VESTEL RNB Series WY55B/2H

55" LCD Video Wall Display

• Description
• Specifications
• Warranty
• Downloads

• Remote Control

  Any number of Vestel VWs can be remotely controlled over RS232 Loop configuration. This eases the installation process of the VW displays, by controlling and configuring all the units via PC at the same time.



  Video Wall Controller Tool

  This new software puts ease of use for Video walls by reaching Auto/Manual parameter setup on each/multi/all selected display, Remote control by IR Simulation or LAN/RS232 Control and Video and Picture rotation for Informal Layouts on one software.



  Eco Design

  Vestel VWs are made to operate at lower energy usage while performing at high levels. Also, Vestel follows the worldwide standards for limiting harmful substances and eliminating waste products.



  Wall Mount Option

  Vestel presents the Wall Mount option for landscape usage. Vestel Wall mounts are able to move in all possible directions making it easy to place and align the bezels perfectly.



  Longer Stability

  Vestel VWs are able to tolerate longer hours of operation, equipped with pixel-shifting feature to prevent a fixed image from sticking on the screen.



  Great Picture with Different Brightness Option

  Create a seamless and striking visual experience with our Video Wall displays. Offering 500-700 Nit options, our monitors can display your content in picture perfect resolution, whatever the lighting conditions.



  Higher Visibility

  Vestel panels come with anti-reflective treatment to decrease glare under strong light exposure. Aside from glare protection, 700 Nits VWs ensure high visibility even under high levels of ambient light.



  White color Calibration

  For managing color uniformity with highest performance, color calibration has been made available for on-site maintenance. This results in a more uniform colour distribution and minimised colour distortion.



  Real Ultra HD Resolution

  With our videowall you can deliver real UHD resolution in a 2 x 2 arrangement. The videowalls are capable of combining 4 x FHD displays to create a single Real UHD image without the need of external processing or scaling devices.



  Daisy Chain with Display Port or HDMI Option

  Reduce cost and maximize video quality with Vestel’s Video Wall displays, using Display Port 1.2a-enabled or HDMI 2.0 screens, Vestel offers a daisy chain solution that cuts the cost of installation, cabling and maintenance. This daisychained monitor set up also ensures a more immersive viewing experience.



  Ultra / Extra / Razor Narrow Bezel

  Reducing the gap between each display area. Vestel’s designs help create an almost seamless overall on screen image with 3.5 mm, 1.8 mm and less than 1 mm combined bezels.



  Landscape and Portrait Mode

  Our Video Walls can be displayed in either landscape or portrait mode. Vestel’s 24/7 professional displays not only allow for installation in portrait mode, but also for additional display protection. The displays’ Pixel Shifting feature reduces the risk of any on-screen imagery sticking.


  IPS Reliability

  Vestel IPS displays present the most clear image in both landscape and portrait orientation without any image distortion. IPS also provides 178o ultra-wide viewing angle, displaying the most accurate image quality.



• Panel
  Screen Size	55"
  Panel Technology	IPS
  Backlight Type	DLED
  Brightness (typical)	500 cd/m2
  Native Resolution	1920 x 1080 (16:9) - FHD
  Contrast Ratio (typical)	1200:1 (typ.)
  Dynamic Contrast Ratio	50000:1
  Life Time (typical)	60000 Hrs
  Response Time (typical)	8 ms
  Active Area (H x V)	1209.6 x 680.4 mm
  Pixel Pitch (H x V)	0.630 x 0.630 mm
  Viewing Angle	178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
  Color Value	1.07 B (10-bit)
  Screen Treatment	2H
  Haze Level	28%
  Refresh Rate	60 Hz
  Front Type	Ultra narrow bezel
  Orientation	Landscape/Portrait
  Operation Hours	24/7
  Area of Usage	Indoor
  Built-in System
  Mainboard Model	17MB135VS
  Monitor Connectivity
  RGB Input	VGA (DE-15F)
  Video Input	2xHDMI2.0, 2xUSB2.0
  Video Output	1xHDMI2.0
  Audio Input	Line In L/R
  Audio Output	Headphone, Optic SPDIF
  External Control	RS232(DE-9F), Ethernet(RJ45), Service(RJ12)
  External Sensor	RJ12
  Environmental Conditions
  Operating Temperature	+50°C / 0°C
  Operating Humidity	%90
  Power
  Power Supply	110 VAC - 240 VAC
  Power Consumption
  Typical	138 W
  Maximum	260 W
  Deep Standby	0.5W<
  Mechanical Features
  Size	1213.4 (W) x 114.39 (D) x 684.2(H) mm
  Shipping Size	1366 (W) x 277 (D) x 836 (H) mm
  Weight (kg)	37.7 kg
  Shipping Weight	45.1 kg
  Vesa Mounting Size	600 (W) x 400 (H) mm M8
  Bezel Width	3.8 mm (active-to-active), 3.5 mm (bezel-to-bezel)
  Features
  Main Features	Videowall setup with Daisy-Chain, Open Content Management Support, Manual Fine Color Calibration, Videowall Scheduler, Auto-Launch, Auto-switch on Failover, Panel Lock
  Mechanical Features	ON/OFF Button, IR Extender, Carrying Handles, OPS option (with a costup)
  Speaker	N/A
  Accessory	Standard
  QSG	IB
  Power Cord	Remote Control
  RC Battery	Display Port Cable
  USB to Rs232 Converter
  Mounting Kit	Standard
  Certification
  Safety	Yes
  EMC	Yes
  CE	Yes



• Warranty Period: 3-year on-site swap out
  UK Mainland De-Install/Re-Install Warranty.

  Vestel Digital Signage Displays offer a large range of large format displays for use in commercial applications from reception, and conference rooms to classrooms backed by a 3 Year On-Site UK Mainland Warranty.

  They have displays operating from 16 hours per day to non-stop usage displays ideal for the transport industry.

  If you need to discuss your warranty period, please contact us.

• Document Type	Download Link
  Specification Sheet	Downloads
  Commercial Datasheet	Downloads
  Detailed Mechanical Drawing	Downloads
  Wall Mount Drawing	Downloads
  Installation Manual	Downloads
