4G LTE-A Pro Outdoor Router
Unparalleled Performance for Harsh Areas
Strong Design, Longer Durability
Robust design makes LTE7490-M904 possible to work in frigid environment and where desirable signal strength is difficult to achieve, but also guarantees a longer device life and reliability.
Dust, dirt and sand resistant
IP68
Water resistant
Level 16
Withstand hurricane level wind speed (200km/hr)
K.21
Enhanced-mode lightning protection
-40° C to 60°C
Adapts to wide range temperature
Signal that Travels Farther and Faster
LTE7490-M904 employs the best-practice 4G LTE-A Cat. 18 with data rates of up to 1.2Gbps/150 Mbps* (Downlink/Uplink). Get up to 8 dBi per element for stronger and better signal performance with its built-in four 4x4 MIMO wide transmission directional antennas. Integrates high speed, strong signal, and long-range transmission.
Non-stop Connectivity
The wireless LTE allows you to take advantage of the 2nd WAN without a cabling plan. As long as the gateway supports “Dual-WAN Failover ”, you can just connect the LTE7490-M904 to the existing gateway and set LTE as the failover WAN and relieve the risk of network outage. More, its flexible routing modes with both bridge and router functions. No matter if you already have a router or not, it can be easily deployed and integrated into your existing environment. Enjoy non-stop and flexible network now!
Not Just Connected, but Secured
LTE7490-M904 is deployed with simple yet essential security and protection functions to help you reduce the risk of falling a victim of data theft and sabotage.
DoS attack
SPI
Application-level firewall
LAN MAC filtering
IP filtering
URL filtering
Effortless Installation
All you need to do is insert a micro-SIM card and use a smartphone or tablet to connect the LTE7490-M904’s WiFi network. Follow its configuration instruction on the free “Zyxel Air” app to find the best signal spot for installation. Comes with flexible wall and pole mounting options. Integrated PoE support makes power requirements a non-issue.
Easy Remote Management
Configure settings, accessibility features, monitor the network status, upgrade software, change network name/password, manage firewall, and more all from TR-069 and HTTP/web GUI. Keeping your network healthy has never been easier!
| System Specifications | |
|---|---|
| IP Networking | |
| Supports IPv4/IPv6 dual stack (NDP IPv6) | Yes |
| DHCP server | Yes |
| Supports ICMP | Yes |
| Virtual Private Network (VPN) passthrough | Yes |
| Supports NAT/NAPT | Yes |
| Supports NAT DMZ | Yes |
| Supports port forwarding/triggering | Yes |
| Supports ALG | Yes |
| Routing | |
| Supports router mode | Yes |
| Supports bridge (IP pass-through) mode | Yes |
| Supports dynamic DNS for first APN | Yes |
| Supports remote management under bridge mode | Yes |
| IP Firewall | |
| Firewall can be enabled or disabled via GUI | Yes |
| DoS attack prevention | Yes |
| Supports SPI | Yes |
| Application-level firewall | Yes |
| Filters LAN MAC addresses | Yes |
| Filters URLs | Yes |
| Management | |
| Supports local/remote device management | Yes |
| Firmware upgrade via TR-069, HTTP/web GUI, and FTP | Yes |
| APN management | Yes |
| Account management | Yes |
| PIN/PUK management | Yes |
| Network selection | Yes |
| Operating frequency band selection | Yes |
| CLI/SSH (local and remote SSH access) | Yes |
| Supports UPnP IGD | Yes |
