Compact Class B HDBaseT receiver supporting 4K HDR transmissions up to 35 meters from a compatible HDBaseT matrix or presentation switcher. 2-way PoH allows the RX-35-POH to power over category cable from a PoH matrix or switcher and also allows for the receiver to power in-wall HDBaseT transmitters.
CLASS B HDBASET™
Small in size but not in specification, the RX-35-POH is no different to the modern H2 family of products, supporting pixel-perfect 4K UHD 4:2:0 10-bit @24Hz at distances up to 35m/115ft or 1080p to 35m/115ft.
CONTROL OPTIONS
Supports 3 methods of control pass-through. Being a pure HDBaseT™ device, the RX-35-POH can handle bi-directional IR, RS-232 and even CEC routing when used as part of a compatible WyreStorm matrix or extender system.
POH
The RX-35-POH can be powered by a PoH compatible matrix or presentation switcher meaning one less thing to think about when specifying & installing a WyreStorm system.
FULLY COMPLIANT WITH HDCP 2.2 ENCRYPTION
As with all of our HDBaseT Receivers, remaining relevant & legal is key to their operation. The RX-35-POH is compliant with the strict anti-piracy algorithms that prevent the unauthorized distribution of content, meaning a trouble-free installation.
Product Features
Receives 4K UHD HDBaseT transmissions up to 35m/115ft
Compatible with 4K HDR source content
Compatible with HDCP 2.2 protected content
2-way PoH enabled for convenient PSU-free installation
RS-232 and IR passthrough for control of peripheral equipment
| Category | Specification |
|---|---|
| Audio and Video | |
| Inputs | 1x HDBaseT In 8-pin RJ-45 female |
| Outputs | 1x HDMI 19-pin type A |
| Output Video Encoding | HDBaseT Class B |
| Encoding Data Rate | 9.2Gbps |
| End to End Latency (Max) | 10μs (micro seconds) |
| Audio Formats | 2ch PCM |
| Video Resolutions (Max) | 1920x1080p @60Hz 16bit, 3840x2160p @60Hz 10bit 4:2:0 HDR, 4096x2160p @60Hz 8bit 4:2:0 |
| HDMI Cable Length | 7m/23ft |
| Cat6 Cable Length | 70m/230ft (Max), 35m/115ft (Max) |
| Cat6a/7 Cable Length | 70m/230ft (Max), 35m/115ft (Max) |
| Note | WyreStorm recommends using shielded category cable to minimize signal noise and interference |
| Supported Standards | DCI |
| Maximum Pixel Clock | HDMI: 297MHz |
| Communication and Control | |
| HDMI | HDCP 2.2 |
| HDBaseT | HDCP 2.2 |
| IR | 1x IR TX 3.5mm (1/8in) Mono |
| RS-232 | 1x 3-pin Phoenix Connector |
| Power | |
| Power Supply | 12V DC (Optional) |
| PoH | 2-way |
| Max Power Consumption | 7.2W |
| Environmental | |
| Operating Temperature | 32°F ~ 113°F (0°C ~ 45°C), 10% ~ 90%, non-condensing |
| Storage Temperature | -4°F to ~ 158°F (-20°C ~ +70°C), 10% ~ 90%, non-condensing |
| Maximum BTU | 24.6 BTU/hr |
| Dimensions & Weight | |
| Rack Units/Wall Box | <1U |
| Height | 21mm/0.82in |
| Width | 140mm/5.5in |
| Depth | 80mm/3.14in |
| Weight | 0.29kg/0.65lbs |
| Regulatory | |
| Safety and Emission | CE |
| Description | Downloads |
|---|---|
| Spec Sheet | Downloads |
