WyreStorm 80m KVM UTP Extender | EX-80-KVM
SKU: EX-80-KVM
£169.99 (Excl. VAT)
- Description
- Specifications
- Downloads
-
WyreStorm 80m KVM UTP Extender | EX-80-KVM
The WyreStorm EX-80-KVM is a plug and play HDMI and KVM extender, capable of sending up to resolutions of 1080p@60Hz and HID (Human Interface Device) up to 80m (262ft) over a single CAT5e/6 cable. Additionally, it supports bidirectional POC (Power Over Cable) for powering at either the transmitter or the receiver with only one power adapter, making installations quick and effortless. Perfect use in office, home and presentation settings to extend HD video and USB keyboard and mouse from a local zone to a remote PC or laptop
USB 2.0 PASSTHROUGH
The EX-80-KVM offers highspeed USB 2.0 pass-through, capable of not only KVM functionality for extension of a keyboard/mouse or touchscreen but also full data transfer capabilities of 480Mbps for webcams or USB peripherals..
BIDIRECTIONAL POC
With it’s KVM extension, the EX-KVM-80 includes bidirectional Power Over Cable abilities, saving the installer time and headache from having to supply local power discreetly to both ends.
HDCP COMPLIANT
WyreStorm extender solutions play nice with the equipment they’re connected to, ensuring that the HDCP encryption is maintained throughout the process
DISCREET, SMALLER FOOTPRINT
As with all of WyreStorm’s line of extenders, we strive to give you the most functionality, while keeping the chassis size as minimal as possible, making it easier to keep discreet. -
Category Specification AUDIO & VIDEO Inputs (TX) 1x HDMI In: 19-pin type A, 1x USB Type B Inputs (RX) 1x UTP In: 8-pin RJ-45 Female, 2x USB Type A Outputs (TX) 1x UTP Out: 8-pin RJ-45 Female Outputs (RX) 1x HDMI Out: 19-pin type A Video Encoding UTP Encoding Data Rate 6.75Gbps End to End Latency 10μs (microseconds) Audio Formats 2ch PCM, Multichannel up to DTS-X and Dolby Atmos Video Resolution (Max) 1920x1080p @60Hz 12bit Supported Standards DCI, RGB Maximum Pixel Clock 225MHz COMMUNICATION & CONTROL HDMI HDMI 1.3b, HDCP 1.4, EDID, DVI/D supported with adapter (not included) UTP HDMI 1.3b, HDCP 1.4, EDID, 2-way PoC USB 1x Type B (host), 2x Type A (device) (Transmitter and Receiver), Maximum uplink speed: 480Mbps USB Distance 60m/197ft Cat6,6a,7 POWER Power Supply 12V 2A PoC IEEE 802.3af 48V 15.4W Max, 2-way Max Power Consumption 3.6W (per unit) Additional Features Full HD video resolution up to 1080P@60Hz at up to 80m (262ft), Supports USB 2.0 data transfers Bidirectionally up to 60m (197ft) and HID up to 80m (263ft), HDMI 1.3 and HDCP 1.4 Compliant Bidirectional PoC – Powered at either the transmitter or receiver with only one power adapter. -
Description Downloads SpecSheet Downloads
