OVERVIEW
Whether for office use or for enjoying entertainment at home, the ViewSonic® VX2776-SMH is designed to take your viewing experience to another level. With a SuperClear® IPS panel and a sleek frameless design, this monitor provides a near-seamless viewing experience ideal for multi-monitor setups. The Full HD resolution boosts efficiency and image detail needed for work or play. A mega dynamic contrast ratio of 80M:1 delivers enhanced image depth for a better user experience. The Built-in HDMI and VGA inputs deliver flexible connectivity options for a wide range of devices.
Clarity From Any Angle
Enjoy accurate and vivid colours with consistent levels of brightness no matter your vantage point. With SuperClear® IPS panel technology, the monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.
SuperClear 178°/178°
Premium Design
The monitor takes on an architecturally inspired design aesthetic, fused with modern form factors such as a thin profile, modern frameless bezel, and a unique triangular stand.
Thin profile, frameless bezel, Chrome like triangular stand
75Hz Refresh Rate
With 75Hz refresh rate, this monitor delivers great visual fluidity and flawless graphics no matter how quickly the in-game action unfolds.
75Hz
ViewMode Optimised Settings
ViewSonic’s ViewMode includes optimised “Game”, “Movie”, “Web”, “Text”, “Mono”, and “Mac” presets. Each preset offers specialised enhancements to gamma curve, colour temperature, contrast, and brightness to deliver the optimal viewing experience for different applications.
Game, Movie, Web, Text, Mac, Mono
Eye Care Technology
Flicker-Free Technology and a Blue Light Filter minimise eyestrain over extended viewing periods.
Blue Light Filter & Flicker-Free
Dual Integrated Speakers
Designed with dual integrated speakers, this monitor combines incredible screen performance with stereo sound for an immersive multimedia experience.
2W x 2
Low Energy Consumption
ViewSonic’s energy efficient Eco-Mode adjusts brightness to the optimal setting to reduce power consumption and eye fatigue while also prolonging the monitor’s lifespan.
ECO-Mode
-
| Display |
|
| Display Size (in.) |
27 |
| Viewable Area (in.) |
27 |
| Panel Type |
IPS Technology |
| Resolution |
1920 x 1080 |
| Resolution Type |
FHD |
| Static Contrast Ratio |
1,000:1 (typ) |
| Dynamic Contrast Ratio |
80M:1 |
| Light Source |
LED |
| Brightness |
250 cd/m² (typ) |
| Colors |
16.7M |
| Color Space Support |
8 bit (6 bit + Hi-FRC) |
| Aspect Ratio |
16:9 |
| Response Time (Typical GTG) |
4ms |
| Viewing Angles |
178º horizontal, 178º vertical |
| Backlight Life (Hours) |
30,000 Hrs (Min) |
| Curvature |
Flat |
| Refresh Rate (Hz) |
75 |
| Blue Light Filter |
Yes |
| Flicker-Free |
Yes |
| Color Gamut |
NTSC: 72% size (Typ), sRGB: 100% size (Typ) |
| Pixel Size |
0.311 mm (H) x 0.311 mm (V) |
| Surface Treatment |
Anti-Glare, Hard Coating (3H) |
| Compatibility |
|
| PC Resolution (max) |
1920x1080 |
| Mac® Resolution (max) |
1920x1080 |
| PC Operating System |
Windows 10 certified; macOS tested |
| Mac® Resolution (min) |
1920x1080 |
| Connector |
|
| VGA |
1 |
| 3.5mm Audio In |
1 |
| 3.5mm Audio Out |
1 |
| HDMI 1.4 |
2 |
| Power in |
3-pin Socket (IEC C14 / CEE22) |
| Audio |
|
| Internal Speakers |
2 Watts x 2 |
| Power |
|
| Eco Mode (Conserve) |
18W |
| Eco Mode (optimized) |
21W |
| Consumption (typical) |
24W |
| Consumption (max) |
25W |
| Voltage |
AC 100-240V, 50/60 Hz |
| Stand-by |
0.5W |
| Power Supply |
Internal |
| Additional Hardware |
|
| Kensington Lock Slot |
1 |
| Controls |
|
| Physical Controls |
Key 1 (favorite), Key 2, Key 3, Key 4, Key 5, Key 6 (power) |
| On Screen Display |
Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
| Operating Conditions |
|
| Temperature |
32°F to 104°F (0°C to 40°C) |
| Humidity (non-condensing) |
20% to 90% |
| Wall Mount |
|
| VESA Compatible |
75 x 75 mm |
| Input Signal |
|
| Frequency Horizontal |
15 ~ 83KHz |
| Frequency Vertical |
50 ~ 75Hz |
| Video Input |
|
| Digital Sync |
TMDS - HDMI (v1.4) |
| Analog Sync |
Separate - RGB Analog |
| Ergonomics |
|
| Tilt (Forward/Back) |
-3º / 15º |
| Weight |
|
| Net (lbs) |
8.8 |
| Net Without Stand (lbs) |
7.9 |
| Gross (lbs) |
12.1 |
| Weight (metric) |
|
| Net (kg) |
4 |
| Net Without Stand (kg) |
3.6 |
| Gross (kg) |
5.5 |
| Dimensions (imperial) (wxhxd) |
|
| Packaging (in.) |
27.6 x 18.2 x 4.4 |
| Physical (in.) |
24.2 x 17.5 x 7.2 |
| Physical Without Stand (in.) |
24.2 x 14.1 x 1.9 |
| Dimensions (metric) (wxhxd) |
|
| Packaging (mm) |
702 x 462 x 112 |
| Physical (mm) |
614 x 443 x 184 |
| Physical Without Stand (mm) |
614 x 357 x 49 |
| General |
|
| Regulations |
CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, BSMI, BIS |
| PACKAGE CONTENTS |
|
| PACKAGE CONTENTS |
VX2776-SMH x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, Quick Start Guide x1 |
| Recycle/Disposal |
|
| Recycle/Disposal |
Please dispose of in accordance with local, state, or federal laws. |
| Warranty |
|
| Warranty |
*Warranty offered may differ from market to market |
-
Warranty
ViewSonic provides customers with the security of a manufacturer’s warranty against defected products. We are keen to provide our customers with great peace of mind and confidence in our product. With that in mind, we are now providing 3 years limited warranty on selected*
