Vestel STM43UH82/4

43" Professional Digital Signage Display

• Description
• Specifications
• Warranty
• Downloads

• Daisy Chain
  The display can mirror the content (to another display) into its display port out coming from its display port in. This set up creates a daisy chain like structure allowing for monitors to be set up as Video Wall mode.

  Display Control
  Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in realtime

  Usb Auto-Play
  You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.

  Scheduler
  Digital Signage Monitor Software allows many important features such as Scheduler. Scheduler sets your display turn on/off time easily and lets you not to worry aboutthe status of your displays in any time.

  Signal Failover
  Our SoC Software has a protection for “No Signal” scenario. If the USB is unplugged after your content is set to be displayed with USB, the display will either show your customized banner or search for any other signal from other sources (HDMI, Display Port, etc.). This failover protection is constructed for higher user experience.

  HDMI Wake Up
  To maximize the user experience while using external video devices such as mediaplayers, display controllers or PCs, all our devices have HDMI Wakeup feature ready to turn on/off the display by simply pluging/unplugging the HDMI cable.



• Panel
  Screen Size (in)	43"
  Panel Technology	IPS
  Backlight Type	Direct-Type
  Brightness (typical)	400 cd/m²
  Native Resolution	1920 x 1080
  Contrast Ratio (typical)	1200:1
  Dynamic Contrast Ratio	40000:1
  Panel Life Time (Min.)	50000 Hrs
  Response Time (typical)	8 ms
  Active Area (H x V, mm)	941 x 530
  Viewing Angle (Vertical/Horizontal)	178° / 178°
  Color Value (Bit Depth)	16.7 M
  Screen Treatment	3H Haze Level 1%
  Refresh Rate	60 Hz
  Front Type	Ultra Narrow Bezel
  Orientation	Horizontal
  Operation Hours	16/7
  Area of Usage	Indoor

  Built-in System
  Mainboard Model	17MB135VS

  Monitor Connectivity
  RGB Input	VGA(DE-15F)
  RGB Output	N/A
  Video Input	4xHDMI2.0, 2xUSB2.0, USB2.0(Internal)
  Video Output	HDMI2.0
  Audio Input	Line In L/R
  Audio Output	Headphone, Optic SPDIF
  External Control	RS232(DE-9F), Ethernet(RJ45), Service(RJ12)
  External Sensor	RJ12

  Mechanical
  Product Dimensions (WxDxH, mm)	966 x 106 x 557
  Package Dimensions (WxDxH, mm)	1050 x 178 x 718
  Product Weight	10.3 kg
  Package Weight	13.65 kg
  VESA Mounting	200 x 200 mm - M6
  Bezel Width (B/T/L/R, mm)	13/9/10/10

  Environmental Conditions
  Operating Temperature	0-40°C
  Operating Humidity	10-90%

  Power
  Power Supply	110 VAC - 240 VAC - 50/60 Hz
  Typical Power Consumption	96 W
  Deep Standby	≤0.5 W

  Features
  Main Features	Open Content Management Support, Scheduler, USB-Autoplay, AutoLaunch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock
  Mechanical Features	Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying slots, Detachable logo positioning, Internal usb cover, Cable Holder
  Optional Features	OPS Compliance, IR Overlay Touch
  Compliance	Speaker 2 x 8 W

  Accessory
  Standard	QSG, IB, Power Cord, Remote Control, RC Battery, Mounting Kit, IR Extender Cable

  Certification
  Safety	YES
  EMC	YES
  CE	YES

• Warranty Period: 3-year on-site swap out
  UK Mainland De-Install/Re-Install Warranty.

  Vestel Digital Signage Displays offer a large range of large format displays for use in commercial applications from reception, and conference rooms to classrooms backed by a 3 Year On-Site UK Mainland Warranty.

  They have displays operating from 16 hours per day to non-stop usage displays ideal for the transport industry.

  If you need to discuss your warranty period, please contact us.

• Document Type	Download Link
  Specification Sheet	Downloads
  Commercial Datasheet	Downloads
  Detailed Mechanical Drawing	Downloads
  Wall Mount Drawing	Downloads
