| Panel Size | 75" | Panel Type | TFT LCD Module with DLED Backlight |
| Display Area | 1650.24mm(H) x 928.26mm(V), 74.6" diagonal | Aspect Ratio | 16:9 |
| Resolution | UHD 3840 x 2160 | Colors | 1.07B colors, 8bit+FRC |
| Brightness | 450 nits | Contrast Ratio | 5000:1 max. with DCR enabled |
| Response Time | 6.5ms | Viewing Angles | H = 178°, V = 178° typ. |
| Backlight Life | 50,000 Hours | Surface Treatment | Hardness: 9H, Anti-glare coating |
| Orientation | Landscape | Processor | Octa-Core CPU |
| RAM | 8GB | Storage | 128GB |
| Touch Type / Tech | Ultra Fine Touch Technology, IR Recognition | Touch Resolution | 32767 x 32767 |
| Touch Point | Up to 64 points of touch | Palm Rejection | Yes |
| HDMI Input | x3, Front x1: HDMI 2.1 4K@60Hz with CEC; Rear x2: HDMI2.1 4K@60Hz with CEC, ARC x1 + HDMI2.1 4K@60Hz with CEC x1 | RGB / VGA Input | x1 |
| DisplayPort Input | x1 | Audio Input | x1 |
| RS232 Input | x1 | SD / SDHC | x1 TF Card Slot, Micro SD |
| OPS | x1 PC Slot | HDMI Output | x1, HDMI 2.1 4K@60Hz |
| Audio Output | x1, Line out | SPDIF Output | x1, Optical |
| RJ45 LAN | x2 | USB Type-A | x5, Front x2 and Rear x2 with USB3.2 Gen 1, all support SmartPort USB; Rear x1 with USB 2.0 for system update |
| USB Type-B | x2, Front x1 and Rear x1 with USB 3.2 Gen 1 connectors, Touch 1 with 3.2 data and Touch 2 with 2.0 data | USB Type-C | x2, Front x1 with USB 3.2 Gen 1, DP1.2, Ethernet 100M, PD 65W; Rear x1 with USB 3.2 Gen 1, DP1.2, Ethernet 100M, PD 15W |
| Speakers | 20W x 2 Front soundbar | Embedded OS | EDLA-Certified with Android 16 |
| Basic Annotation Software | myViewBoard for Android | Pro Annotation Software | myViewBoard for Windows, embedded in VPC |
| Wireless Presentation | AirSync | Device Management | Manager |
| ViewSonic Launcher | Yes | All-in-one USB Port | USB 3.2 Gen 1 SmartPort USB to all channels |
| LAN Sharing | 10/100/1000M, USB Type-C 10/100, Android & PC 10/100/1000 | Light Sensor | Yes |
| PIR Sensor | Yes | Power Voltage | 100-240VAC +/- 10% Wide Range |
| Power Consumption | On: 92.44 W; Off: <0.5 W | Wall Mount | VESA 800 mm x 400 mm |
| Operating Temperature | 0°C to 40°C | Operating Humidity | 20% ~ 80% RH Non-Condensing |
| Physical Dimensions | 67.28 x 40.16 x 3.87 in / 1709 x 1020 x 98.2 mm | Packaging Dimensions | 72.95 x 44.88 x 6.93 in / 1853 x 1144 x 176 mm |
| Net Weight | 85.76 lb / 38.9 kg | Gross Weight | 101.20 lb / 45.9 kg |
| Regulations | cTUVus, EPEAT Silver, BSMI, TGM, LBL, FF, REACH, WEEE, FCC_ICES003, ES8.0, CE_EMC, CB, EAC, UKr, ErP-EEL | Energy Star Version | 8.0 |
| EEI Rating | D | Power Cord | x1, 3 meters, by shipping area: VSA US / VSE UK, EU / VSI UK, AU / VSCN CN |
| USB Touch Cable | x1, 3 meters | Touch Pen | Passive pen x2 |
| Quick Start Guide | With Compliance statement | Screw | x4, for wall mount |
| HDMI Cable | x1, 3 meters, HDMI LA certified | Remote Controller | x1 |
| AAA Battery | x2 | Warranty Card | Only for VSCN |
| Compatible Slot-in PC | VPCF5-S55-G1-2A / VPCF5-W55-G1-2A / VPC35-W53-G1 / VPC-A31-O1 / VPC11-C33-G1 / VPC13-C33-G1 / VPC15-C53-G1 |
