The SW-220-TX-W is the perfect solution for today’s huddle spaces and small meeting rooms. This switcher is equipped with the essential connectivity to have a successful meeting. USB-C and HDMI local inputs provide simple methods for sharing content to a display. In addition to the wired inputs, the SW-220-TX-W also supports native wireless casting via Airplay and Miracast so content can be shared easily from a tablet or smartphone. Connect a 4K camera or other highspeed USB devices to the USB 3.0 device ports and take advantage of the power and unification that is USB-C.
Tailored for Corporate
For the smaller sized meeting rooms, this presentation switcher brings those important corporate meetings together, conveniently allowing every participant to present at any time, and from anywhere in the room.
WIRELESS CASTING
Wirelessly screenshare from your laptop, phone or tablet by using Apple Airplay or Miracast. Take advantage of the convenience wireless casting has to offer.
DUAL-VIEW
Display up to 2 source devices at the same time. This can be a combination of wired and wireless devices, creating a supportive environment for collaboration between colleagues and teams.
USB-C DONGLE
Compatible with the Apollo APO-DG1 casting dongle, simply plug the dongle into an available USB-C port on your computer and tap the button. Getting connected couldn’t be easier!
USB 3.0
A built-in USB 3.0 hub on the switcher connected to the USB-C input allows local connection of peripherals devices such as a conference speakerphone or 4K camera.
In the Box
1x SW-220-TX-W
1x 12V DC Power Supply (UK/US/EU/AU)
1x 5-pin Terminal Block
2x Mounting Brackets with Screws
1x Quickstart Guide
| Category | Details |
|---|---|
| AUDIO & VIDEO | |
| Inputs | 1x HDMI In, 1x USB-C, Wireless video from Airplay, Miracast, or APO-DG1 |
| Outputs | 1x HDMI Out, 1x Audio Out (5-pin balanced phoenix) |
| Video Resolution (Max) | Wireless Casting: 1920x1080p @30Hz, HDMI & USB-C: 3840×2160 @30Hz 4:4:4 8bit |
| Video Encoding | Uncompressed HDMI |
| HDMI Bandwidth | 10.2Gbps |
| Audio Formats | 2ch PCM |
| Supported Standards | DCI |
| Maximum Pixel Clock | 300MHz |
| COMMUNICATION & CONTROL | |
| HDMI | HDMI 1.4 |
| USB | 2x USB 3.2 Gen1 Type A device ports, 1x USB 3.2 Gen2 Type C host port |
| ETHERNET | 1x 8-pin RJ-45 (API control & WebUI) |
| Wireless | 2x Wi-Fi Antennas |
| POWER | |
| Power Supply | 12V DC 2A |
| Power Consumption | 12w |
| Description | Downloads |
|---|---|
| Spec Sheet | Downloads |
