DISCREET, SMALLER FOOTPRINT
WyreStorm’s newly designed 40 meter extender, the EX-40-G3, is now smaller than ever. With almost half the width of its predecessor, this makes the G3 lighter in weight and easier to keep discreet.
POC READY
Size isn’t the only upgrade found in the newly designed 40 meter extender. The G3 now includes Power over Cable abilities, saving the installer time and headache from having to supply local power discreetly to the receiver. But don’t fret if PoC isn’t available, as the receiver is capable of accepting local power.
FEATURE RICH; UNBEATABLE VALUE
With features such as PoC, automatic EDID, long cable mode capability and IR source control, the EX-40-G3 brings a tremendous amount of features to any simple installation at a cost effective price.
HDCP COMPLIANT
WyreStorm extender solutions play nice with the equipment they’re connected to, ensuring that the HDCP encryption is maintained throughout the process.
In the Box
1x EX-40-G3 Transmitter
1x EX-40-G3 Receiver
1x 5V DC 1A Power Supply (US/UK/EU/AU)
1x USB-A to Micro-B RX Power Cable
1x IR Emitter
1x IR Receiver
4x Mounting Brackets (2x for TX | 2x for RX)
1x Quickstart Guide
| Category | Specification |
|---|---|
| AUDIO & VIDEO | |
| Inputs | |
| Transmitter | 1x HDMI 19-pin type A |
| Receiver | 1x UTP 8-pin RJ-45 female |
| Outputs | |
| Transmitter | 1x UTP 8-pin RJ-45 female |
| Receiver | 1x HDMI 19-pin type A |
| Output Video Encoding | TMDS over UTP |
| Encoding Data Rate | 6.75Gb/s |
| Audio Formats | 2ch PCM |
| Video Resolutions (max) | 1920x1080p @60Hz 8bit |
| Supported Standards | DCI |
| Maximum Pixel Clock | 225MHz |
| COMMUNICATION & CONTROL | |
| HDMI | HDMI 1.3b |
| UTP | HDMI |
| IR | Transmitter: 1x IR TX: 3.5mm (1/8in) TRS Mono |
| POWER | |
| Power Supply | 5V DC 1A (Optional for Receiver) |
| PoC | 1-way Transmitter to Receiver |
| Max Power Consumption | 2.5W (TX/RX Pair) |
| Description | Downloads |
|---|---|
| SpecSheet | Downloads |
