Vivolink VLVWIP2000-ENC is based on JPEG2000 technology.
It integrates Copper port and Fiber port within a single box. Encoder input supports up to 4K60 4:4:4, audio embedding or extracting.
Decoder output supports up to 4K60 4:4:4, audio extracting.
The product supports ARC/eARC/S/PDIF/Analog audio return function, also supports USB2.0/KVM/Camera, 1G Ethernet, bidirectional RS- 232, two-way IR and POE function.
Guest mode controls of RS-232, IR, CEC are supported. Built-in two channel RELAY ports and two channel I/O ports for contact control. Dante AV-A mode is supported if the product is license activated.
Built-in MJPEG Substream which supports plenty API commands to achieve flexible configurations is useful for 3rd party control Apps to preview video content.
The system is based on Linux for software development, provides flexible control methods, that are based on the intelligent networking of 1G Ethernet Switch.
The system requires a layer3 1G managed network switch supporting IGMP snooping and 8K Jumbo frame. With the PoE function it is also possible to power the unit without a PSU.
| Audio support | Yes | Cable types supported | Cat6a |
| Connectivity technology | Wired | Easy to install | Yes |
| HDCP | Yes | HDCP version | 2.2 |
| KVM port selection | OSD | LED indicators | Link/Power |
| Maximum digital resolution | 4096x2160@60Hz | Plug and Play | Yes |
| Product colour | Black | Supported resolutions | 4K@60Hz 4:4:4 |
| USB 2.0 ports quantity | 2 | Country of Origin | China |
| EU ECCN Code | N/A | Tariff No. | 8543709099 |
| UNSPSC Code | 43211601 | US ECCN Code | 5A992 |
| Operating temperature | -5 - 55 °C | Storage temperature | -25 - 70 °C |
| Depth (package, cm) | 28 cm | Gross Weight (Package, kg) | 0.82 kg |
| Height (package, cm) | 8 cm | Width (package, cm) | 18 cm |
| AC adapter included | Yes | Power plug types | EU |
| Manual | Yes | Mounting bracket included | Yes |
| Quick installation guide | Yes | HDMI version | 1.4b/2.0b |
| Remote (IR) input | 1 | Remote (IR) output | 1 |
| RJ-45 ports quantity | 1 | RS-232 ports | 1 |
| USB port type | USB Type-B | AC input voltage | 100 - 240 V |
| DC voltage | 12 V | DC-in jack | Yes |
| Input current | 2.5 A | Power consumption | 30 W |
| Net Weight (Product, kg) | 0.5 kg | Product Depth | 13.5 cm |
| Product Height | 2.5 cm | Product Width | 20.3 cm |
| Receiver video port | HDMI | Receiver video ports qty | 1 |
| Receiver USB Type-A ports qty | 4 | RJ-45 ports (receiver) | 1 |
| Dimensions (WxDxH) | 205 x 140 x 26 mm | Maximum resolution | 4096x2160 pixels |
| Video in | HDMI | Weight | 265 g |
| Transmitter keyboard/mouse | USB | Brand Name | Vivolink |
| Warranty | 3 Year(s) |
| Description | Downloads |
|---|---|
| Datasheet | Download |
