| Display Size (in.): |
24 |
| Viewable Area (in.): |
23.6 |
| Panel Type: |
VA Technology |
| Resolution: |
1920 x 1080 |
| Resolution Type: |
FHD |
| Static Contrast Ratio: |
3,000:1 (typ) |
| Dynamic Contrast Ratio: |
20M:1 |
| Light Source: |
LED |
| Brightness: |
250 cd/m² (typ) |
| Colors: |
16.7M |
| Colour Space Support: |
8 bit (6 bit + Hi-FRC) |
| Aspect Ratio: |
16:9 |
| Response Time |
|
| Typical GTG: |
7ms |
| GTG w/OD: |
7ms |
| Typical Tr+Tf: |
25ms |
| Viewing Angles |
|
| Horizontal: |
178º |
| Vertical: |
178º |
| Backlight Life (Hours) |
40000 Hrs (Min) |
| Curvature: |
Flat |
| Refresh Rate (Hz): |
75 |
| Blue Light Filter: |
Yes |
| Flicker-Free: |
Yes |
| Colour Gamut: |
NTSC: 72% size (Typ) |
|
sRGB: 104% size (Typ) |
| Pixel Size: |
0.272 mm (H) x 0.272 mm (V) |
| Touch Screen: |
IR, 10-point multi-touch |
| Surface Treatment: |
Glossy, Hard Coating (7H) |
| Cover Glass Thickness: |
1.85mm |
| Compatibility |
|
| PC Resolution (max): |
1920x1080 |
| Mac® Resolution (max): |
1920x1080 |
| PC Operating System: |
Windows 10/11 certified; macOS tested |
| Mac® Resolution (min): |
1920x1080 |
| Connector |
|
| VGA: |
1 |
| USB 2.0 Type A: |
2 |
| USB 2.0 Type B: |
1 |
| 3.5mm Audio In: |
1 |
| 3.5mm Audio Out: |
1 |
| HDMI 1.4: |
1 |
| DVI-D: |
1 |
| Power in: |
3-pin Socket (IEC C14 / CEE22) |
| Audio |
|
| Internal Speakers: |
2Watts x2 |
| Power |
|
| Eco Mode (Conserve): |
11.5W |
| Eco Mode (optimized): |
13.5W |
| Consumption (typical): |
15.5W |
| Consumption (max): |
16.5W |
| Voltage: |
AC 100-240V, 50/60 Hz |
| Stand-by: |
0.5W |
| Power Supply: |
Internal |
| Additional Hardware |
|
| Kensington Lock Slot: |
1 |
| Cable Organisation: |
Yes |
| Controls |
|
| Physical Controls: |
1, 2, Up, Down, Power |
| On Screen Display: |
Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Colour Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall |
| Operating Conditions |
|
| Temperature: |
32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing): |
20% to 90% |
| Wall Mount |
|
| VESA Compatible: |
100 x 100 mm |
| Input Signal |
|
| Frequency Horizontal: |
RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz, DisplayPort (v1.2): 15 ~ 82KHz |
| Frequency Vertical: |
RGB Analog: 50 ~ 76Hz, HDMI (v1.4): 50 ~ 76Hz, DisplayPort (v1.2): 50 ~ 76Hz |
| Video Input |
|
| Digital Sync: |
TMDS - DVI-D, TMDS - HDMI (v1.4) |
| Analog Sync: |
Separate/Composite/SOG - RGB Analog |
| Ergonomics |
|
| Tilt (Forward/Back): |
22º / 38º |
| Weight (imperial) |
|
| Net (lbs): |
11.5 |
| Net Without Stand (lbs): |
10.3 |
| Gross (lbs): |
15.4 |
| Weight (metric) |
|
| Net (kg): |
5.2 |
| Net Without Stand (kg): |
4.7 |
| Gross (kg): |
7 |
| Dimensions (imperial) |
|
| Packaging (in.): |
25.4 x 16.6 x 6.5 |
| Physical (in.): |
22.5 x 13.7 x 4 |
| Physical Without Stand (in.): |
22.5 x 13.7 x 2.4 |
| Dimensions (metric) |
|
| Packaging (mm): |
645 x 422 x 166 |
| Physical (mm): |
571 x 348 x 101 |
| Physical Without Stand (mm): |
571 x 348 x 61 |
| General |
|
| Regulations: |
cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, BSMI, RCM, GEMS, VCCI, PSE, BIS, CCC, China RoHS, China Energy Label, CECP |
| PACKAGE CONTENTS |
|
| TD2423 x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v2.0; Male-Male) x1, Audio Cable (Male-Male) x1, Quick Start Guide x1 |
|
| Recycle/Disposal: |
Please dispose of in accordance with local, state or federal laws. |
| Warranty: |
*Warranty offered may differ from market to market |
| Power Management: |
Energy Star standards, EPEAT |
