Three-way
These loudspeakers use three drivers; a woofer, a squawker, and a tweeter. Asking a driver to produce a wide range of frequencies is always a compromise, so dividing the sonic range into three means each driver has a narrower range of frequencies to produce, resulting in less distortion and clearer sound.
Bass reflex
A bass reflex port allows greater excursion of the woofer, allowing the woofer to produce lower frequencies, and the phase-delayed movement of air from behind the woofer to the front reinforces the bass even more.
Rugged grille
A metal grille protects the drivers from physical interference.
Tough finish
Constructed with tough ABS plastic, the finish withstands the rigors of the professional use.
Pro AV applications
In small to medium presentation environments a wide dispersion is generally more important than microphone feedback management, so no horns are used.
Horizontal C bracket
The adjustable brackets allow the installer to easily angle up 30º or down 30º. Or leave the brackets off and use as shelf speakers.
| Feature | Specification |
|---|---|
| General | |
| Enclosure Colour | White |
| Product Type | Audio system |
| Warranty | Limited lifetime warranty |
| Miscellaneous | |
| Included Accessories | Mounting hardware, AC power adaptor, audio cable, remote control, speaker cable |
| Power | |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Connections | |
| Connectors | 2 × audio line-in (Phoenix-type) – rear Audio line-in (3.5 mm stereo mini-jack) – front 2 × speaker output – rear |
| Dimensions & Weight | |
| Speaker System | 17.8 × 19.3 × 24 cm / 4.2 kg |
| Amplifier | 4.2 × 4 × 7.1 cm / 63 g |
| Audio System | |
| Audio Channels | Stereo |
| Output Power | 50 W total |
| Input Impedance | 50 kΩ |
| Functions | Amplifier |
| Input Sensitivity | 500 mV |
| Components | Amplifier, Speaker system |
| Features | In-wall mountable, Digital Amplifier |
| Audio Specifications | Response: 80 – 22000 Hz / SNR: 98 dB / THD: 1% |
| Amplifier Output | 25 W – 8 Ω – 2 channels |
| Speaker System | |
| Speakers | 2 × 3-way external, 50 W, 70 – 20000 Hz, 8 Ω, wired |
| Driver Details | Woofer: 5.25″ Tweeter: 0.5″ Silk Mid-range: 1″ |
| Description | Downloads |
|---|---|
| Vision Professional Audio Kit | TC3-AMP+SP-1800 DataSheet | Download |
