The PoE12-3PD is a Gigabit PoE Extender designed for point to multipoint
PoE applications, which effortlessly extend the range of power and data
connectivity when your devices are located at a distance that far away from
power source or connection to a PoE Switch. It features four RJ-45 Gigabit
Ethernet ports, offering one (1) PoE++ PoE input port with up to 60W power
input and three PoE output to your devices. Instead of connecting to an AC
adapter, connecting via a PoE switch enables better visibility for network
management to cover the edge of your network. It features three PoE+ ports
to power a variety of PoE devices, including IP cameras, VoIP handsets, IoT
device, Sensors, PoE switches and wireless access points. PoE12-3PD is good
for residential and commercial network environment
| Category | Specification |
|---|---|
| Ethernet Interface | Gigabit Ethernet |
| Ethernet LAN Data Rates | 1000 Mbit/s |
| Cabling Technology | 10/100/1000 |
| Power over Ethernet (PoE) | Yes |
| Networking Standards | IEEE 802.3at, IEEE 802.3bt |
| Auto MDI/MDI-X | Yes |
| MAC Address Table | 2000 entries |
| Packet Buffer Memory | 128 MB |
| Transmission Method | tcp |
| Supported Network Protocols | ip |
| Compliance Industry Standards | IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Duplex System | Full |
| Cable Types Supported | Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e |
| Web-based Management | Yes |
| Firmware Upgradeable | Yes |
| Syslog | No |
| Forwarding Rate | 8000 Mpps |
| Operational Conditions | Operating temp: -4 - 122 °F, Humidity: 10 - 95% |
| Storage temp: -40 - 70 °C, Humidity: 10 - 95% | |
| Physical Dimensions | Width: 180 mm, Depth: 99 mm, Height: 36 mm, Weight: 257 g |
| Packaging Data | Package length: 21.4 cm, Width: 125 mm, Depth: 47 mm, Weight: 114 g, Volume: 1257 cm³, Type: Box |
| Packaging Content | Number of products: 24 pc(s), Wall mounting kit: Yes, AC adapter: No, Power cord: No, Quick installation guide: Yes, Manual: No |
| Description | Downloads |
|---|---|
| Brochure | Downloads |
