Vestel UHM75UH83B/4 - 75" 4K Professional Digital Signage Displays
SKU: UHM75UH83B/4
£772.00 (Excl. VAT)
Vestel UHM75UH83B/4 - 75" Digital Signage Displays
End Of Line - Replaced with XN75D-4H
- Descriptions
- Specifications
- Warranty
- Downloads
-
HDMI Wake UpTo maximize the user experience while using external video devices such as mediaplayers, display controllers or PCs, all our devices have HDMI Wakeup feature ready to turn on/off the display by simply pluging/unplugging the HDMI cable.
Source SwitchingIt is made available to set any Source on startup of the display. It can also be switched on any other signal source using scheduler and failover scenarios. This lets the users to freely control the process of their requirements allowing best user experience.
Pixel ShiftingPixel Shifting is designed to be activated inside the SoC in order to prevent for potential risk of image sticking, caused by constant content. With this feature turned on, pixels on the screen will move in an interval while causing no interference of visual experience.
SchedulerDigital Signage Monitor Software allows many important features such as Scheduler. Scheduler sets your display turn on/off time easily and lets you not to worry about the status of your displays in any time.
DAP (Dolby Audio Processing) TechnologyOur displays provide a comprehensive sound performance by using Dolby’s latest technology DAP. With embedded DAP Technology, superior sound performance achieves by intelligent audio equalizing, dialog enhancements and surround sound upmixing.
HDR10 & 4K HDMI @60HzBy HDR10 compatibility, customers can guarantee that all featured content meets HDR guidelines and reaches superior picture quality as clearly and brightly as possible. Different than many products in the market, 4K content over HDMI source is supported at 60Hz.
Embedded CMSEmbedded content management program which supports playback library, ready templates and scheduler. With its simple and intuitive menus and layout options, it is effective for small and medium enterprises to make easy content management.
Auto LaunchWe have made it easy to give any HTML5-based application link to the display within the SoC software. Upon this, the display will start with the given link. The application can either be an offline or an online application, allowing the customers to execute their own application.
SoCHTML-5 based applications can be developed to work directly within the SoC platform of our displays. The displays are capable of working in either online or offline mode.
Menu LockThe menu lock feature allows the displays menus to be locked after installation in order to prevent any changes or access whilst being used in a public area.
Wireless DisplayUsing either Microsoft Wireless Display Adaptor or Android Screen Sharing functions on Windows and Android devices, you can mirror screen to the display using embedded wireless display capabilities without using any external devices or cables.
Display Control over RS232 and LANOur platform allows users to control their displays, using a large range of commands through either a Local Area Network or direct RS232 Serial connection.
-
Panel UHM75UH83B/4
Screen Size 75" Backlight Type Direct-Type LED Brightness (typical) 400 cd/m² Native Resolution UHD: 3840 x 2160 - HDR10 Contrast Ratio (typical) 1200:1 Dynamic Contrast Ratio 40000:1 Panel Life Time (Min.) 30000 Hrs Response Time (typical) 8 ms Active Area (H x V) 1650 x 928 mm Pixel Pitch (H x V) 0.429 x 0.429 mm PPI (pixel per inch) 59 Viewing Angle 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 Color Value 1.07 B (10-bit) Screen Treatment 2H Haze Level 3% Refresh Rate 60 Hz Front Type Ultra Narrow Bezel Orientation Horizontal Operation Hours 16/7 Area of Usage Indoor Built-in System Mainboard Model 17MB135VS Monitor Connectivity RGB Input VGA(DE-15F) RGB Output N/A Video Input 4xHDMI2.0 (HDCP2.2), 2xUSB2.0, USB2.0(Internal) Video Output HDMI2.0 Audio Input Line In L/R Audio Output Headphone, Optic SPDIF External Control RS232(DE-9F), Ethernet(RJ45), Service(RJ12) External Sensor RJ12 Mechanical Product Dimensions (WxDxH) 1684 x 100 x 967 mm Package Dimensions (WxDxH) 1948 x 210 x 1170 mm Product Weight 37.2 kg Package Weight 50.2 kg Vesa Mounting 600 x 400 mm - M6 Bezel Width B:21 Environmental Conditions Operating Temperature 0-40°C Operating Humidity 10-90% Power Power Supply 110 VAC - 240 VAC - 50/60 Hz Power Consumption Typical: 240 W Maximum Maximum: 320 W Deep Standby ≤0.5 W Features Main Features Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, OSD Rotation, NoSignalPowerOff, Screen Saver, Pixel shift, Scheduler, Videowall support, remote control via LAN, Real Time Clock -
Warranty Period: 3-year on-site swap out
UK Mainland De-Install/Re-Install Warranty.
Vestel Digital Signage Displays offer a large range of large format displays for use in commercial applications from reception, and conference rooms to classrooms backed by a 3 Year On-Site UK Mainland Warranty.
They have displays operating from 16 hours per day to non-stop usage displays ideal for the transport industry.
If you need to discuss your warranty period, please contact us. -
Description Downloads Specification Sheet Download Commercial Datasheet Download Detailed Mechanical Drawing Download Detailed Mechanical Drawing Download RS232 Control Document Download Wall Mount Drawing Download