| Supports SSH with key access certification management | Yes |
| Supports bandwidth/quota management | Yes |
| Supports mobile apps (iOS and Android) for easy installation and local management only | Yes |
| Supports remote throughput testing by TR-143 | Yes |
| WiFi Protected Setup (WPS) | Yes |
| Hidden SSID | Yes |
| Hardware Specifications | |
| LTE interface | |
| Standard-compliant: 3GPP UE DL Category 18, UL Category 13 | Yes |
| Supports LTE bands: B1/B3/B5/B7/B8/B20/B28/38/40/41 | Yes |
| Supports DL transmission mode TM1/2/3/4/6/7/8/9 | Yes |
| LTE antennas: 4 embedded directional antennas of up to 8 dBi/element (4x4 MIMO) | Yes |
| Supports DL 5xCA**, 2x2 MIMO | Yes |
| Supports DL 3xCA, 4x4 MIMO, B1/3/7** | Yes |
| Supports DL modulations QPSK, 16-QAM, 64-QAM and 256-QAM | Yes |
| Supports UL modulations QPSK, 16-QAM and 64-QAM | Yes |
| Supports UL 2xCA** intra-band, B3/7/38/40/41 | Yes |
| Peak data rates: | |
| DL: 1.2 Gbps within 100 MHz bandwidth | Yes |
| UL: 150 Mbps within 40 MHz bandwidth | Yes |
| UMTS Air interface | |
| Standard-compliant: WCDMA bands 1/3/5/8 | Yes |
| Supported frequencies: | |
| HSPA+/UMTS: 2100/1800/900/850 MHz (bands 1/3/5/8) | Yes |
| WCDMA: 2100/1800/900/850 MHz | Yes |
| HSPA+ downlink data rates up to 42 Mbps | Yes |
| HSUPA uplink data rates up to 5.76 Mbps | Yes |
| WiFi Air interface*** | |
| Wireless standards: 802.11 b/g/n, 2.4 GHz, 300 Mbps | Yes |
| Wireless omni antennas: | |
| WiFi 2.4 GHz: 2x2 internal antennas up to 3 dBi | Yes |
| Hardware Interface | |
| One Gigabit RJ-45 PoE LAN port | Yes |
| LED indicators for: | |
| Power status | Yes |
| Internet status | Yes |
| LTE signal strength | Yes |
| WiFi status | Yes |
| LAN status | Yes |
| One WiFi on/off button | Yes |
| One 3FF micro SIM card socket | Yes |
| One reset to default button | Yes |
| Power Specifications | |
| Standard 802.3af/at Power over Ethernet (PoE) | Yes |
| Power consumption at PoE < 16 W | Yes |
| Power consumption | 16 watt (peak) |
| Physical Specifications | |
| Item dimensions (WxDxH): | 254 x 255 x 58 mm (9.99” x 10.03” x 2.28”) |
| Item weight: | 1100 g (2.43 lb.) |
| Package dimensions (WxDxH): | 280 x 402 x 108 mm (11.02” x 15.83” x 4.25”) |
| Package weight: | 2520 g (5.55 lb.) |
| Environmental specifications | |
| Ingress Protection rating | IP68 harden for outdoor environments |
| Lightning protection | K.21 enhanced mode, 6 kV |
| Operating environment | |
| Temperature: -40°C to 60°C (-40°F to 140°F) | Yes |
| Humidity: 5% to 95% (non-condensing) | Yes |
| Storage environment | |
| Temperature: -40°C to 70°C (-40°F to 158°F) | Yes |
| Humidity: 5% to 95% (non-condensing) | Yes |
| Certification | |
| CE | Yes |
| WEEE (Waste Electrical and Electronic Equipment) Directive certification | Yes |
| RoHS (Restriction of Hazardous Substances) Directive certification | Yes |
| HSF (Hazardous Substance Free) | Yes |
| European Parliament and Council Directive 94/62/EC of 20 December 1994 on packaging and packaging waste | Yes |
| Package contents | |
| Standard 802.3af/at Power of Ethernet (PoE) injector | Yes |
| 1.8 m Ethernet cable yellow 8P8C | Yes |
| PG19 thread (cable gland) | Yes |
| Quick Start Guide | Yes |
| Warranty card | Yes |
| DoC and safety warning | Yes |
| Wall/pole mounting kit | Yes |
| Wire grounding kit | Yes |
| Description | Downloads |
|---|---|
| Datasheet | Download |
| User Guide | Download |
