24-Port Smart Managed Gigabit PoE Switch offers seamless connectivity with 130W PoE budget, fanless design, VLAN, QoS, and advanced management protocols. Perfect for SMBs and wall-mountable setups. Supports IGMP snooping, RSTP, LLDP-MED, and more for efficient and reliable performance.
| Category | Details |
|---|---|
| General | |
| Subtype | Gigabit Ethernet |
| MAC Address Table Size | 8K entries |
| Authentication Method | RADIUS |
| Encryption Algorithm | SSL |
| PoE Budget | 130 W |
| Power Over Ethernet | PoE |
| Jumbo Frame Support | 9KB |
| Enclosure Type | Desktop, wall-mountable |
| Device Type | Switch - 24 ports - smart |
| Performance | |
| Switching Capacity | 48 Gbps |
| Forwarding Performance | 35.7 Mpps |
| Ports | 24 x 10/100/1000 (12 PoE) |
| Packet Buffer Size | 525,000 |
| Routing Protocol | IGMP, IGMPv2, IGMPv3, STP, RSTP |
| Remote Management | SSH-2, SNMP (1, 2c, 3), RMON, ICMP, Syslog |
| Features | VLAN, QoS, Loop Guard, Port Security, PoE scheduling, Storm Control |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3af, 802.3at, 802.1D/Q/p |
| Expansion/Connectivity | |
| Interfaces | 12 x PoE+ RJ-45, 12 x RJ-45 |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption | 166.1 W |
| Environmental | |
| Operating Temp Range | 0 °C to 40 °C |
| Storage Temp Range | -40 °C to 70 °C |
| Operating Humidity | 10% - 95% (non-condensing) |
| Storage Humidity | 10% - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 33 cm |
| Depth | 23 cm |
| Height | 4.4 cm |
| Weight | 2.48 kg |
| Miscellaneous | |
| Included Accessories | Rack mount kit |
| MTBF | 768,989 hours |
| Compliance | FCC, RCM, RoHS, LVD, EN 62368-1 |
