brackets, IR Extender Cable
  Certification	Safety - YES, EMC - YES, CE - YES, Reability Approval - YES



• Warranty Period: 3-year on-site swap out
  UK Mainland De-Install/Re-Install Warranty.

  Vestel Digital Signage Displays offer a large range of large format displays for use in commercial applications from reception, and conference rooms to classrooms backed by a 3 Year On-Site UK Mainland Warranty.

  They have displays operating from 16 hours per day to non-stop usage displays ideal for the transport industry.

  If you need to discuss your warranty period, please contact us.

• Document Type	Download Link
  Specification Sheet	Downloads
  Commercial Datasheet	Downloads
  Detailed Mechanical Drawing (1)	Downloads
  Detailed Mechanical Drawing (2)	Downloads
  Control Document	Downloads
