Vivolink HDMI 2.0 Matrix Switcher 8x8 | VLHDMIMAT8X8
The VLHDMIMAT8X8 is a versatile 2x8 HDMI splitter designed to distribute two HDMI sources to up to eight outputs. It supports video resolutions up to 4K@60Hz with 4:4:4 chroma subsampling, HDR10, and Dolby Vision, ensuring exceptional video quality. With a bandwidth of 18Gbps and HDCP 2.2 compliance, it guarantees compatibility with the latest high-definition content.
Key features include 4K-to-1080p downscaling on all outputs, allowing seamless integration with both 4K and 1080p displays. The splitter offers digital Toslink and analog L+R audio de-embedding for flexible audio extraction. Built-in signal equalization enhances transmission stability, while comprehensive EDID management and CEC support ensure optimal device communication.
Typical Applications:
Conference Rooms:
Perfect for large meeting spaces where multiple presenters need to share content from various devices on multiple displays.
Control Centers:
Ideal for monitoring multiple inputs and routing them to different outputs efficiently in security, broadcasting, or command centers.
Educational Facilities:
Great for lecture halls and classrooms that require flexible content distribution to multiple screens or projectors.
Retail and Digital Signage:
Useful for large retail stores or shopping malls to display synchronized or independent promotional content on multiple screens.
Home Theaters:
High-end home theater setups that demand seamless switching between various HDMI sources like gaming consoles, Blu-ray players, and streaming devices across multiple displays.
Event Venues:
Suitable for exhibition halls or event spaces where content needs to be distributed and displayed across various areas.
Corporate Environments:
Allows seamless collaboration and display of information across various teams and departments on dedicated displays.
| Category | Details |
|---|---|
| Audio Support | PCM, 2.0 channels |
| Bandwidth | 18 Gbit/s |
| Features | CEC Support, EDID Support, Plug and Play |
| Video Support | 4K Ultra HD, 60 fps |
| HDCP | Yes (Version 2.2) |
| LED Indicators | Yes |
| Product Design | Black, Rack Mountable |
| Remote Control | IR + RS232 |
| Legal | Details |
| EU ECCN Code | N/A |
| US ECCN Code | 5A992 |
| Operational Conditions | Details |
| Operating Temperature | -5 to 55 °C |
| Package Dimensions | Details |
| Depth | 54 cm |
| Height | 14 cm |
| Width | 35 cm |
| Gross Weight | 3.1 kg |
| Packaging Content | Details |
| AC Adapter Included | Yes |
| Cables Included | IR Sensor |
| Mounting Brackets | Yes |
| Remote Control | Yes |
| Ports & Interfaces | Details |
| Audio Out (L/R) | 1 |
| Digital Audio Coaxial Out | 1 |
| HDMI In | 4 |
| HDMI Out | 4 |
| HDMI Version | 2.0 |
| RJ-45 Input Ports | 1 |
| RS-232 Ports | 1 |
| S/PDIF Out Port | Yes |
| Power Specifications | Details |
| AC Input Voltage | 100 - 240 V |
| Product Dimensions | Details |
| Depth | 54 cm |
| Height | 14 cm |
| Width | 35 cm |
| Net Weight | 2 kg |
| Technical Details | Details |
| Audio Support | Yes |
| Description | Downloads |
|---|---|
| Datasheet | Download |
