WyreStorm TX-35-IW HDMI Single Gang In-Wall HDBaseT Transmitter
SKU: TX-35-IW
£143.64 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Professional In-Wall HDMI Signal Extension Over HDBaseT
The TX-35-IW provides simple transmission of remote HDMI sources. Pair with the RX-35-POH for simple yet effective signal extension of 4K UHD content. The TX-35-IW uses standardized HDBaseT and PoH technology, meaning that it is compatible with many WyreStorm models including presentation receivers or the H2XC series of matrix switchers. The TX-35-IW is great for remote input applications including education environments such as training rooms or huddle spaces. It can be remotely powered from a compatible HDBaseT receiver and features IR and RS-232 control signal passthrough.
SMALL FOOTPRINT
Powerful HDBaseT technology in the smallest footprint possible. Install the TX-35-IW into standard 1-Gang US sized wall boxes. Keep your installations looking professional and tidy.
COST EFFECTIVE
Retaining core functionality, the TX-35-IW has the capability you need and gets rid of those you don’t. Easily transmit HDMI content, control signals and power over a single category cable.
POH
The TX-35-IW features PoH technology which allows it to be powered from a compatible HDBaseT receiver. Eliminate the need for bulky DC power supplies and remotely power the TX over category cable.
VERSATILITY
Using standard technologies such as HDBaseT and PoH makes the TX-35-IW compatible with a myriad of WyreStorm receivers such as the SW-515-RX, or even as a remote input into the MX-H2XC for larger deployments.
In the Box
1x 2 pin Phoenix Male Connector
2x 3 pin Phoenix Male Connector
1x 1-Gang Decora Wall Plate
Device powers via PoH (12V 2A DC PSU Sold Separately)
1x Quickstart Guide -
Inputs 1x HDMI Outputs 1x HDBaseT Class B (Transmission to RX) Output Video Encoding UTP Maximum Sampling Rate 192KHz Audio Formats 2ch PCM | Multichannel LPCM | DTS-X, Dolby Atmos Video Resolutions (max) 5120×1440 @60Hz 4:2:0
5120×1440 @30Hz
4096x2160p @60Hz 8bit 4:2:0
3840x2160p @24Hz 10bit 4:2:0 HDR
3840x2160p @30Hz 8bit 4:2:0
1920x1080p @60HzSupported Standards DCI | RGB Maximum Pixel Clock 297MHz HDMI HDMI 1.4 | HDCP 1.4 | EDID EDID Pass-Through, from RX IR Passthrough; Front panel window, Rear 3-pin phoenix RS-232 1x 3-pin Phoenix, Bi-directional passthrough Power Supply PoH; 12V DC 1A (sold separately) PoH Supported, 1-way from RX Max Power Consumption 7.8W Local Power Supply Input 2-pin Phoenix -
Description Downloads Datasheet Download
