Vestel IFM75TH6534

75" Interactive Flat Panel Display for Education

10 Points Multi Touch

• Description
• Specifications
• Warranty

• Simultaneous Smooth writing Multi - Touch

  10 point touch support detects multiple touch points, enhancing the possibility of collaborative work. The screens also provide a precise and user friendly writing experience with its smooth surface.



  HDR10 & 4K HDMI @60Hz

  Displays supporting HDR10 allows HDR based content to be shown, giving a brighter and more dynamic picture. This is further enhanced due to the support of 4K 60Hz, allowing ultra sharp, smooth Video content to be presented.



  Anti Glare Tempered Glass

  Prevents light reflection and provides smooth touch performance with anti glare technology. Robust design with toughened glass material to avoid any damage to the screen



  Collaborate, Annotate with Oktopus

  Collaborate: View lessons, respond, share annotations, and take notes using any tablet or laptop Anntate: Works over browser content & existing applications Poll: Pose questions and gain immediate participant feedback, displaying results instantly.



• Parameter	Specification
  Screen Size	75"
  Panel Technology	IPS
  Backlight Type	Direct-Type LED
  Brightness (typical)	400 cd/m²
  Native Resolution	UHD: 3840 x 2160 - HDR10
  Contrast Ratio (typical)	1200:1
  Dynamic Contrast Ratio	40000:1
  Panel Life Time (Min.)	30000 Hrs
  Panel Life Time (Average)	8 ms
  Active Area (H x V)	1650 x 928 mm
  Pixel Pitch (H x V)	0.429 x 0.429 mm
  PPI (pixel per inch)	59
  Viewing Angle	178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
  Color Value	1.07 B (10-bit)
  Screen Treatment	2H
  Haze Level	8%
  Refresh Rate	60 Hz
  Front Type	Touch Bezel Type
  Orientation	Horizontal
  Operation Hours	16/7 Panel
  Area of Usage	Indoor
  Built-in System	Mainboard Model 17MB135VS
  Monitor Connectivity	RGB Input VGA(DE-15F), RGB Output N/A, Video Input 4xHDMI2.0, 2xUSB2.0, USB2.0(Internal), Video Output HDMI2.0, Audio Input Line In L/R, Audio Output Headphone, Optic SPDIF, External Control RS232(DE-9F), Ethernet(RJ45), Service(RJ12), External Sensor RJ12
  Touch Interactivity	Type of Touch Technology Infrared (IR) Technology, Continuous Touch Points 10 Points, Sensitivity Any touch with finger, gloved hand or pointer, Connectivity HID, TUIO, Flash, Compatibility Windows®7,Windows®8, Windows®10, Vista, XP, Mac® OS, Linux, Android, Orientation Landscape support, Calibration No need, Accuracy %90 <, Reporting Rate Up to 450 fps, Glass Type Anti Glared (AG), 4mm Tempered, Frame Rate up to 450 fps, Communication USB 2.0, Power Supply Mode USB, Supply Voltage DC 5V +/- 5%, Average Current <400mA, Response Time <10ms, Touch Accuracy +/-2mm (over 90% area), Touch Durability Unlimited, HID Compatibility Yes USB, Object Sizes for Touch 5mm
  Mechanical	Product Dimensions (WxDxH) 1731 x 119 x 1008 mm, Package Dimensions (WxDxH) 1990 x 265 x 1227 mm, Product Weight 58.3 kg, Package Weight 72.3 kg, Vesa Mounting 600 x 400 mm, Bezel Width B:38
  Environmental Conditions	Operating Temperature +40°C / 0°C, Operating Humidity 90%
  Power	Power Supply 110 VAC - 240 VAC, Power Consumption Typical 240 W, Maximum 320 W, Deep Standby ≤0.5W
  Features	Main Features USB-Autoplay, Auto-switch on Failover, Control Button Lock, HDMI Wake-Up, Mechanical Features IR Touch, Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying handles, Detachable logo positioning, Cable Holders
  Optional Features	OPS Compliance
  Speaker	2 x 12 W
  Accessory	Standard QSG, IB, Power Cord, Remote Control Unit, RC Battery, Mounting Kit, Extension Brackets, IR Extender Cable
  Certification	Safety YES, EMC YES, CE YES, Reability Approval YES



• Warranty Period: 3-year on-site swap out
  UK Mainland De-Install/Re-Install Warranty.

  Vestel Digital Signage Displays offer a large range of large format displays for use in commercial applications from reception, and conference rooms to classrooms backed by a 3 Year On-Site UK Mainland Warranty.

  They have displays operating from 16 hours per day to non-stop usage displays ideal for the transport industry.

  If you need to discuss your warranty period, please contact us.
